424271 - Screen filter MANHATTAN - Free user manual and instructions

Product Type	Privacy Screen Filter
Brand	Manhattan
Model	424271
Dimensions	26.1 x 16.3 cm (10.27 x 6.4 in)
Privacy Viewing Angle	45 degrees from center
Package Contents	Privacy Filter, mounting kit, cleaning cloth, reference guide
Mounting Kit	Clear plastic tabs and adhesive strips included
Cleaning Cloth	Included for screen preparation
Installation Options	Tabs for monitors larger than filter; adhesive strips for monitors smaller than filter
Screen Protection	Helps protect LCD from scratches and minor damage
Glare Reduction	Reduces glare and annoying reflections
Eye Strain Reduction	Decreases eyestrain
Compatibility	For notebook and LCD monitor screens
Cutout Position	Top right when facing the filter
Maintenance	Clean with included cloth; do not use abrasive cloths or excessive force
Safety Precautions	Do not bend, cut, or alter the filter; use only with LCD screens
Additional Features	Multi-option mounting kit for versatile installation

Frequently Asked Questions - 424271 MANHATTAN

How do I install the Manhattan 424271 Privacy Filter?

Follow the steps in the included guide. First, clean your monitor screen with the enclosed cloth. If your screen is larger than the filter, use the clear plastic tabs. If smaller, use the adhesive strips. Ensure the cutout is at the top right when you face the filter. Do not bend or cut the filter.

Can I cut the privacy filter to fit my screen?

No, do not cut, bend, or otherwise alter the filter. Doing so will compromise its performance and may damage it. Use the provided mounting kit to adjust fit.

How does the privacy filter work?

It narrows the field of view to approximately 45 degrees from the display center, making it difficult for others to see the screen from the side. This effectively discourages glances from curious onlookers.

What is included in the package?

The package includes the Privacy Filter, a mounting kit (with clear plastic tabs and adhesive strips), a cleaning cloth, and a reference guide.

How do I clean the privacy filter?

Use the included cleaning cloth. Do not use abrasive cloths or exert excessive force. Do not bend the filter while cleaning.

Will the Manhattan 424271 fit my 13-inch laptop?

The filter measures 26.1 x 16.3 cm (10.27 x 6.4 in). Check your screen dimensions. If your screen is larger, use the clear plastic tabs; if smaller, use the adhesive strips.

Can I use this filter on a desktop monitor?

Yes, it is designed for notebook and LCD monitor screens. Ensure the screen is flat and not curved.

How do I attach the filter if my monitor screen is larger than the filter?

Use the clear plastic tabs. Separate the tabs, peel the protective cover from the adhesive, place the tabs along the bottom and sides of your monitor, then slip the filter behind the tabs.

How do I attach the filter if my monitor screen is smaller than the filter?

Use the adhesive strips (double-sided). Remove strips one at a time, place along the back edges of the filter aligning with the monitor frame, peel the remaining cover, and press the filter onto the monitor. Avoid covering control buttons.

Does the filter protect against scratches?

Yes, once installed, the filter helps protect the fragile LCD surface from scratches and minor damage.

USER MANUAL 424271 MANHATTAN

Thank you for purchasing this MANHATTAN Privacy Filter.

By narrowing the field of view to approximately 45^ from the display center, it effectively discourages glances from curious onlookers and prevents the disclosure of on-screen displays to information thieves. Once installed, the Privacy Filter also helps protect fragile LCD surfaces from scratches and minor damage, and can decrease eyestrain, glare and annoying reflections.

Privacy Filter with cleaning cloth and multi-option mounting kit.

The image at far right shows how the display on the monitor screen becomes more difficult to discern through the Privacy Filter as the view approaches a 45° angle, at which point the display becomes completely "private" for the user and indiscernible to others.

Blank whiteboard with two blue square cutouts and a small grid of cubes on the left (no text or symbols)

MOUNTING KIT INSTALLATION

IMPORTANT: For proper product performance, do not bend, cut or otherwise alter the size or shape of the Privacy Filter. Do clean your monitor screen with the enclosed cloth before positioning the filter, and do ensure the cutout appears at the top right as you face the filter when it's in place (as circled in blue in the Step 4 image below).

If your monitor screen is larger than the Privacy Filter, use the clear plastic tabs.

1. Separate the tabs.
2. Peel the protective cover from the adhesive.
3. Place the tabs along the bottom and sides of your monitor.
4. Slip the Privacy Filter behind the tabs so it covers the screen.

If your monitor screen is smaller than the Privacy Filter, use the adhesive strips (adhesive on both sides).

1. Remove the strips one at a time from the sheet.
2. Place the strips along the back edges of the filter so they line up with the monitor frame. NOTE: Be careful not to cover any control buttons.
3. Peel the remaining protective cover from the strips and press the filter in place on the monitor frame so it covers the screen.

SPECIFICATIONS

Dimensions by Model # *

• 424004: 18 x 25 cm (7 x 9.8 in.)
• 424028: 23 x 30 cm (9 x 11.8 in.)
• 424035: 21 x 33 cm (8.25 x 13 in.)
• 424042: 27 x 34 cm (10.5 x 13 in.)

• 424257: 28.6 x 21.5 cm (11.25 x 8.4 in.)
• 424264: 30.5 x 19.0 cm (12 x 7.4 in.)
• 424271: 26.1 x 16.3 cm (10.27 x 6.4 in.)
• 424295: 41.0 x 25.7 cm (16.1 x 10.1 in.)
• 424301: 47.5 x 29.7 cm (18.7 x 11.7 in.)

Package Contents

• Privacy Filter
• Mounting kit, cleaning cloth, reference guide

CAUTIONS

• Use the filter only with notebook or LCD monitor screens.
• Do not exert excessive force or use an abrasive cloth when cleaning the surface of the filter.
• Do not bend the filter.
