RCH-220 - Vacuum Cleaner WINIA - Free user manual and instructions

Product Type	Vacuum Cleaner
Brand	Winia
Model	RCH-220
Technology	Ultra Cyclonic
Type	Canister vacuum cleaner
Power Connection	10A earthed socket
Cord Rewind	Yes, with button
Filtration	Washable foam filter
Floor Brush	Dual-position for carpet and hard floors
Accessories Included	Narrow nozzle, small brush, extension tube(s)
Tube Type	Plastic, metal, or telescopic (2 pieces)
Wind-Force Adjuster	Yes, on hose
Handle	Yes, on hose
Hose	Flexible hose with connector
Safety Warnings	Do not vacuum liquids, hot ash, or flammable materials
Maintenance	Clean dust cup and foam filter regularly; dry naturally
Use	For household use only
Suitable For	Carpets and hard floors
Not Suitable For	Liquids, hot ashes, sharp objects, strings
Power Switch	On/Off button on body
Dustbin	Removable dust cup

Frequently Asked Questions - RCH-220 WINIA

How do I assemble the vacuum cleaner?

First, insert the extension tube(s) into the handle. Then attach the floor brush or desired accessory to the tube. Finally, connect the flexible hose to the air intake duct by pressing the button on the hose end and pushing firmly. Ensure all parts click into place.

How do I use the wind-force adjuster?

The wind-force adjuster is located on the hose. Slide it to adjust suction power: open for maximum suction, close for reduced suction on delicate surfaces.

How do I clean the dustbin?

Lift the foam cover and remove the dust cup. Empty the dust into a trash bag. Clean off any remaining dust inside the cup. You can also rinse the dust cup with water, but make sure it is completely dry before reinserting.

How do I clean the foam filter?

Remove the foam filter from the dust cup when it appears dirty. Rinse it under running water. Do not use detergents or solvents. Let it dry naturally in a well-ventilated area before placing it back. Do not use the vacuum without the filter.

Can I vacuum liquids with this vacuum?

No, do not use this vacuum cleaner to vacuum liquids. It is designed for dry vacuuming only. Vacuuming liquids can damage the motor and create an electrical hazard.

What should I do if the power cord is damaged?

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or a similarly qualified person to avoid a hazard. Do not attempt to repair it yourself. Contact an authorized service center.

Can children use this vacuum cleaner?

Children aged 8 years and above can use the vacuum cleaner under supervision. Persons with reduced capabilities should also be supervised. Children must not play with the appliance. Cleaning and maintenance should not be performed by children without supervision.

How do I rewind the power cord?

Hold the plug with one hand and press the cable rewind button on the vacuum with the other hand. Guide the cord with your hand to prevent whipping and damage. Do not rewind beyond the white mark on the cord.

What accessories come with the vacuum?

The vacuum includes a dual-position carpet/floor brush, a narrow nozzle for radiators and corners, a small brush for delicate surfaces like bookshelves, and extension tube(s) (plastic, metal, or telescopic). Additional accessories may be purchased separately.

How do I switch between carpet and floor mode?

The floor brush has two positions. For hard floors, push the switch to extend the bristles (position 1). For carpets, retract the bristles (position 2) to allow better contact with the carpet fibers.

USER MANUAL RCH-220 WINIA

DESCRIPTIONIMPORTANT

A. Handle

F. Hose connector

B. Hose

G. Dustbin

C. Wind-force adjuster

H. Cable rewind button

D. Tube

1. Power switch

E. Floor bruch

D. The products could come with different tube which is not same as this IFU illustrates, the tube could be 2pcs of plastic or metal or telescopic.

1. Read this instruction booklet carefully.

2. Before using the appliance, check that the mains power voltage corresponds to the voltage shown on the rating plate.

3. The appliance should be connected to a correctly-earthed 10A power socket.

4. Always remove the plug from the power socket when the appliance is not in use and before cleaning or maintenance.

5. Always remove the plug from the power socket before opening the appliance.

6. Never use methylated spirits or other solvents to clean the appliance.

7. Do not use the appliance to vacuum liquids.

8. Never leave the appliance unattended when it is switched on. Keep the appliance out of the reach of children or the infirm.

9. This appliance is only for household. Use as described in this instruction booklet.

10. Do not switch the appliance on if it appears to be faulty in any way.

11. For repairs or accessories, contact your dealer or an authorized Service Center.

12. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

13. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

14. Keep the appliance and its cord out of reach of children less than 8 years.

15. Do not remove the plug from the socket by pulling the cable or the appliance itself.

16. Do not use the appliance to vacuum lighted matches, cigarette ends and hot ash.

17. Do not use the appliance on wet surfaces.

18. Do not obstruct the air intake or outlet vent.

19. Do not use the appliance to vacuum needles, drawing pins or strings.

Do not remove the plug from by pulling the cable the or appliance itself.	Do not run the appliance over the power cable.	Do not use the appliance to vacuum lighted matches, cigarette ends or hot ash.
Do not use the appliance on wet surfaces.	Do not obstruct the air intake or outlet vent.	Do not use the appliance to to vacuum needles, drawing-pins or string.

ASSEMBLING THE VACUUM CLEANER

Removing the flexible tube:

Remove the plug from the pover socket. Torefease the flexible Tube, press the button on the end of the tube and pull the tube Firmly from the air intake duct.

Fitting the extension tubes and accessories

Fitting the extension tubeThe handle.	Fitting the extension tubes.	Fitting the accessories tothe extension tube.

INSTRUCTION FOR USE

1. Before using the appliance. unwind length of cable and insert the plug into the power socket.

Do not extend the cable beyond the WHITE mark.

To rewind the power cable, press the rewind button with one hand, and guide the other hand to ensure that it does not whip causing damage.

1. Press the ON/OFF button to switch the appliance on.

USING THE CLEANING ACCESSORIES

Dual-position carpet/floor brush.

Pos.1: bristles extended. for hard floors Pos.2: bristles retracted for carpets

Narrow nozzle.

For cleaning radialors; corners, edges, drawers etc.

Small brush

For cleaning eurlains, shelves, books, inlaid furniture, lamps and other ceticate objects.

The product could come with different tube and brush

MAINTENANCE

Clean the dust

1. Lift the form cover and take out the dust cup.
2. Take out the foam form dust cup.
3. Clean off the dust inside the dust cup.

Clean the foam

1. Take out the foam when it's setting dirtys.
2. Clean it in the water .dry it naturally before next use.

Environmental Protection

Waste electrical production should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
