Brand	Philips
Model	Norelco S6015
Product Type	Electric Shaver
Charging Time	Approx. 1 hour
Operating Time	70 minutes
Battery Type	Rechargeable
Supply Unit Model	HQ8505
Input Voltage	100-240 V
Output Voltage	Safe low voltage <24 V
Shaving Heads Model	SH50
Shaving Head Replacement Interval	Every 2 years
Wet/Dry Use	Yes
Waterproof	Yes (suitable for bath and shower)
Cleaning Reminder	Yes
Replacement Reminder	Yes
Travel Lock	Yes
Display Indicators	Battery charge (3 lights), cleaning reminder, replacement reminder, travel lock, unplug for use
Included Accessories	Pouch, cleaning brush, supply unit, small plug
Usage	Cordless only
Skin Adaptation Period	3 weeks recommended

Frequently Asked Questions - Norelco S6015 PHILIPS

How long does it take to fully charge the Philips Norelco S6015?

Charging takes approximately 1 hour. When fully charged, the shaver provides up to 70 minutes of cordless use.

Can I use the shaver in the shower?

Yes, the Philips Norelco S6015 is waterproof and suitable for use in the bath or shower. However, it must be used without the charging cord for safety.

How do I clean the shaver?

After each use, rinse the shaving unit under warm tap water while the shaver is switched on. You can also use the included cleaning brush to remove excess hair. Never dry the shaving unit with a towel.

When should I replace the shaving heads?

For optimal performance, replace the shaving heads every 2 years. The shaver has a replacement reminder that lights up when it’s time to change them. Use original Philips SH50 shaving heads.

What does the travel lock do and how do I activate it?

The travel lock prevents the shaver from accidentally turning on. To activate, press and hold the on/off button for 3 seconds. The travel lock symbol will flash. Deactivate by pressing and holding the button again for 3 seconds.

Can I shave with shaving foam or gel?

Yes, the shaver supports both dry and wet shaving. For wet shaving, apply water and shaving foam/gel to your face. Rinse the shaving unit under water before and during use for a smooth glide.

What do the battery indicator lights mean?

The 3 lights show the remaining battery charge. When charging, lights flash sequentially. A flashing orange bottom light means battery is low (enough for 1 shave). All lights solid white means fully charged. The display turns off after 30 minutes when full.

Why won't my shaver turn on?

Possible causes: the shaver is still plugged in (must be unplugged for use), the battery is empty, or the travel lock is active. If travel lock is on, press and hold the on/off button for 3 seconds to deactivate.

How do I reset the replacement reminder after changing shaving heads?

After installing new shaving heads, press and hold the on/off button for 7 seconds to reset the reminder. Otherwise, the shaver will reset automatically after 9 shaves.

Is the shaver dual voltage?

Yes, the supply unit (model HQ8505) is suitable for mains voltages from 100 to 240 volts, so it can be used worldwide with the appropriate plug adapter.

USER MANUAL Norelco S6015 PHILIPS

English 6

简体中文 24

English

General description

1 Click-on shaving unit
2 Release button
3 On/off button
4 Handle
5 Cleaning reminder
6 Replacement reminder
7 Travel lock symbol
8 Unplug for use symbol
9 Battery charge indicator with 3 lights
10 Socket for small plug
11 Pouch
12 Small plug
13 Supply unit
14 Cleaning brush

Introduction

Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.

Important safety information

Read this important information carefully before you use the appliance and its accessories and save it for future reference. The accessories supplied may vary for different products.

Danger

- Keep the supply unit dry.

Warning

• To charge the battery, only use the detachable supply unit (HQ8505) provided with the appliance.
• The supply unit contains a transformer. Do not cut off the supply unit to replace it with another plug, as this causes a hazardous situation.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
• Always unplug the shaver before you clean it under the tap.
• Always check the appliance before you use it. Do not use the appliance if it is damaged, as this may cause injury. Always replace a damaged part with one of the original type.

English

- Do not open the appliance to replace the rechargeable battery.

Caution

• Never use water hotter than 60° C to rinse the shaver.
• Only use this appliance for its intended purpose as shown in the user manual.
• For hygienic reasons, the appliance should only be used by one person.
• Never use compressed air, scouring pads, abrasive cleaning agents or aggressive liquids such as petrol or acetone to clean the appliance.
• Water may drip from the socket at the bottom of the shaver when you rinse it. This is normal and not dangerous because all electronics are enclosed in a sealed power unit inside the shaver.
• Do not use the supply unit in or near wall sockets that contain an electric air freshener to prevent irreparable damage to the supply unit.

Electromagnetic fields (EMF)

This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fields.

General

- This shaver is waterproof. It is suitable for use in the bath or shower and for cleaning under the tap. For safety reasons, the shaver can therefore only be used without cord.

- The supply unit is suitable for mains voltages ranging from 100 to 240 volts.

- The supply unit transforms 100-240 volts to a safe low voltage of less than 24 volts.

The display

Battery charge indicator

Note: If you press the on/off button during charging, the 'unplug for use' symbol flashes white to remind you that you have to disconnect the appliance from the wall socket.

Quick charge: When the battery is empty and you connect the appliance to the wall socket, the lights of the battery charge indicator light up one after the other repeatedly. When the appliance contains enough energy for one shave, the bottom light of the battery charge indicator starts flashing slowly. While the appliance continues to charge, first the bottom light of the battery charge indicator flashes and then lights up continuously. Then the second light flashes and then lights up continuously, and so on until the appliance is fully charged.

Battery fully charged

Note: When the battery is full, the display switches off automatically after 30 minutes.

Note: This appliance can only be used without cord.

When the battery is fully charged, all lights of the battery charge indicator light up white continuously.

Battery low

When the battery is almost empty, the bottom light of the battery charge indicator flashes orange. At this point there is enough energy left for one shave.

Remaining battery charge

The remaining battery charge is shown by the lights of the battery charge indicator that light up continuously.

'Unplug for use' reminder

The ‘unplug for use’ symbol flashes to remind you that you have to disconnect the appliance from the wall socket before you can switch it on.

Cleaning reminder

Clean the shaver after every use for optimal performance. When you switch off the appliance, the cleaning reminder flashes to remind you to clean the appliance.

Travel lock

When you are going to travel, you can lock the shaver to prevent it from accidentally switching on (see 'Activating the travel lock').

Activating the travel lock

1 Press the on/off button for 3 seconds to use the travel lock mode.

While you activate the travel lock, the travel lock symbol lights up continuously. When the travel lock is activated, the travel lock symbol flashes.

If you try to switch on the shaver while the travel lock is active, the travel lock symbol flashes.

Deactivating the travel lock

1 Press the on/off button for 3 seconds.

While you deactivate the travel lock, the travel lock symbol lights up briefly and the shaver produces a short sound. The shaver switches on and is now ready for use again.

12 English

Replacement reminder

For maximum shaving performance, we advise you to replace the shaving heads every two years. The appliance is equipped with a replacement reminder which reminds you to replace the shaving heads. The shaving unit symbol and arrows light up to indicate that you have to replace the shaving heads (see 'Replacing the shaving heads').

Note: After replacing the shaving heads, you can reset the replacement reminder by pressing the on/off button for 7 seconds. If you do not reset the replacement reminder, the shaver resets automatically after 9 shaves.

Charging

Charge the shaver before you use it for the first time and when the display indicates that the battery is almost empty.

Charging takes approx. 1 hour. When the appliance is fully charged, it has an operating time of 70 minutes.

Note: You cannot use the appliance while it is charging.

Charging with the supply unit

1 Make sure the appliance is switched off.

2 Put the small plug in the appliance and put the supply unit in the wall socket.

3 After charging, remove the supply unit from the wall socket and pull the small plug out of the appliance.

Note: When the battery is full, the display switches off automatically after 30 minutes.

Using the appliance

Note: This appliance can only be used without cord.

Switching the appliance on and off

1 To switch on the appliance, press the on/off button once.
2 To switch off the appliance, press the on/off button once.

Battery charge indicator with 3 lights: The display lights up for a few seconds to show the remaining battery status.

Shaving

Skin adaptation period

Your first shaves may not bring you the result you expect and your skin may even become slightly irritated. This is normal. Your skin and beard need time to adapt to any new shaving system. To allow your skin to adapt to this new appliance, we advise you to shave regularly (at least 3 times a week) and exclusively with this appliance for a period of 3 weeks.

Dry shaving

1 Switch on the appliance.
2 Move the shaving heads over your skin in circular movements to catch all hairs growing in different directions. Make sure each shaving head is fully in contact with the skin. Exert gentle pressure for a close, comfortable shave.

Note: Do not press too hard, as this can cause skin irritation.

3 Clean the appliance after use.

14 English

Wet shaving

For a more comfortable shave, you can also use this appliance on a wet face with shaving foam or shaving gel.

To shave with shaving foam or shaving gel, follow the steps below:

1 Apply some water to your skin.

2 Apply shaving foam or shaving gel to your skin.

3 Rinse the shaving unit under the tap to ensure that the shaving unit glides smoothly over your skin.

4 Switch on the appliance.

5 Move the shaving heads over your skin in circular movements to catch all hairs growing in different directions. Make sure each shaving head is fully in contact with the skin. Exert gentle pressure for a close, comfortable shave.

Note: Do not press too hard, this can cause skin irritation.

Note: Rinse the shaving unit regularly to ensure that it continues to glide smoothly over your skin.

6 Dry your face.

7 Clean the appliance after use.

Note: Make sure you rinse all foam or shaving gel off the appliance.

Removing or attaching click-on attachments

1 Make sure the appliance is switched off.
2 Pull the attachment straight off the appliance.

Note: Do not twist the attachment while you pull it off the appliance.

3 Insert the lug of the attachment into the slot in the top of the appliance. Then press down the attachment to attach it to the appliance ('click').

Cleaning

Cleaning the shaver under the tap

Clean the shaver after every use for optimal performance.

Never dry the shaving unit with a towel or tissue, as this may damage the shaving heads.

While rinsing the shaving unit, water may drip out of the base of the shaver. This is a normal occurrence.

1 Use the cleaning brush to remove any excess hair from the shaving heads and hair chamber.

16

English

2 Switch on the appliance.

3 Rinse the shaving unit under a warm tap.

4 Switch off the appliance. Press the release button to open the shaving unit.

5 Rinse the hair chamber under the tap.

6 Rinse the shaving head holder under a warm tap.

7 Carefully shake off excess water and let the shaving head holder air-dry completely.

8 Close the shaving head holder ('click').

Storage

1 Store the shaver in the pouch supplied.

Note: Make sure the appliance is dry before you store it in the pouch.

Replacement

Replacing the shaving heads

For maximum shaving performance, we advise you to replace the shaving heads every two years.

Replace damaged shaving heads immediately. Always replace the shaving heads with original Philips shaving heads (see 'Ordering accessories').

Replacement reminder

The replacement reminder indicates that the shaving heads need to be replaced. The shaving unit symbol and arrows light up when you switch off the appliance.

1 Switch off the appliance.

2 Press the release button to open the shaving unit.

18

English

3 Pull the shaving head holder off the bottom part of the shaving unit.

4 Turn the retaining rings counterclockwise and remove them. Place them aside in a safe place.

5 Remove the shaving heads from the shaving head holder.

Discard the used shaving heads immediately to avoid mixing them with the new shaving heads.

6 Place the new shaving heads in the shaving head holder.

Note: Make sure that the projections of the shaving heads fit exactly into the recesses of the shaving head holder.

7 Place the retaining rings back onto the shaving heads and turn them clockwise to reattach the retaining ring.

Each retaining ring has two recesses and two projections that fit exactly in the projections and recesses of the shaving head holder.

- Turn the ring clockwise until your hear a click to indicate that the ring is fixed.

Note: Hold the shaving head holder in your hand when you reinsert the shaving heads and reattach the retaining rings. Do not place the shaving head holder on a surface, as this may cause damage to the shaving heads.

8 Reinsert the hinge of the shaving head holder into the slot of the shaving unit. Close the shaving head holder ('click').

9 To reset the replacement reminder, press and hold the on/off button for approx. 7 seconds.

Ordering accessories

To buy accessories or spare parts, visit www.philips.com/parts-and-accessories or go to your Philips dealer. You can also contact the

English

Philips Consumer Care Center in your country (see the international warranty leaflet for contact details).

The following accessories and spare parts are available:

• SH50 Philips shaving heads
• HQ110 Philips shaving head cleaning spray
• RQ111 Philips beard styler attachment
• RQ585 Philips cleansing brush attachment
• RQ560, RQ563 Philips cleansing brush heads
• JC301, JC302, JC303, JC304, JC305 cleaning cartridge
• HQ8505 supply unit

Note: The availability of the accessories may differ by country.

Recycling

- This symbol means that this product shall not be disposed of with normal household waste (2012/19/EU).

- This symbol means that this product contains a built-in rechargeable battery which shall not be disposed of with normal household waste (2006/66/EC). Please take your product to an official collection point or a Philips service center to have a professional remove the rechargeable battery.

- Follow your country's rules for the separate collection of electrical and electronic products and rechargeable batteries. Correct disposal helps prevent negative consequences for the environment and human health.

Removing the rechargeable shaver battery

Only remove the rechargeable battery when you discard the appliance. Before you remove the battery, make sure that the appliance is disconnected from the wall socket and that the battery is completely empty.

Take any necessary safety precautions when you handle tools to open the appliance.

Be careful, the battery strips are sharp.

1 Remove the screw in the back of the shaver.
2 Remove the back panel.

3 Take out the power unit.

4 Bend the snap hooks aside and remove the transparent cover of the power unit.
5 Lift out out the battery holder and cut the wires with a pair of cutting pliers or scissors.

22 English

6 Bend the battery tags aside with a pair of cutting pliers or a screw driver.
7 Remove the rechargeable batteries.

Warranty and support

If you need information or support, please visit www.philips.com/support or read the international warranty leaflet.

Warranty restrictions

The shaving heads (cutters and guards) are not covered by the terms of the international warranty because they are subject to wear.

Troubleshooting

This chapter summarizes the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, visit www.philips.com/support for a list of frequently asked questions or contact the Consumer Care Center in your country.

Shaver

Problem Possible cause Solution

The appliance does not work when I press the on/off button.	The appliance is still attached to the wall socket. For safety reasons, the appliance can only be used without charging cord.	Unplug the appliance and press the on/off button to switch on the appliance.
	The rechargeable battery is empty.	Recharge the battery.

Problem Possible cause Solution

	The travel lock is activated.	Press the on/off button for 3 seconds to deactivate the travel lock.
	The shaving unit is soiled or damaged to such an extent that the motor cannot run.	Clean the shaving heads thoroughly or replace them.
The appliance does not shave as well as it used to.	The shaving heads are damaged or worn.	Replace the shaving heads.
	Hairs or dirt obstruct the shaving heads.	Clean the shaving heads in the regular way or clean them thoroughly.
I replaced the shaving heads, but the replacement reminder is still showing.	You have not reset the replacement reminder.	To reset the replacement reminder, press and hold the on/off button for more than 7 seconds.
A shaving head symbol has suddenly appeared on the display.	This symbol is the replacement reminder.	Replace the shaving heads.
Water is leaking from the bottom of the appliance.	During cleaning, water may collect between the inner body and the outer shell of the appliance.	This is normal and not dangerous because all electronics are enclosed in a sealed power unit inside the appliance.

简体中文

基本说明

剃须

32 简体中文

2 在皮肤上涂抹剃须泡沫或剃须啫喱。

4 启动产品。

简体中文

1 确保产品电源已关闭。

2 将附件竖直抽离产品。

注意：将附件从产品上抽出时，不要旋转。

2 启动产品。

3 用温水冲洗剃须刀头部件。

5 在水龙头下冲洗胡茬储藏室。

简体中文

6 用温水冲洗剃须刀头支架。

1 将剃须刀存放在随附的软袋中。

6 将新的剃须刀头装到剃须刀头支架中。

3 取出电源部件。

6 用钢丝钳或螺丝刀将电池挡片向外掰。

7 卸下充电电池。
