| Product Type | Built-in Kitchen Hood |
| Brand | Corbero |
| Model | CCST3506022TLW |
| Width | 60 cm |
| Depth | 50 cm |
| Height (min-max) | 12-15 cm |
| Net Weight | 6.5 kg |
| Power Supply | 220-240 V ~ 50 Hz |
| Motor Power | 120 W |
| Max Extraction Rate | 600 m³/h |
| Noise Level (max) | 65 dB(A) |
| Number of Speeds | 3 + Boost |
| Lighting | 2 x LED (1.5 W each) |
| Grease Filter | Aluminum, washable |
| Carbon Filter | Optional, replaceable |
| Controls | Push buttons |
| Installation Type | Built-in under cabinet |
| Exhaust Outlet | 150 mm diameter |
| Energy Class | A+ |
| Air Recirculation | Possible with carbon filter |
| Warranty | 2 years |
Frequently Asked Questions - CCST3506022TLW CORBERO
How do I install the Corbero CCST3506022TLW kitchen hood?
Refer to the user manual for detailed installation steps. Generally, it involves drilling holes for mounting brackets, connecting the ducting (if using extraction mode), and wiring the hood to the mains supply. Ensure the hood is level and securely fixed.
How often should I clean the grease filter?
Clean the aluminum grease filter every month or after 30 hours of use. It can be washed with warm soapy water or in a dishwasher. Allow it to dry completely before reinstalling.
Can this hood be used in recirculation mode?
Yes, if you purchase a carbon filter (not included). The carbon filter absorbs odors and allows the air to be recirculated back into the kitchen. Replace the carbon filter every 3-6 months depending on usage.
What is the noise level of this hood?
The maximum noise level is 65 dB(A) at highest speed. Lower speeds are quieter, making it suitable for open-plan kitchens.
Does the hood come with a remote control?
No, the CCST3506022TLW is controlled via push buttons on the front panel. It does not include a remote control.
What are the dimensions of the hood?
The hood is 60 cm wide, 50 cm deep, and has an adjustable height of about 12-15 cm to fit standard cabinets.
How do I replace the LED bulbs?
The hood uses built-in LED lights that are not user-replaceable. If they fail, contact customer service or a qualified technician.
What is the extraction capacity?
The maximum extraction rate is 600 m³/h, suitable for kitchens up to 20 m² with normal cooking intensity.
Can I duct the hood outside?
Yes, using the 150 mm exhaust outlet. It is recommended to use rigid or flexible ducting with minimal bends for optimum performance.
What is the warranty period?
Corbero offers a 2-year warranty on this hood for manufacturing defects. Register your product online to activate warranty.
