Product Type Freestanding Refrigerator-Freezer
Brand Nevir
Model NVR-C588600-IFE
Total Gross Capacity 588 L
Refrigerator Capacity Approx. 400 L
Freezer Capacity Approx. 188 L
Dimensions (H x W x D) 1850 x 600 x 650 mm
Weight 60 kg
Power Supply 220-240 V, 50 Hz
Energy Consumption Approx. 300 kWh/year
Climate Class N-ST (16-38°C)
Noise Level 42 dB(A)
Cooling System Static (Fan-assisted optional)
Defrosting Automatic in refrigerator, manual in freezer
Interior Light LED
Door Reversibility Yes, left/right
Adjustable Thermostat Yes
Shelves Tempered glass, 4 adjustable
Freezer Drawers 3
Door Storage 5 compartments
Cleaning Unplug, clean with mild detergent, dry thoroughly
Safety Features Child safety lock (optional)
Spare Parts Availability Contact Nevir support or authorized dealers

Frequently Asked Questions - NVR-C588600-IFE NEVIR

What is the recommended temperature setting for the refrigerator?
The optimal refrigerator temperature is between 2°C and 6°C. The freezer should be set to -18°C or lower.
How do I defrost the freezer?
Unplug the appliance, remove food and drawers, and leave the door open to allow ice to melt. Do not use sharp objects to remove ice.
Why is my fridge making unusual noises?
Normal sounds include clicking (compressor startup), gurgling (refrigerant flow), and humming (fan). If sounds are loud, check if the fridge is level.
How much space should I leave around the fridge for ventilation?
Leave at least 10 cm at the back, 5 cm on each side, and 15 cm above for proper airflow.
Can I reverse the door opening direction?
Yes, the door is reversible. Follow the instructions in the manual to change the hinges.
How do I clean the condenser coils?
Unplug the fridge, access the rear or bottom coils, and gently vacuum or brush to remove dust every 6-12 months.
What temperature should the freezer be for long-term storage?
Keep the freezer at -18°C or colder. Use a freezer thermometer to verify.
How can I reduce energy consumption?
Keep the fridge away from heat sources, avoid overloading, and ensure door seals are clean and tight.
What should I do if the fridge stops cooling?
Check power supply, thermostat setting, and door closure. If still not cooling, contact a technician.
Are spare parts available for this model?
Yes, contact Nevir customer service or authorized parts distributors with your model number.

User questions about NVR-C588600-IFE NEVIR

0 question about this device. Answer the ones you know or ask your own.

Ask a new question about this device

The email remains private: it is only used to notify you if someone responds to your question.

No questions yet. Be the first to ask one.

Download the instructions for your Refrigerator in PDF format for free! Find your manual NVR-C588600-IFE - NEVIR and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. NVR-C588600-IFE by NEVIR.

USER MANUAL NVR-C588600-IFE NEVIR

natural_image Simple line drawing of a two-panel refrigerator with no text or symbols

CONTENTS

1 Safety warnings

2 Proper use of the refrigerators

3 Structure and functions

4 Maintenance and care of the appliance

Warning:risk of fire / flammable materials

This appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments; bed and breakfast type environments; catering and similar non-retail applications.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.)

Children should be supervised to ensure that they do not play with the appliance.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

The appliance has to be unplugged after use and before carrying out user maintenance on the appliance.

Warning: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

Warning: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

Warning: Do not damage the refrigerant circuit.

Warning: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

Warning: Please abandon the refrigerator according to local regulators for it use flammable blowing gas and refrigerant.

Warning: When positioning the appliance, ensure the supply cord is not trapped or damaged.

Warning: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.

Do not use extension cords or ungrounded (two prong) adapters.

Danger: Risk of child entrapment. Before you throw away your old refrigerator or freezer:

-Take off the doors.

-Leave the shelves in place so that children may not easily climb inside.

The refrigerator must be disconnected from the source of electrical supply before attempting the installation of accessory.

Refrigerant and cyclopentane foaming material used for the appliance are flammable. Therefore, when the appliance is scrapped, it shall be kept away from any fire source and be recovered by a special recovering company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the environment or any other harm.

For EN standard: This appliance can be used by children aged from 8 years and above and persons with reduce physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.

The necessity that, for doors or lids fitted with locks and keys, the keys be kept out of the reach of children and not in the vicinity of the refrigerating appliance, in order to prevent children from being locked inside.

To avoid contamination of food, please respect the following instructions:

- Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance.

- Clean regularly surfaces that can come in contact with food and accessible drainage systems.

- Clean water tanks if they have not been used for 48 h; flush the water system connected to a water supply if water has not been drawn for 5 days. (note 1)

- Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food.

- Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice-cream and making ice cubes. (note 2)

- One-, two- and three-star compartments are not suitable for the freezing of fresh food. (note 3)

- For appliances without a 4-star compartment: this refrigerating appliance is not suitable for freezing foodstuffs. (note 4)

- If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance. Note 1,2,3,4: Please confirm whether it is applicable according to your product compartment type.

For a freestanding appliance: this refrigerating appliance is not intended to be used as a built-in appliance.

Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer, its service agent or similar qualified person. This product contains a light source of energy efficiency class .

1.2 Meaning of safety warning symbols

NEVIR NVR-C588600-IFE - Meaning of safety warning symbols - 1

Prohibition symbol

This is a prohibition symbol.

Any incompliance with instructions marked with this symbol may result in damage to the product or endanger the personal safety of the user

NEVIR NVR-C588600-IFE - Meaning of safety warning symbols - 2

Warning symbol

This is a warning symbol.

It is required to operate in strict observance of instructions marked with this symbol; or otherwise damage to the product or personal injury may be caused

NEVIR NVR-C588600-IFE - Meaning of safety warning symbols - 3

Note symbol

This is a cautioning symbol.

Instructions marked with this symbol require special caution. Insufficient caution may result in slight or moderate injury, or damage to the product

This manual contains lots of important safety information which shall be observed by the users.

Diagram showing hand holding checkmark and pointing at a smiling face, with a checkmark symbol above the hand.

NEVIR NVR-C588600-IFE - Electricity related warnings - 2

natural_image Simple line drawing of a plug with a bulb and cable, no text or symbols present

NEVIR NVR-C588600-IFE - Electricity related warnings - 3

natural_image Simple line drawing of a room with a monitor and equipment, no text or symbols present

NEVIR NVR-C588600-IFE - Electricity related warnings - 4

natural_image Simple line drawing of a refrigerator with a mounted appliance and a 'no' symbol (no text or labels)
  • Do not pull the power cord when pulling the power plug of the refrigerator. Please firmly grasp the plug and pull out it from the socket directly.
  • To ensure safe use, do not damage the power cord or use the power cord when it is damaged or worn

- Please use a dedicated power socket and the power socket shall not be shared with other electrical appliances. The power plug should be firmly contacted with the socket or else fires might be caused.

- Please ensure that the grounding electrode of the power socket is equipped with a reliable grounding line.

- Please turn off the valve of the leaking gas and then open the doors and windows in case of leakage of gas and other flammable gases. Do not unplug the refrigerator and other electrical appliances considering that spark may cause a fire

- Do not use electrical appliances on the top of the appliance, unless they are of the type recommended by the manufacturer.

1.4 Warnings for using

NEVIR NVR-C588600-IFE - Warnings for using - 1

natural_image Simple line drawing of a refrigerator with tools and a crossed-out box, no text or symbols present
  • Do not arbitrarily disassemble or reconstruct the refrigerator, nor damage the refrigerant circuit; maintenance of the appliance must be conducted by a specialist
  • Damaged power cord must be replaced by the manufacturer, its maintenance department or related professionals in order to avoid danger.

NEVIR NVR-C588600-IFE - Warnings for using - 2

natural_image Simple line drawing of a mechanical or electrical component with a starburst and warning symbol (no text or labels)
  • The gaps between refrigerator doors and between doors and refrigerator body are small, be noted not to put your hand in these areas to prevent from squeezing the finger. Please be gentle when close the refrigerator door to avoid falling articles.
  • Do not pick foods or containers with wet hands in the freezing chamber when the refrigerator is running, especially metal containers in order to avoid frostbite.

NEVIR NVR-C588600-IFE - Warnings for using - 3

natural_image Line drawing of a person hanging from an open refrigerator with no text or symbols

- Do not allow any child to get into or climb the refrigerator; otherwise suffocation or falling injury of the child may be caused.

NEVIR NVR-C588600-IFE - Warnings for using - 4

natural_image Simple line drawing of a trash can with a sad face and warning symbols (no text or labels)
  • Do not place heavy objects on the top of the refrigerator considering that objects may fall when close or open the door, and accidental injuries might be caused.
  • Please pull out the plug in case of power failure or cleaning. Do not connect the refrigerator to power supply within five minutes to prevent damages to the compressor due to successive starts.

1.5 Warnings for placement

NEVIR NVR-C588600-IFE - Warnings for placement - 1

natural_image Illustration of a hand holding a notebook with a bottle, eraser, and capsule (no text or symbols)
  • Do not put flammable, explosive, volatile and highly corrosive items in the refrigerator to prevent damages to the product or fire accidents.
  • Do not place flammable items near the refrigerator to avoid fires.

Blank Drugs Natural products

- The refrigerator is intended for household use, such as storage of foods; it shall not be used for other purposes, such as storage of blood, drugs or biological products, etc.

reei ng chamber Beer

- Do not store beer, beverage or other fluid contained in bottles or enclosed containers in the freezing chamber of the refrigerator; or otherwise the bottles or enclosed containers may crack due to freezing to cause damages.

1.6 Warnings for energy

Warning for energy

1) Refrigerating appliances might not operate consistently (possibility of defrosting of contents or temperature becoming too warm in the frozen food compartment) when sited for an extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed.
2) The fact that effervescent drinks should not be stored in food freezer compartments or cabinets or in low-temperature compartments or cabinets, and that some products such as water ices should not be consumed too cold;
3) The need to not exceed the storage time(s) recommended by the food manufacturers for any kind of food and particularly for commercially quick-frozen food in food-freezer and frozen-food storage compartments or cabinets;
4) The precautions necessary to prevent an undue rise in the temperature of the frozen food while defrosting the refrigerating appliance, such as wrapping the frozen food in several layers of newspaper.
5) The fact that a rise in temperature of the frozen food during manual defrosting, maintenance or cleaning could shorten the storage life.

1.7 Warnings for disposal

Refrigerant and cyclopentane foaming material used for the refrigerator are flammable. Therefore, when the refrigerator is scrapped, it shall be kept away from any fire source and be recovered by a special recovering company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the environment or any other harm.

When the refrigerator is scrapped, disassemble the doors, and remove gasket of door and shelves; put the doors and shelves in a proper place, so as to prevent trapping of any child.

NEVIR NVR-C588600-IFE - Warnings for disposal - 1

Correct Disposal of this product

This marking indicates that this product should not be disposed with other household wastes. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.

2 Proper use of refrigerators

2.1 Placement

NEVIR NVR-C588600-IFE - Placement - 1

natural_image Simple line drawing of a person pushing a cardboard box next to an refrigerator (no text or symbols)

- Before use, remove all packing materials, including bottom cushions, foam pads and tapes inside of the refrigerator; tear off the protective film on the doors and the refrigerator body.

NEVIR NVR-C588600-IFE - Placement - 2

natural_image Simple line drawing of a refrigerator with a sad face, sun, and potted plant (no text or symbols)

- Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or watery places to prevent rust or reduction of insulating effect.

- Do not spray or wash the refrigerator; do not put the refrigerator in moist places easy to be splashed with water so as not to affect the electrical insulation properties of the refrigerator.

NEVIR NVR-C588600-IFE - Placement - 3

natural_image Simple line drawing of a smiling refrigerator next to a door with four compartments (no text or symbols)

- The refrigerator is placed in a well-ventilated indoor place; the ground shall be flat, and sturdy (rotate left or right to adjust the wheel for levelling if unstable).

1 cm 1 cm

- The top space of the refrigerator shall be greater than 30cm, and The refrigerator should be placed against a wall with a free distance more than 10cm to facilitate heat dissipation.

Precautions before installation

Before installation or adjusting of accessories, it shall be ensured that the refrigerator is disconnected from power.

Precautions shall be taken to prevent fall of the handle from causing any personal injury.

2.2 Levelling feet

Schematic diagram of the levelling feet

L H

( The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor )

Adjusting procedures:

a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.

2.3 Door Right-Left Change (optional)

List of tools to be provided by the user
NEVIR NVR-C588600-IFE - Door Right-Left Change (optional) - 1Cross screwdriverNEVIR NVR-C588600-IFE - Door Right-Left Change (optional) - 2Putty knifethin-blade screwdriver
NEVIR NVR-C588600-IFE - Door Right-Left Change (optional) - 35/16"socket and ratchetNEVIR NVR-C588600-IFE - Door Right-Left Change (optional) - 4Masking tape
  1. Power off the refrigerator, and remove all objects from the door trays
  2. Dismantle upper hinge cover, upper hinge and hole cap of the other side, remove the refrigerating door

upper hinge cover upper hinge sleeve pipe hole cap

  1. Dismantle the middle hinge, the screws, the screws hole caps and remove the freezer door.

screw middle hinge hole cap screw

  1. Dismantle the bottom hinge, hole caps and screws, Install the bottom hinge shaft and adjust foot on other side of the bottom hinge, then install the hinge on the other side.

shaft shaft hole cap screw screw cap

  1. Dismantle the screw, sleeve pipe and stopper from the refrigerating door and freezer door, Then install them on the other side of the doors in order.

Exchange the position of sleeve pipe and hole cap at the top cover of refrigerating door, and install the upper hinge sleeve on the freezer door to the hole on the other side of axis sleeve.

sleeve pipe stopper stopper screw

  1. Put the freezer door on bottom hinge, install the middle hinge, the screws and the screw hole caps

hole cap screw screw middle hinge

  1. Put the refrigerating door on the middle hinge, install the upper hinge, hinge cover and hole cap.

hole cap hinge cover upper hinge

NEVIR NVR-C588600-IFE - Door Right-Left Change (optional) - 11

(The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor)

2.4 Changing the Light

NEVIR NVR-C588600-IFE - Changing the Light - 1

- Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer, its service agent or similar qualified person.

ight source in this product is replaceable only by ualified engineers.

NEVIR NVR-C588600-IFE - Changing the Light - 21. lease ta e out the plug before removal.NEVIR NVR-C588600-IFE - Changing the Light - 3. emove the lampshade with a screwdriver.
NEVIR NVR-C588600-IFE - Changing the Light - 4. a e down the lamp panel.NEVIR NVR-C588600-IFE - Changing the Light - 5ction terminal.

2.5 Starting to use

NEVIR NVR-C588600-IFE - Starting to use - 1

natural_image Simple line drawing of a smiling refrigerator with a power outlet (no text or symbols)

595.. 545 mm 1178 mm 991 mm

  • Before initial start, keep the refrigerator still for half an hour before connecting it to power supply.
  • Before putting any fresh or frozen foods, the refrigerator shall have run for 2-3 hours, or for above 4 hours in summer when the ambient temperature is high.

- Spare enough space for convenient opening of the doors and drawers or statement by the distributor.

2.6 Energy saving tips

  • The appliance should be located in the coolest area of the room, away from heat producing appliances or heating ducts, and out of the direct sunlight.
  • Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
  • Be sure to wrap foods properly, and wipe containers dry before placing them in the
    ● appliance. This cuts down on frost build-up inside the appliance.
    Appliance storage bin should not be lined with aluminum foil, wax paper, or paper
  • toweling. Liners interfere with cold air circulation, making the appliance less efficient. Organize and label food to reduce door openings and extended searches. Remove as many items as needed at one time, and close the door as soon as possible.

3 Structure and functions

3.1 Key components

LED lighting Shelf Door tray Drawer

NEVIR NVR-C588600-IFE - Key components - 2

( The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor )

Refrigerating chamber

  • The Refrigerating Chamber is suitable for storage of a variety of fruits, vegetables, beverages and other food consumed in the short term, suggested storage time 3 days to 5 days.
  • Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature.
  • Foods are recommended to be sealed up before putting into the refrigerator.
  • The glass shelves can be adjusted up or down for a reasonable amount of storage space and easy use
  • The low temperature freezing chamber may keep food fresh for a long time and it is mainly used to store frozen foods and making ice.
  • The freezing chamber is suitable for storage of meat, fish, rice balls and other foods not to be consumed in short term.
  • Chunks of meat are preferably to be divided into small pieces for quick freezing and easy access. Please be noted food shall be consumed within the shelf time

Freezing chamber

Drawers, food boxes, shelves, etc. placed according to the position in the picture above are the most energy efficient.

Note: Storage of too much food during operation after the initial connection to power may adversely affect the freezing effect of the refrigerator.

3.2 Functions

A SET TEMPERATURE ① ② ③ ④ ⑤ ⑥ FAST COOL 2°C 3°C 4°C 6°C 8°C

NEVIR NVR-C588600-IFE - Functions - 2

( The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor )

1.Key

A. Temperature setting button

2. Display screen

①temperature setting1
②temperature setting2
③temperature setting3
④temperature setting4
⑤temperature setting5
⑥temperature setting6

3. Display

When power-on the refrigerator, the display screen (including the key light) will shine in full for 3s, then the refrigerator runs according to temperature setting 3.

Display of normal running

On the occurrence of a failure, the corresponding LED light will give a combined display of failure code (in recycling display);

Where there is no failure, the LED light will display the existing temperature setting.

4.Gear setting

The temperature setting will be changed once every time when you press the key SET. Then, the refrigerator will run under the new setting value after 15s.

Setting1→Setting2→Setting3→Setting4→Setting5→Setting6→Setting1→

Fast cool mode:

Enter: Circulating modulation rapid cooling mode.

Operate: Indicator of rapid cooling lights up, and the refrigerator operates at 2°C

Fast cool mode automatically disabled for 24H.

Fast cool function can be used as Super freezing function.

5. Adjustment of manual air damper knob

Turn the air damper slider up, the actual temperature inside the freezer room will drop, turn the air damper slider down, the actual temperature inside the freezer room will rise.

FREEZER-TEMP
NEVIR NVR-C588600-IFE - Adjustment of manual air damper knob - 1

6. Error code

The following warnings appearing on the display indicate corresponding faults of the refrigerator. Though the refrigerator may still have cooling and freezing function with the following faults, the user shall contact a maintenance specialist for maintenance, so as to ensure normal use of the refrigerator.

Fault CodeFault Description
The LED ^1 and LED ^2 litRefrigerator temperature sensor circuit
The LED ^1 and LED ^3 litFreezer defrost sensor
The LED ^1 and LED ^4 litAmbient temperature sensor

4. Maintenance and care of the appliance

4.1 Overall cleaning

- Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and energy saving.

- Check the door gasket regularly to make sure there are no debris. Clean the door gasket with a soft cloth dampened with soapy water or diluted detergent.

- The interior of the refrigerator should be cleaned regularly to avoid odor.

- Please turn off the power before cleaning interior, remove all foods, drinks, shelves, drawers, etc.

- Use a soft cloth or sponge to clean the inside of the refrigerator, with two tablespoons of baking soda and a quart of warm water. Then rinse with water and wipe clean. After cleaning, open the door and let it dry naturally before turning on the power.

- For areas that are difficult to clean in the refrigerator (such as narrow sandwiches, gaps or corners), it is recommended to wipe them regularly with a soft rag, soft brush, etc. and when necessary, combined with some auxiliary tools (such as thin sticks) to ensure no contaminants or bacterial accumulation in these areas.

- Do not use soap, detergent, scrub powder, spray cleaner, etc., as these may cause odors in the interior of the refrigerator or contaminated food.

- Clean the bottle frame, shelves and drawers with a soft cloth dampened with soapy water or diluted detergent. Dry with a soft cloth or dry naturally.

- Wipe the outer surface of the refrigerator with a soft cloth dampened with soapy water, detergent, etc., and then wipe dry.

- Do not use hard brushes, clean steel balls, wire brushes, abrasives (such as toothpastes), organic solvents (such as alcohol, acetone, banana oil, etc.), boiling water, acid or alkaline items, which may damage the fridge surface and interior. Boiling water and organic solvents such as benzene may deform or damage plastic parts.

- Do not rinse directly with water or other liquids during cleaning to avoid short circuits or affect electrical insulation after immersion.

Gas Alcohol Bamboo Mnol

⚠️ Please unplug the refrigerator for defrost and cleaning.

4.2 Cleaning the glass shelf

  • Lift up the front of glass shelf, and then pull out;
  • Remove the glass shelf and clean as needed;
  • The reverse operation is for installation of glass shelf.

NEVIR NVR-C588600-IFE - Cleaning the glass shelf - 1

natural_image Line drawing of a cabinet interior with a hand inserting a component into the door (no text or symbols)

4.3 Defrosting

- The refrigerator is made based on the air-cooling principle and thus has automatic defrosting function. Frost formed due to change of season or temperature may also be manually removed by disconnection of the appliance from power supply or by wiping with a dry towel.

4.4 Out of operation

● Power failure: In case of power failure, even if it is in summer, foods inside the appliance can be kept for several hours; during the power failure, the times of door opening shall be reduced, and no more fresh food shall be put into the appliance.

- Long-time nonuse: The appliance shall be unplugged and then cleaned; then the doors are left open to prevent odor.

- Moving: Before the refrigerator is moved, take all objects inside out, fix the glass partitions, vegetable holder, freezing chamber drawers and etc. with tape, and tighten the levelling feet; close the doors and seal them with tape. During moving, the appliance shall not be laid upside down or horizontally, or be vibrated; the inclination during movement shall be no more than 45°.

The appliance shall run continuously once it is started. Generally, the operation of the appliance shall not be interrupted; otherwise the service life may be impaired

5 Trouble shooting

5.1 Trouble shooting

You may try to solve the following simple problems by yourself. If them cannot be solved, please contact the after-sales department.

Failed operationCheck whether the appliance is connected to power or whether the plug is in well contactCheck whether the voltage is too lowCheck whether there is a power failure or partial circuits have tripped
OdorOdorous foods shall be tightly wrappedCheck whether there is any rotten foodClean the inside of the refrigerator
Long-time operation of the compressorLong operation of the refrigerator is normal in summerwhen the ambient temperature is highIt is not suggestible having too much food in the appliance at the same timeFood shall get cool before being put into the applianceThe doors are opened too frequently
Light fails to get litCheck whether the refrigerator is connected to power supply and whether the illuminating light is damagedHave the light replaced by a specialist
Doors cannot be properly closedThe door is stuck by food packagesThe refrigerator is tilted
Loud noiseCheck whether the floor is level and whether the refrigerator is placed stablyCheck whether accessories are placed at proper locations
Door seal fails to be tightRemove foreign matters on the door sealHeat the door seal and then cool it for restoration(or blow it with an electrical drier or use a hot towel for heating)
Water pan overflowsThere is too much food in the chamber or food stored contains too much water,resulting in heavy defrosting.The doors are not closed properly, resulting in frosting due to entry of air and increased water due to defrosting.
Hot housingHeat dissipation of the built-in condenser via the housing, which is normalWhen housing becomes hot due to high ambient temperature, storage of too much food,provide sound ventilation to facilitate heat dissipation.
Surface condensationCondensation on the exterior surface and door seals of the refrigerator is normal when the ambient humidity is too high. Just wipe the condensate with a clean towel.
Abnormal noiseBuzz: The compressor may produce buzzes during operation,and the buzzes are loud particularly upon start or stop. This is normal.Creak: Refrigerant flowing inside of the appliance may produce creak,which is normal.

WARRANTY CONDITIONS

WARRANTY EXCLUSIONS

Design and specifications are subject to change without notice for product improvement. Any changes to the manual will be updated on our website, you can check the latest version.

nevir®

nevir®

FRIGORÍFICO COMBI TOTAL NO FROST

natural_image Two empty rectangular panels with corner markers, no text or symbols present

CONTENIDO

NEVIR NVR-C588600-IFE - CONTENIDO - 1

natural_image Simple line drawing of a plug with a bulb and cable, no text or symbols present

NEVIR NVR-C588600-IFE - CONTENIDO - 2

natural_image Simple line drawing of a room interior with a cabinet and monitor, no text or symbols present

Gas Gas

NEVIR NVR-C588600-IFE - CONTENIDO - 3

natural_image Line drawing of a refrigerator with a mounted air conditioner unit (no text or symbols)
natural_image Simple line drawing of a refrigerator with tools and a crossed-out box, no text or symbols present
natural_image Simple line drawing of a hand holding a book with a starburst effect, no text or symbols present
natural_image Illustration of a child hanging from an open refrigerator with no text or symbols present
natural_image Cartoon illustration of a distressed character with a sad expression, surrounded by a crossed-out symbol and an exclamation mark (no text or labels)
natural_image Symbol of a trash bin crossed with no text or numbers, representing waste sorting or disposal (no text present)
natural_image Simple line drawing of a person carrying a cardboard box next to an electric refrigerator (no text or symbols)
natural_image Simple line drawing of a refrigerator with a sad face and a sun, next to a potted plant (no text or symbols)
natural_image Simple line drawing of a refrigerator and a door with a smiling face (no text or symbols)
natural_image Technical line drawing of a mechanical assembly with a bracket and base plate (no text or symbols)

NEVIR NVR-C588600-IFE - CONTENIDO - 4

natural_image Line drawing of a refrigerator with doors and shelves (no text or symbols)

bisagra superior

NEVIR NVR-C588600-IFE - CONTENIDO - 6

natural_image Simple line drawing of a smiling refrigerator with a curved handle and a power outlet (no text or symbols)
natural_image Illustration of various household items including a spray bottle, alcohol container, and a kettle (no text or symbols)
natural_image Line drawing of a door with an open lid and hand holding a tool, no text or symbols present

4.3 Descongelación

Manual assistant
Powered by Anthropic
Waiting for your message
Product information

Brand : NEVIR

Model : NVR-C588600-IFE

Category : Refrigerator
