Product Type	Rechargeable amplified speaker
Brand	Karma
Model	HPS 44R
Power Supply	5V DC, 1A via mini USB
Battery Charging Time	Approximately 2 hours
Input Sources	Bluetooth, USB (FAT32, up to 32GB), micro SD (FAT32, up to 16GB), AUX (3.5mm), microphone
Bluetooth Version	Not specified (typical: 4.2 or 5.0)
Bluetooth Range	Approximately 10 meters (typical)
TWS Function	Yes (pair two HPS 44 speakers for stereo)
Microphone	Included, 3.5mm connector
Audio Playback	MP3, WAV
LED Lighting	Woofer LED effect (color-changing)
Indoor Use Only	Yes
Warranty	2 years (EU), 1 year with invoice
Operating Temperature	Below 45°C
Dimensions (Approx.)	Not specified (typical portable speaker size)
Weight (Approx.)	Not specified (typical: 1-2 kg)
Color	Black (common)
Compliance	CE, WEEE
Certification	EU Declaration of Conformity available at www.karmaitaliana.it

Frequently Asked Questions - HPS 44R Karma

How do I pair the speaker via Bluetooth?

Turn on the speaker and press the MODE button until Bluetooth mode is selected. A voice will say 'Bluetooth'. On your smartphone, search for 'HPS 44' and connect. The LED near the buttons will fast flash during pairing, then slow flash when connected.

How do I use the TWS function to connect two speakers?

Turn on both HPS 44 speakers and set them to Bluetooth mode. On the first speaker, press and hold the MODE button for 10 seconds until you hear a sound signal. Then search for 'HPS 44' on your smartphone and connect. Audio will play on both speakers.

How do I charge the speaker?

Connect the included mini USB cable to the DCIN port and plug it into a standard 5V 1A USB charger. Charging takes about 2 hours.

What file systems are supported for USB and micro SD?

USB must be formatted as FAT32 with a maximum capacity of 32GB. The micro SD card must also be FAT32 with a maximum capacity of 16GB.

Can I use the microphone while playing music?

Yes, the microphone allows you to amplify your voice or sing along to music played via USB, micro SD, or Bluetooth. Connect the microphone to the MIC IN socket.

How do I control volume and track selection?

Press the BACKWARD button for previous track or hold to decrease volume. Press the FORWARD button for next track or hold to increase volume. The PLAY/PAUSE button starts or pauses playback.

What should I avoid to prevent damage?

Avoid using the speaker in temperatures above 45°C, in humid conditions, or where it may vibrate or be impacted. Do not allow liquids or metal objects inside. Do not disassemble. Use only indoors.

How do I clean the speaker?

Unplug the speaker and wipe with a soft, dry cloth. Do not use harsh chemicals or water. Keep the ports clear of dust.

What is the warranty period?

The warranty covers manufacturing defects for 2 years from purchase date (EU). If purchased with an invoice, the warranty is limited to 1 year. The warranty does not cover damage from misuse or modification.

How do I reset the speaker?

If the speaker is unresponsive, turn it off, wait a few seconds, and turn it back on. For Bluetooth issues, unpair and re-pair. If problems persist, contact support.

USER MANUAL HPS 44R Karma

Rechargeable amplified speaker

KARMA®

Thank you for choosing KARMA!

The KARMA product you have purchased is the result of careful planning by specialized engineers. High quality materials were used for its construction, to ensure its functioning over time. The product is manufactured in compliance with strict regulations imposed by the European Union, a guarantee of reliability and safety. Please read this manual carefully before starting to use the fixture in order to exploit its full potential. We thank you again for your trust in our brand.

Cautions and warnings

• Avoid using the unit:
• in places with temperatures above 45^ C
• in places subject to vibrations and / or possible impacts
• in places with too much humidity
• Do not allow flammable liquid, water or metal objects to enter the product
• Do not disassemble and/or make changes to the product
• All repairs must always be carried out by authorized persons.
  • This product is for indoor use only
• Do not turn the product on and off at short intervals, it may reduce the life of the device
• Periodically check the condition of the power cord

Shipments and complaints

The goods are always transported at the risk of the consignee. Any damage must be immediately indicated on the carrier's delivery bill. All claims for damaged packagings / items must be notified within 7 days from the goods' reception.

Warranty conditions

The product is covered by warranty according to current national and European regulations.

For detailed warranty conditions and RMA requests please refer to our website: www.karmaitaliana.it

• The warranty covers manufacturing defects and faults occurred in the first 2 years from the date of purchase. In case of purchase with invoice, the warranty is limited to 1 year
• Damages caused by negligence or wrong use of the device are not covered by warranty.
• The warranty is no longer effective if the item is modified or disassembled by not authorized people.
• This warranty doesn't necessarily envisage the product's replacement.
• External components, batteries, knobs, switches and any removable or subject to wear and tear parts are excluded from warranty.
• Shipment for the return of faulty items is at expense and risk of the owner.
• For all intents and porpuses the warranty is effective only upon exhibition of the invoice or of the purchase receipt.

We also suggest to register your product on our website www.karmaitaliana.it, after signing in to access the private area. In this way you will have the possibility to keep track of the warranty validity and to receive updates on our items.

Produto / Product

Funções Functions

1. PEGA DE TRANSPORTE
2. TECLAS E FICHAS

1. HANDLE
2. CONTROLS and SOCKETS

See on page 6 for more detailed instructions.

1. MULTIFUNCTION PANEL

It manages all the device's functions. See next page for more detailed instructions.

1. WOOFER WITH LED

Thanks to some leds behind the front grid the woofer lights up, changing its colour and creating a nice "party" effect.

1. MICROPHONE

The microphone allows to amplify your voice, but also to sing on a track played via USB/micro SD/bluetooth.

Painel Multifunções Multifunction panel

1. TECLA DE MODO

Press this button to choose the desired mode (bluetooth, MP3). A guide voice in English will indicate the selected mode.

2. BACKWARD/VOLUME -

Press this button to choose the previous track. Press and hold it to reduce volume.

3. PLAY /PAUSE / SCAN BUTTON

Use it to start and/or pause playing.

This device is endowed with the innovative TWS function, allowing to play music from your smartphone contemporarily on 2 speakers via bluetooth. To set this function turn on the two HPS 44, enable the bluetooth mode on both speakers and then press and hold the MODE button for 10 seconds on first device until you here a sound signal. Now the two speakers are connected one with the other. From your smartphone search for the HPS 44 speaker in the bluetooth screen. Once connected, audio will be played by both speakers. Led near buttons show the bluetooth status as follow: fast flash: waiting for pairing slow flash: connected and playing fix led: connected but without audio signal

4. FORWARD/ VOLUME +

Press this button to choose the following track. Hold it pressed to increase volume.

Controlos e fichas Controls and sockets

USB TFCARD DCIN AUX ON OFF

1. FICHA USB

Use it to insert a USB key to play MP3 /WAV songs. Please make sure that it is in FAT 32 format with maximum capacity 32GB. To connect external sources, such as (smartphones, computers, tablets etc...), use the supplied cable and connect the 3,5mm plug to your device and the mini USB to the speaker (HPS 44).

2. TF CARD SOCKET

Like the USB stick, the micro SD can contain songs to play. Make sure that it is in FAT 32 format with maximum capacity 16GB.

3. 5V POWER SUPPLY

Plug in the included mini USB power cable, then connect it to an ordinary 5V - 1A USB socket. The fixture will be recharged in about 2 hours.

4. MIC IN

Connect the supplied microphone, endowed with 3.5mm connector, to this socket. The AUX socket (jack 3.5mm) is intended only for use of the included microphone.

5. ON / OFF BUTTON

Use it to turn on the product

CARACTERÍSTICAS

This symbol alerts you to the presence of important operating and maintenance instructions, in the manual or in the documentation accompanying the product.

This symbol indicates a risk of electric shock in case of wrong use or alteration of the product.

The CE mark indicates that this product complies with the applicable European directives and their related standards. Compliance documentation in complete form is available at the company Karma Italiana Srl.

To prevent possible hearing damage, do not listen at high volume levels for long periods.

Directive 2012/19/UE regarding electric and electronic equipment waste (WEEE).

The symbol of the crossed-out dustbin indicates that the product at the end of its life must be collected separately from other waste. The user must, therefore, confer the fixture complete with all the essential components to an authorized disposal center for collection of electronic and electrical waste, or return it the dealer when buying new equipment of equivalent type, at a rate of one to one, or one to zero if dimension is less than 25cm. Appropriate separate collection to send the decommissioned equipment to recycling, treatment and environmentally compatible disposal helps to prevent negative impact on the environment and human health and promotes recycling of the materials making up the product. In Italy illegal dumping of the product by the user entails the application of administrative sanctions pursuant to Legislative Decree n. 49 (14/03/2014).

The product's remote control contains a battery, which according to the European Directive 2013/56/EU, cannot be disposed of with normal household waste. Please inquire about the local regulations regarding the separate collection of batteries: a correct disposal allows to avoid negative consequences for the environment and health.

CE

Hereby, KARMA ITALIANA SRL declares that the radio equipment type speaker with bluetooth TIGER series is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.karmaitaliana.it.

Karma Italiana Srl
