KA65LKNFRYA - Deep fryer Kogan - Free user manual and instructions

Product Type	Air Fryer
Model	KA65LKNFRYA
Brand	Kogan
Capacity	6.5 L
Power Supply	220-240 V AC
Power Consumption	1700 W (estimated)
Temperature Range	140°C to 200°C
Timer	Up to 30 minutes
Controls	Two dials: Temperature and Time
Indicators	Power indicator (red), Heat indicator (green)
Basket Material	Stainless steel
Drawer Material	Stainless steel
Safety Features	Automatic shut-off when drawer opened, cool-touch handle, overheat protection
Cleaning	Basket and drawer are dishwasher safe; body wipe with damp cloth
Maintenance	No user-serviceable parts; professional servicing required for disassembly
Disposal	Do not dispose with household waste; recycle responsibly
Included Accessories	Frying basket, drawer
Cord Length	Short power-supply cord (approx. 0.8 m)
Usage	Household indoor use only

Frequently Asked Questions - KA65LKNFRYA Kogan

Do I need to preheat the air fryer?

Yes, it is recommended to add an additional 5 minutes to the cooking time to allow the air fryer to preheat if it is cold.

Can I use oil in the air fryer?

Yes, lightly oiling foods before air frying helps achieve browning and crispiness. Use an oil spray or brush a small amount of oil onto the food.

Why is my air fryer smoking?

Smoking is normal during first use. For subsequent uses, excess smoke may occur when cooking high-fat foods like chicken wings or sausages. Empty the fat from the drawer between batches and pat food dry before cooking.

How do I clean the air fryer?

Clean after each use. The basket and drawer are dishwasher safe. For the body, wipe with a damp cloth and mild detergent. Never immerse the body in water.

What is the maximum capacity of the frying basket?

Do not fill the basket more than 1/2 full to ensure proper air circulation and even cooking.

Can I cook frozen foods directly?

Yes, frozen foods like fries, chicken nuggets, and fish sticks can be cooked directly. Adjust cooking time and temperature according to the chart in the manual.

How do I know when the food is cooked?

Use a meat thermometer to check internal temperatures. Refer to the internal temperature chart in the manual for safe cooking guidelines.

What should I do if the air fryer does not turn on?

Ensure the frying basket drawer is fully closed. The air fryer will not operate unless the drawer is properly locked. Also check that the timer is set to a time above 0.

Can I use metal utensils in the basket?

It is not recommended to use abrasive cleaning materials or utensils on the stainless steel surfaces to avoid damage. Soak caked-on food in warm soapy water.

How do I store the air fryer?

Unplug and let it cool completely. Ensure all parts are clean and dry. Store in a clean, dry place.

USER MANUAL KA65LKNFRYA Kogan

Line drawing of a modern air fryer with control buttons and handle (no text or symbols)

6.5L XL AIR FRYER

KA65LKNFRYA

Handle this product with care and inspect it regularly to ensure it is in good working order.

If the product, power cord or plug shows any signs of damage: cease use immediately, unplug and contact help.Kogan.com for support.

When using an electrical appliance, basic safety precautions should always be followed, including the following:

• All users of this appliance must read and understand all instructions and safety notes before operating or cleaning this appliance. Retain this user guide for future reference.
• Do not touch hot surfaces. Always use handles or knobs.
• To protect against electric shock do not immerse cord, plugs or the appliance in water or other liquids.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Unplug the appliance from the electrical outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.
• Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Cease use immediately and contact help.Kogan.com for support.
• The use of accessory attachments not recommended by or supplied by Kogan.com may may cause injuries.
• Do not use outdoors.
• This appliance is intended for household use only.
• Do not let the cord hang over edge of a table or counter or touch hot surfaces.
• Do not place on or near a hot gas or electric burner or in a heated oven.
• Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
• To disconnect, turn both the time control and temperature control dials to the 'OFF' positions. Then remove the plug from the electrical outlet.

• Do not use this appliance for anything other than it intended use.

• Ensure the frying basket is locked into the front of the drawer – both frying basket handle tabs must be fully inserted into the slots on the top of the basket drawer.

• Always make sure the frying basket drawer is fully closed, with the frying basket handle locked securely in the drawer, while Air Fryer is in operation.

WARNING: Air Fryer will not operate unless frying basket drawer is fully closed.

Caution: After air frying, the frying basket, frying basket drawer and the cooked foods are hot. Extreme caution must be used when handling.

Caution: This appliance generates heat and steam during use. Proper precautions must be taken to prevent the risk of burns, fires or other injury to persons or damage to property.

Caution: This appliance is hot during operation and retains heat for some time after turning off. Always use oven mitts when handling hot materials and allow metal parts to cool before cleaning. Do not place anything on top of the appliance while it is operating or while it is hot.

• The cord to this appliance should be plugged into a 220-240V AC electrical outlet only.
• If this appliance begins to malfunction during use, cease use immediately and contact help.Kogan.com for support. Do not use or attempt to repair the malfunctioning appliance.
• Do not leave this appliance unattended during use.
• Keep the cord out of reach from children and infants to avoid the risk of electric shock and choking.
• Place the Air Fryer on a flat, heat-resistant work area.
• Do not obstruct the air outlet on the back side and the air inlet on the top of the Air Fryer with any objects.
• Keep appliance at least 10cm away from walls or other objects during operation.
  • Always use the handle when opening the frying basket drawer.
• Do not replace the empty frying basket drawer (without the frying basket) into the Air Fryer body. Check to ensure the frying basket is locked in position in the drawer.
• Never move a hot Air Fryer or an Air Fryer containing hot food. Allow to cool before moving.
• The provided short power-supply cord should be used to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord is not recommended for use with this product. Always plug directly into a wall outlet.

WARNING: After air frying, make sure to place the frying basket drawer on a flat, heat-resistant surface before pressing the basket release button.

Under- or over-filling the frying basket may damage the Air Fryer and could result in serious personal injury.

CAUTION: To prevent plasticizes (solvent) from damaging the finish of the countertop or tabletop, place non-plastic heat resistant coasters or place mats between the appliance and the countertop or tabletop. Failure to do so may damage your countertop.

CAUTION: If the electrical circuit is overloaded with other appliances, your appliance may not operate properly. It should be operated on a separate electrical circuit from other appliances.

BEFORE FIRST USE

1. Your Air Fryer is shipped with the frying basket locked into the drawer, inside the Air Fryer body. Firmly grasp the frying basket handle to open the frying basket drawer; then remove the drawer from the machine and place it on a flat, clean work area.
2. Remove all packing material and labels from the inside and outside of the Air Fryer. Check that there is no packaging underneath and around the frying basket and drawer.
3. Wash the frying basket and drawer in hot, soapy water.
4. Do not immerse the Air Fryer body in water. Wipe the Air Fryer body with a damp cloth. Dry all parts thoroughly.
5. Replace the clean frying basket into the frying basket drawer.

OPERATION

WARNING: This appliance should not be used to boil water.

Notes:

During first use, the Air Fryer may emit a slight odour and/or smoke. This is normal.

Control Dials

Temperature Control Dial:

• Select the cooking temperature from 140^ C to 200^ C. Temperature can be adjusted at any time.
• The heat indicator will illuminate green once the set temperature has been reached.

Note: The heat indicator light and heating element cycle on and off to maintain the selected temperature.

Time Control Dial:

• Once the timer has been set (up to 30mins), the power indicator will turn red to show the air fryer is powered on.
• To ensure even cooking and browning, halfway through the cooking time, open the frying basket drawer. Check, turn, or vigorously shake the foods in the frying basket.

Important: When you remove the drawer from the Air Fryer body, the Air Fryer and power indicator will turn off. The timer will continue to count down when the drawer is opened.

• Heating will resume once the drawer is replaced.
• The Air Fryer will ‘Beep’ when the set time has reached “0”. The Air Fryer will turn off automatically. Both the power and heat indicators will turn off.

Important: When you are finished using the Air Fryer, turn the temperature control dial to "MIN" and the timer control dial to "0". Unplug the Air Fryer when not in use.

Using the Air Fryer

1. Place the Air Fryer on a flat, heat-resistant work area, close to an electrical outlet.
2. Plug the cord into the electrical outlet.
3. Firmly grasp the frying basket handle to open the frying basket drawer, then remove the drawer and place on a flat, clean surface.
4. Place food into the frying basket. Do not overfill the basket with food. To ensure proper cooking and circulation, never fill any frying basket more than 1/2 full.
5. Insert the frying basket drawer into the front of the Air Fryer. Always ensure the frying basket drawer is fully closed.
6. Select the desired temperature (140°C - 200°C).
7. Select the desired cooking time. The power indicator will illuminate, and the Air Fryer will begin heating.

Note: Add an additional 5 minutes to preheat if the Air Fryer is cold.

Important: The Air Fryer will not heat if the cooking time has not been set.

Warning: Air Fryer will not begin cooking, until frying basket drawer is fully closed.

1. The heat indicator will turn on when set temperature is reached.

Note:

During operation, the heat indicator will cycle on and off as the cooking temperature is maintained.

1. To assure even cooking/browning, open the basket drawer halfway through the cooking process and check. Remove the frying basket drawer to turn or shake foods. Once cooking complete, return the frying basket drawer. Adjust the temperature if needed. The timer will continue to count down when the drawer is opened, but the Air Fryer will stop heating until the drawer is replaced.

Caution: Ensure the frying basket is in the locked position when shaking foods. To avoid damage to persons or personal property, do not press the basket release button while shaking the frying basket.

WARNING: Extreme caution must be used when handling the hot frying basket and drawer. Avoid escaping steam from the frying basket and the food.

Caution: Always use oven mitts when handling the hot air fryer basket.

Caution: Hot oil can collect at the base of the drawer. To avoid risk of burns or personal injury or to avoid oil from contaminating air fried foods, always unlock and remove the frying basket from the drawer before emptying. Never turn the drawer upside down with the frying basket attached.

1. The Air Fryer can be turned off at any time by turning the timer dial to "0".

2. A beep will sound when the set time has expired. The Air Fryer will automatically turn off. Both the indicators will turn off.

3. Shake the frying basket drawer vigorously and check food for browning and doneness. If additional air frying is needed, adjust temperature (if necessary) and set timer for 5-minute increments until fully cooked.

4. Allow cooked food to rest for 5-10 seconds before removing basket drawer from Air Fryer or food from frying basket.

5. When cooking is finished, remove the drawer from the air fryer and place on a flat, heat resistant surface. Then remove the frying basket from the drawer.

6. Remove food and promptly return the frying basket to the drawer and lock into place. Continue with subsequent batches, if any.

Note: When the next batch of food is ready, the Air Fryer will quickly re-heat.

1. When all cooking is completed, turn both the temperature control dial and the timer dial to "MIN" and 0. "Both indicators will turn off."

2. Unplug the Air Fryer when not in use.

Tips:

• Olive oil spray or vegetable oil works well for air frying.
• It is recommended to lower the recipe baking temperature by 10^ C and reduce the cooking time by 30% to 50% depending on the food and amount.
• Do not overfill the frying basket with food. Never fill any frying basket more than 1/2 full.

• For best results, some foods need to be shaken vigorously or turned over half-way through cooking.

• To avoid excess smoke, when cooking naturally high fat foods, such as chicken wings or sausages, it may be necessary to empty fat from the frying basket drawer between batches.
  • Always pat food dry before cooking to encourage browning and avoid excess smoke.

• Air fry small batches of freshly breaded foods. Press breading onto food to help it adhere. Arrange in frying basket so that food is not touching to allow air flow on all surfaces.
• The Air Fryer can be used to reheat food. Set the temperature to 140^ C for up to 10 minutes.

Cooking Guide

WARNING: Always use a meat thermometer to ensure that meat, poultry and fish are cooked thoroughly before eating.

The following chart is intended as a guide only. The quantity of food air fried at one time, the thickness or density of the food and whether the food is fresh, thawed or frozen may alter the total cooking time necessary.

1. To assure even cooking/browning, open the frying basket drawer halfway through the cooking. Check, turn or vigorously shake foods in the frying basket. This chart lists average total air frying time, the time at which some action is required and what action is to be taken for best results.
2. Remember, frying smaller batches will result in shorter cooking times and higher food quality. Adjust air frying temperatures and times as necessary to suit your taste.

Note: Unless food is pre-packaged and pre-oiled, for browned and crispy results, all foods should be lightly oiled before air frying.

• Oil may be sprayed or brushed onto foods.
• Spray oils work well as oil is evenly distributed and smaller quantities of oil are needed.
• To ensure crispy results, make sure foods is dried before adding oil.
• Cut pieces smaller to create more surface area for crispier results.
• Add an additional 5 minutes to the AIR FRY TIME to allow the Air Fryer to preheat.

Cooking Chart

The table below will help you select the correct temperature and time for best results. As you become more familiar with the air fryer cooking process, you may adjust these settings to suit your own personal tastes.

Food Item	Min-Max	Time	Temperature	Comments
Thin Frozen Fries	1 1/4-3 cups	15-16 mins	200°C
Thick Frozen Fries	1 1/4-3 cups	15-20 mins	200°C
Homemade Fries	1 1/4-3 1/4cups	10-16 mins	200°C	Add 1/2 tbsp. oil
Homemade Potato Wedges	1 1/4-3 1/4cups	18-22mins	182°C	Add 1/2 tbsp. oil
Homemade Potato Cubes	1 1/4-3 cups	12-18mins	182°C	Add 1/2 tbsp. oil
Hash Browns	1 cup	15-18mins	182°C
Potato Gratin	2 cups	15-18mins	200°C
Steak	1/4-1.1lb	8-12 mins	182°C
Pork Chops	1/4-1.1lb	10-14mins	182°C
Hamburger	1/4-1.1lb	7-14 mins	182°C
Sausage Roll	1/4-1.1lb	13-15mins	200°C
Chicken Drumsticks	1/4-1.1lb	18-22 mins	182°C
Chicken Breast	1/4-1.1lb	10-15mins	182°C
Spring Rolls	1/4-3/4 lb	15-20mins	200°C	Use oven-ready
Frozen Chicken Nuggets	1/4-1.1lb	10-15mins	200°C	Use oven-ready
Frozen Fish Sticks	1/4-1.1lb	6-10 mins	200°C	Use oven-ready
Mozzarella Sticks	1/4-1.1lb	8-10 mins	182°C	Use oven-ready
Stuffed Vegetables	1/4-1.1lb	10 mins	160°C
Cake	1 1/4 cups	20-25 mins	160°C	Use baking tin
Quiche	1 1/2 cups	20-22 mins	182°C	Use baking tin/ oven dish
Muffins	1 1/4 cups	15-18 mins	200°C	Using baking tin
Sweet Snacks	1 1/2 cups	20mins	160°C	Use baking tin/ oven dish
Frozen Onion Rings	1lb	15 mins	200°C

Note:

These settings are intended to be guidelines, because ingredients differ in origin, size, shape and brand, it cannot guarantee the best settings for your ingredients.

Tips:

• Set the timer to half the time needed for the recipe and the timer will alert you when it's time to flip your food.
• Add 3 minutes to cooking time when starting with a cold appliance.

Internal Temperature Meat Chart

This chart should be used to check the internal temperature of cooked meats.

Food	Type	Internal Temperature
Beef & Veal	Ground	70°C
	Steaks, Roasts: Medium	70°C
	Steaks, Roasts: Rare	63°C
	Breasts	75°C
Chicken & Turkey	Ground, stuffed	75°C
	Whole bird, legs, thighs, wings	75°C
Fish & Shellfish	Any type	63°C
	Ground	70°C
Lamb	Steaks, Roasts: Medium	70°C
	Steaks, Roasts: Rare	63°C
Pork	Chops, ground, ribs, roasts	70°C
	Fully cooked ham	60°C

CLEANING & CARE

Cleaning

• Clean the air fryer after each use.
• The fry basket and other accessories are made of durable stainless steel and are dishwasher safe.
• Never use abrasive cleaning materials or utensils on these surfaces.
• Caked-on food should be soaked for easy removal in warm, soapy water.

Remove the power cord from the outlet and be certain the appliance is thoroughly cooled before cleaning.

1. Wipe the outside of the appliance with a warm, moist cloth and mild detergent.
2. To clean glass, open the door of the Unit.
3. Clean the inside of the appliance with hot water, a mild detergent and a non-abrasive sponge.
4. If necessary, remove unwanted food residue from the upper screen with a cleaning brush.

Storage

1. Unplug the appliance and let it cool thoroughly.
2. Make sure all components are clean and dry.
3. Place the appliance in the clean, dry place.

Maintenance

This appliance requires little maintenance. It contains no user-serviceable parts. Any servicing requiring disassembly other than cleaning must be performed by a qualified appliance repair technician.

Disposal

This marking indicates that this appliance should not be disposed with other household wastes. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.

NOTES

The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), this is a stylistic or background line, not a placeholder underscore. Therefore, the OCR result must ignore it and output nothing or only meaningful text. The provided OCR content is "____", which consists of four underscores. This is an incorrect interpretation of the line as a fill-in-the-blank placeholder, violating the rule that stylistic lines must be ignored. The OCR has hallucinated underscores where none should exist based on the GT's visual context. Hence, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
[EMPTY]
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, continuous horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The OCR content provided is "", which consists of no characters. Since the OCR output correctly ignores the background/stylistic line and produces no actual text, it complies with the “Stylistic/Background Lines (Ignore)” rule. Therefore, the OCR result is consistent with the Ground Truth.
[Non-Text]
[Non-Text]
[EMPTY]
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, continuous horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a fill-in-the-blank placeholder. Since the OCR output incorrectly rendered a stylistic line as underscores (which should be ignored), this violates the rule. Therefore, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, continuous horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a fill-in-the-blank placeholder. Therefore, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, continuous horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a fill-in-the-blank placeholder. Therefore, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, continuous horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a fill-in-the-blank placeholder. Therefore, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, continuous horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a fill-in-the-blank placeholder. Therefore, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, continuous horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a fill-in-the-blank placeholder. Therefore, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), this is a stylistic or background line, not a placeholder underscore. Therefore, the OCR result must ignore it and output nothing or only meaningful text. The provided OCR content is "____", which consists of four underscores. This is an incorrect interpretation of the line as a placeholder, violating the rule that stylistic lines must be ignored. The OCR has hallucinated placeholder underscores where none exist in the GT, violating the rule to ignore such lines. Hence, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, solid horizontal line, which is a stylistic or background element (like a ruled paper line or separator), not a placeholder for text. According to Rule 2, such stylistic/background lines must be ignored by the OCR result. The OCR content provided is "", which consists of no characters. This correctly represents the absence of any textual content in the GT and correctly matches the visual line as a stylistic element. Therefore, the OCR output should not contain any underscores or line representations. Outputting underscores for a stylistic line violates the rule and constitutes an error.
[Non-Text]
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), this is a stylistic or background line, not a placeholder underscore. Therefore, the OCR result must ignore it and output nothing or only meaningful text. The provided OCR content is "____", which consists of four underscores. This is an incorrect interpretation of the line as a placeholder, violating the rule that stylistic lines must be ignored. The OCR has hallucinated underscores where none should exist based on the GT's visual context. Hence, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, continuous horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a fill-in-the-blank placeholder. Therefore, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
[Non-Text]
The Ground Truth image displays a single, solid horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a placeholder fill-in-the-blank area. Since the OCR output incorrectly rendered a stylistic line as underscores (which should be ignored), this violates the rule that stylistic lines must be ignored. Therefore, the OCR result is inconsistent with the Ground Truth.
[Non-Text]
(No text)

广力云智慧零售收银系统

Need more information?

We hope that this user guide has given you the assistance needed for a simple set-up.

For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.kogan.com

kogan.com
