DED8724-46C - Lawn mower DEDRA - Free user manual and instructions
Find the device manual for free DED8724-46C DEDRA in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Lawn Mower |
| Brand | DEDRA |
| Model | DED8724-46C |
| Cutting Width | 46 cm |
| Cutting Height Adjustment | Central lever, 5 positions (25-75 mm) |
| Grass Bag Capacity | 50 liters |
| Engine Type | 4-stroke petrol engine |
| Displacement | 139 cc |
| Power | 2.5 kW (3.4 HP) |
| Starting System | Recoil start |
| Drive Type | Push (manual) |
| Wheels | 200 mm front, 250 mm rear |
| Weight | 28 kg |
| Dimensions (L x W x H) | 1400 x 460 x 1050 mm |
| Sound Level (LWA) | 96 dB(A) |
| Vibration Level | 8.5 m/s² |
| Safety Features | Blade brake, engine stop handle |
| Collection | Rear grass bag with indicator |
| Mulching Capability | Yes (mulching plug included) |
| Material | Steel deck |
| Warranty | 2 years |
Frequently Asked Questions - DED8724-46C DEDRA
How to start the lawn mower?
Ensure the spark plug is connected and fuel is fresh. Set the engine stop handle to the start position, then pull the recoil starter firmly.
How to adjust cutting height?
Use the central cutting height lever. Move it to one of the 5 positions to set the desired height between 25 and 75 mm.
How often should I change the oil?
Change the engine oil after the first 5 hours of use, then every 25 hours or once per season. Use SAE 30 or 10W-30 oil.
What type of fuel should I use?
Use unleaded petrol with an octane rating of 95 or higher. Do not use ethanol blends above 10%.
How to clean the mower deck?
After each use, tilt the mower (with spark plug disconnected) and scrape off grass clippings. Use a hose if equipped with a wash port.
How to store the mower for winter?
Drain the fuel tank and run the engine until dry. Change the oil, clean the mower, and store in a dry place. Disconnect the spark plug.
What to do if the mower vibrates excessively?
Check the blade for damage or imbalance. Tighten the blade bolt. If vibration persists, inspect the engine mounts and shaft.
How to replace the blade?
Disconnect the spark plug. Tilt the mower and remove the blade bolt with a wrench. Install a new blade with the cutting edge facing the rotation direction.
Is the grass bag easy to empty?
Yes, the grass bag is designed with a rigid top and a rear handle. Simply lift it off the mower and empty from the top.
Where can I find spare parts?
Spare parts such as blades, air filters, and spark plugs are available at DEDRA authorized dealers or online stores. Use the model number DED8724-46C.
