| Product Type | Pedestal Fan |
| Model | FAN-N16TECSILENCE |
| Brand | Grunkel |
| Fan Diameter | 16 inches (40 cm) |
| Height (Max) | Approximately 130 cm |
| Weight | Approximately 5 kg |
| Power Source | 220-240 V, 50 Hz |
| Power Consumption | 50 W |
| Speed Settings | 3 speeds (Low, Medium, High) |
| Oscillation | Yes, 90° oscillation |
| Timer | Up to 7 hours |
| Remote Control | Included (battery operated) |
| Noise Level | Silent operation (< 35 dB) |
| Blade Material | Plastic |
| Protection Grille | Metal with safety mesh |
| Maintenance | Clean with damp cloth; disconnect before cleaning |
| Safety Features | Overheat protection, tip-over switch |
| Spare Parts Availability | Contact Grunkel customer service |
| Included Accessories | Remote control, user manual |
Frequently Asked Questions - FAN-N16TECSILENCE Grunkel
User questions about FAN-N16TECSILENCE Grunkel
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Fan in PDF format for free! Find your manual FAN-N16TECSILENCE - Grunkel and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. FAN-N16TECSILENCE by Grunkel.
USER MANUAL FAN-N16TECSILENCE Grunkel
DESCUBRE TODO LO QUE PODEMOS HACER POR TI EN
www.grunkel.com
GRACIAS POR ESCOGER ESTE PRODUCTO GRUNKEL
This instruction manual is an accurate reproduction of the specifications, operation and look of the product you have just bought, except for typographical, print or translation errors. The specifications, operation and features of this product are subject to change without further notice.
Núm. Descripción
- Please, read carefully the entire instruction manual before using it.
- Pay special attention to the safety indications.
- Keep this instruction manual. If you hand over this appliance to another person, these instructions must be also be transferred.
- Keep also the guarantee card, purchase ticket or invoice. If possible, keep the original box with all the accessories included for future inquiries.
General safety instructions
Before using the appliance ensure that the main voltage corresponds to the voltage displayed on the rating label. Always plug the appliance into a suitable electrical outlet.
In order to avoid electrical shock risk, please do not inmerse the power cord nor the appliance into water or any other kind of liquid. Check the cleaning instructions.
Do not use unauthorized accessories. This will result in cancellation of the guarantee and could cause accidents.
Do not keep the power cording hanging from the table or the shelf. Keep it away from hot sources. Do not allow sharp or blunt objects to touch it. Do not operate the appliance if the power cord or the plug are damaged, or if you notice unusual operation of the appliance.
Do not leave the appliance operating without supervision. Always switch off the appliance and unplug it. Pull the plug, not the power cord.
If any repair is needed, or if the power cord must be replaced, please ask a aqualified professional or contact the Official Technical Support.
CAUTION: to ensure children's safety, keep away packaging material such as plastic bags, carton boxes, etc.
Always watch the appliance when using it near children Never leave the appliance without supervision.
grunkel
Only use the appliance for domestic purposes and in the way indicated in these instructions.
This appliance is not supposed to be operated by any external timer or remote control system.
Do not use the appliance over or near heat sources, such as gas heaters, electric heaters or hot ovens.
Do not use the appliance near flammable objects or materials.
Ensure the appliance is installed on a plain stable surface.
Do not immerse the appliance in water. Do not handle the appliance with wet hands.
Before cleaning the appliance, check that it is unplugged.
If you require a copy of the instruction manual, please contact the Official Technical Support.
Do not use the appliance in an improper way. It could cause severe injuries. In the event that the appliance has been misused by the costumer, the guarantee will be cancelled.
Do not use the appliance outdoors.
Do not place the appliance on surfaces with instability or low heat resistance, or on top of any other domestic appliance.
WARNING: In case of improper use, injuries and loss of guarantee may occur.
Children must be supervised so they do not play with the appliance.
Keep the appliance and its cord out of reach of children under 8 years old.
WARNING: This appliance is intended for domestic purposes exclusively. Do not use for commercial applications.
Do not start operating the appliance until all its parts have been assembled properly.
Allow enough space between the appliance and other objects. Do not block the air inlets and outlets. Allow at least 15cm of free space around the appliance.
Do not cover the appliance while operating.
Do not insert sharp or metallic objects inside the appliance's grill.
Do not place the appliance near curtains, sheets or similar clothes. be careful to avoid entanglements with long hair.
Check the packaging includes all parts before starting assembling the appliance.
Do not throw away the used batteries into the organic waste. Deliver these batteries to a collection point for its recycling.
CAUTION!
CHILDREN UNDER 8 YEARS OLD SHOULD NOT USE NOR CLEAN THIS APPLIANCE WITHOUT THE SUPERVISION OF AN ADULT. NEITHER CAN BE USED NOR CLEAN BY PEOPLE WITH REDUCED PHYSICAL, MENTAL OR SENSORIAL CAPABILITIES, WITHOUT EXPERIENCE OR KNOWLEDGE CONCERNING THE USE OF THE APPLIANCE, OR WITHOUT HAVING RECEIVED PROPER TRAINING UNDER DIRECT SUPERVISION FROM AN EXPERIENCED PERSON RESPONSIBLE FOR THEIR SAFETY.
Part identification
Num. Description
| 1 Front grille |
| 2 Grille ring |
| 3 Adjustment thread for blades |
| 4 Blades |
| 5 Adjusting thread for rear grille |
| 6 Rear grille |
| 7 Motor shaft |
| 8 Motor shaft ring |
| 9 Fan head |
| 10 Tilt adjustment screw |
| 11 Control unit |
| 12 Screw for control unit |
| 13 Screw for height adjustment |
| 14 Base |
| 15 Control panel |
| 16 Switch |
| 17 Bar for height adjustment |
| 18 Base |
| 19 Heavy base |
| 20 Adjustment thread for base |
| 21 Screw for grille |
Assembly
The fan is delivered with the grilles unassembled. The grilles must be assembled before the appliance is put into operation.
Warning: Never use the appliance without the base and all parts assembled. The appliance must only be used in an upright position. Any other positioning will be dangerous.
Assemble the base and other parts of the appliance in the following sequence:
- Unpack the ventilator and remove all parts from the carton.
- Fit the base (18) into the base (14) and tighten the corresponding fitting thread (20).
- Insert the control unit into the height adjustment rod (17). Tighten the fixing screw (12).
- Use the clamping nut on the back of the grille (5) to assemble the rear grille (6) to the fan head. Then fit the blades (4). Then use the blade adjusting thread (3) to fasten the blades in place.
- To assemble the front grille (1) to the rear grille, use the grille ring (2) carefully to hold them together, and tighten it with the screw provided (22).
Operation
Before using the fan, make sure that it is on a flat and stable surface. Damage may occur if the unit is placed at an angle.
Turn all switches to the "OFF" position. Insert the plug into the socket. Make sure that the plug fits correctly into the socket.
To turn off the fan completely, turn all controls to the OFF position, and pull the cord out of the socket.
-
"ON/SPEED": Press the ON / SPEED button to start the fan at the desired speed, indicated in the following sequence: 1, 2, 3, 4, 5, 6. The control panel displays the current speed.
-
"PROGRAM/TIMER":
- If the fan is in stand-by mode, press the "PROGRAM/TIMER" button. Set the desired operating mode, oscillation and speed. Then choose the timer for the fan to start running (e.g. if you select 0.5 hours, the fan will start running automatically after 30 minutes). The indicator light corresponding to the selected time will illuminate.
grunkel
- If the fan is running, press the "PROGRAM/TIMER" button. Then choose the timer for the fan to stop. The indicator light corresponding to the selected time will illuminate.
OSCILLATE": If you want to increase the area of action in the room, press the OSCILLATE button. The fan will oscillate and ventilate the room with greater range. The oscillation indicator light will remain illuminated. To stop oscillation, simply press the OSCILLATE button again. The oscillation indicator light will turn off.
- "MODE": selects the operating mode: normal, natural and sleep.
- "OFF": Press the OFF button to turn off the fan. All indicator lights will turn off.
- The functions described above can be operated from the remote control by pressing the corresponding buttons. The remote control operates at a maximum distance of 7 metres and at an angle of approximately 20 degrees.
- If the remote control does not work properly, replace the old batteries with new ones. The battery disposal instructions must be observed.
- To increase or decrease the height of the fan, loosen the height adjustment screw, and raise or lower the bar to the desired height. Then tighten the height adjustment thread firmly. Note: Turn off the fan while adjusting the height.
Cleaning and maintenance
Unplug the power cord from the electrical outlet before cleaning, disassemble or handle the appliance or any of its parts.
The appliance should be disassembled first before carrying out a deep cleaning.
Use damp soft cloth to clean the appliance's surface. Please clean carefully the motor unit and the control panel with a dry or damp soft cloth. If the cloth is excessively moistened, clean immediately with a dry cloth.
Clean the blades with a damp soft cloth. It is possible to moisten the cloth with a mild solution of water and soap.
Never immerse the appliance into water or any other liquid. Do not put it under a water stream. Do not put the appliance into the dishwasher. Do not use aggressive cleaner products. Do not use metallic brushes or sharp tools to clean the appliance.
Remove the batteries from the remote controller if it is not going to be used during long periods of time.
If appliance is not to be used for long periods of time, clean it and store it in its packaging. If you are disassembling it, place every part in an orderly manner to make easier its future assembly. Store the appliance in a dry environment.
WARNING
This appliance is intended for domestic use. Do not use it for commercial purposes. If so, guarantee would be cancelled.
220-240V \~50Hz / 60W
Product disposal
Regulation regarding waste from electronic appliances according to RAEE 2002/96/EC. This symbol means the appliance can not be treated as regular domestic waste; it must be returned to the distributor, handed over the corresponding electronic product collection point or delivered to the collection point empowered for such purpose, so its components are recycled and not mixed within domestic waste.
You can also contact your local waste collection service, so it can be collected and treated accordingly following the environment protection instructions, or to receive proper information about the steps to follow for the correct disposal of the appliance.
The correct disposal of an appliance implies avoiding negative consequences for both environment and health. A proper disposal allows to save a significant amount of energy and resources. As a reminder of the necessity of disposing the appliances separately, the product displays the symbol of a crossed out garbage bin.
