Product Type	Cutting Machine (Band Saw)
Brand	Hilti
Model	X-SL B3
Dimensions (L x W x H)	620 x 400 x 320 mm
Weight	16.5 kg
Power Supply	230 V, 50/60 Hz
Power Consumption	1500 W
Blade Speed	30 - 80 m/min (variable)
Max Cutting Capacity (Round)	120 mm diameter
Max Cutting Capacity (Rectangular)	120 x 150 mm
Blade Length	2240 mm
Blade Width	13 mm
Noise Level	76 dB(A)
Vibration Level	< 2.5 m/s²
Safety Features	Emergency stop, blade guard, overload protection
Maintenance	Regular cleaning and blade inspection
Spare Parts Available	Replacement blades, guides, and drive belts
Intended Use	Cutting metal, plastic, and wood materials
Operating Environment	Indoor dry workshop

Frequently Asked Questions - X-SL B3 HILTI

How do I adjust the blade tension on my Hilti X-SL B3 cutting machine?

Turn the blade tension knob (located on the side of the machine) clockwise to increase tension and counterclockwise to decrease. Refer to the markings for optimal tension.

What type of coolant should I use for metal cutting?

Use a water-soluble cutting fluid or general-purpose coolant suitable for ferrous and non-ferrous metals. Never use flammable liquids.

How often should I replace the blade?

Replace the blade when you notice decreased cutting performance, excessive vibration, or visible damage. Typical lifespan is 20-40 hours of cutting depending on material.

Can I cut aluminum with the X-SL B3?

Yes, the machine can cut aluminum. Use a fine-tooth blade and reduce the cutting speed to prevent chip welding.

What is the maximum workpiece size the machine can handle?

The maximum cutting capacity is 120 mm diameter for round stock and 120 x 150 mm for rectangular sections. Larger workpieces cannot be accommodated safely.

How do I clean the machine after use?

Unplug the machine and use a brush or compressed air to remove chips and dust. Wipe surfaces with a dry cloth. Do not use water or solvents.

What should I do if the machine trips the circuit breaker?

First, reset the breaker. If it trips again, check for a short circuit in the power cord or motor. Ensure the machine is not overloaded. If the problem persists, contact Hilti service.

Is it normal for the blade to leave marks on the cut surface?

Slight blade marks are normal, especially with new blades. To minimize marks, use a finer-tooth blade and reduce feed pressure. Lubricating the cut also helps.

How do I replace the drive belt?

Disconnect power, remove the side cover, and loosen the motor mounting bolts. Slide the new belt onto the pulleys and adjust tension. Tighten bolts and replace cover. Refer to the manual for belt type.

Can I use a blade other than the original Hilti blade?

Yes, you can use compatible blades with the same dimensions (13 mm width, 2240 mm length) and appropriate tooth pitch for your material. Ensure the blade is designed for metal cutting.

USER MANUAL X-SL B3 HILTI

Technical illustration of a mechanical assembly with ladder and motor components, showing a close-up view of the component (no text or symbols present)
