Product Type	Range Hood
Brand	Haceb
Model	Appiani 60 PENIN ALA VID
Width	60 cm (23.6 in)
Installation Type	Peninsula/island mount
Color/Finish	Stainless steel / glass
Extraction Rate (max)	Approx. 600 m³/h (depending on model variant)
Number of Speeds	3 speed settings + boost
Control Type	Touch control or push buttons
Lighting	LED lights (2 x 3W or similar)
Filter Type	Aluminum grease filter, washable
Air Duct Diameter	150 mm (6 in)
Noise Level (max)	~65 dB(A) (estimate)
Energy Efficiency Class	A (typical for modern hoods)
Annual Energy Consumption	~35 kWh/year (estimate)
Power Supply	220-240 V, 50/60 Hz
Motor Power	200-300 W (typical)
Dimensions (H x W x D)	Approx. 60 cm x 60 cm x 50 cm (height adjustable)
Weight	Approx. 15-20 kg (depending on materials)
Maintenance	Clean grease filter monthly; replace charcoal filter if recirculation; wipe exterior with damp cloth
Safety Features	Auto shut-off timer, overheat protection (if available)
Spare Parts Availability	Filters, bulbs, motor available via Haceb service centers
Repairability Index	Estimated 7.5/10 (based on typical design)
Certifications	CE, RoHS

Frequently Asked Questions - Appiani 60 PENIN ALA VID Haceb

How do I install the Haceb Appiani 60 PENIN ALA VID range hood?

Installation should be performed by a qualified professional. Ensure the hood is mounted securely above the cooking surface at a height of 65-75 cm for gas cooktops or 55-65 cm for electric. Connect the ducting to an external outlet or use recirculation mode with charcoal filters.

What is the correct way to clean the grease filters?

Remove the aluminum grease filters and wash them in warm soapy water or in a dishwasher at low temperature. Allow them to dry completely before reinstalling. Clean filters every 2-3 months depending on usage.

How often should I replace the charcoal filter?

If your hood is set to recirculation mode, replace the charcoal filter every 3-6 months. The filter cannot be washed and must be replaced to maintain effective odor removal.

Why is my hood not extracting air effectively?

Check if the grease filters are clogged. Also ensure the ducting is not blocked or kinked. If recirculating, the charcoal filter may be saturated. Verify the fan speed is set correctly.

Can I use the hood without ducting?

Yes, the hood can be used in recirculation mode. You will need to install charcoal filters (not included with all models) to purify the air before recirculating it into the kitchen.

How do I replace the LED lights?

Turn off the power and allow the lights to cool. Depending on the model, you may need to remove the light cover. The LED module is typically clip-on or screw-mounted. Use only manufacturer-recommended replacement parts.

What should I do if the hood stops working?

First, check the power supply and circuit breaker. Ensure the plug is properly inserted. If the hood has a thermal cut-off, it may have tripped; wait for the motor to cool before resetting. If issues persist, contact Haceb customer support.

Can I install the hood myself?

We recommend hiring a professional electrician and installer due to electrical connections and structural mounting. Improper installation may void warranty or cause safety hazards.

What is the noise level of this hood?

The noise level varies by speed. At maximum speed, it can reach around 65 dB(A), which is comparable to normal conversation. Lower speeds are quieter.

Where can I find spare parts or accessories?

Authorized Haceb service centers carry genuine spare parts such as filters, bulbs, and motors. You can also check the Haceb website or contact their support for part numbers and ordering.

USER MANUAL Appiani 60 PENIN ALA VID Haceb

IMPORTANTE

Figura 13.

Filtro de carbón

Figura 14.

Filtro de carbón

Figura 15.

IMPORTANTE

LIMPIEZA

Filtro de aluminio atrapa grasa

Servicio Haceb

más cerca

•ASESORÍA
