| Product Type | Gas Boiler (Conventional) |
| Brand | Baxi |
| Model | Solo 3 PFL 80 |
| Fuel Type | Natural Gas (G20) |
| Heat Output (kW) | 24.0 kW (max) |
| Dimensions (H x W x D) | 780 x 450 x 330 mm |
| Weight | 35 kg (approx.) |
| Electrical Supply | 230 V / 50 Hz |
| Power Consumption | 150 W (electrical) |
| Mounting Type | Wall-hung |
| Flue Type | Room-sealed (balanced flue) |
| Water Connection | 22 mm flow and return |
| Gas Connection | 15 mm (R 1/2") |
| Central Heating System | Pressurised sealed system |
| Control Interface | Manual thermostat and timer |
| Safety Features | Overheat protection, flame failure, frost protection |
| Efficiency Class | B (approx. 85% seasonal efficiency) |
| Noise Level | < 60 dB(A) |
| Maintenance Interval | Annual service recommended |
| Spare Parts Availability | Standard Baxi parts widely available |
| Warranty | 2 years (typical) |
Frequently Asked Questions - Solo 3 PFL 80 Baxi
What is the Baxi Solo 3 PFL 80 boiler?
The Baxi Solo 3 PFL 80 is a conventional gas boiler designed for central heating systems. It is wall-hung and provides hot water via a separate cylinder.
What are the dimensions of the Baxi Solo 3 PFL 80?
The boiler dimensions are approximately 780 mm high, 450 mm wide, and 330 mm deep. It requires clearance for servicing.
How do I reset the Baxi Solo 3 PFL 80 after a fault?
To reset, press the reset button on the control panel and hold for 3 seconds. Ensure the system has cooled down and the fault is resolved.
What is the recommended maintenance schedule?
An annual service by a Gas Safe registered engineer is recommended. This includes cleaning, checking safety devices, and inspecting flue and seals.
How do I adjust the water pressure?
Check the pressure gauge; it should be between 1 and 2 bar. To increase, open the filling loop valve. Consult the manual for details.
Why is my boiler losing pressure?
Common causes include leaks in the system, faulty pressure relief valve, or an expansion vessel issue. Call a professional to inspect.
Can I use the boiler with a thermostat?
Yes, the Solo 3 PFL 80 is compatible with a wired room thermostat. Connect to the designated terminals as per the wiring diagram.
What type of flue does the Solo 3 PFL 80 use?
It uses a room-sealed balanced flue, which draws air from outside and exhausts products safely. Standard horizontal or vertical kits are available.
How do I bleed radiators with this boiler?
Turn off the boiler, wait for it to cool, then use a radiator key to open the bleed valve slightly until water appears. Repressurise system.
Where can I find spare parts for the Baxi Solo 3 PFL 80?
Spare parts are available through Baxi approved distributors or online heating part shops. Use the model number for correct identification.
