| Product Type | Crimping Tool |
| Brand | Panduit |
| Model | LCB1-38-E |
| Color | Red and black |
| Material | Steel with cushioned grips |
| Length | 10 in (254 mm) |
| Weight | 1.2 lbs (544 g) |
| Power Source | Manual (hand-operated) |
| Application | Crimping insulated and non-insulated terminals |
| Wire Range | 22-10 AWG |
| Crimping Mechanism | Ratchet-controlled for consistent crimps |
| Adjustable Die | Yes, for different terminal sizes |
| Ergonomic Handle | Yes, with non-slip grip |
| Safety Lock | Built-in ratchet release button |
| Maintenance | Clean with dry cloth; lubricate pivot points periodically |
| Certifications | UL/CSA listed |
| Warranty | 1 year limited warranty |
| Spare Parts Availability | Die sets and springs available |
| Repair Service | Authorized service centers |
Frequently Asked Questions - LCB1-38-E Panduit
What is the Panduit LCB1-38-E used for?
The Panduit LCB1-38-E is a hand crimping tool designed for crimping insulated and non-insulated terminals and connectors onto wires from 22 to 10 AWG.
How do I adjust the crimping die for different terminal sizes?
The LCB1-38-E has an adjustable die. Turn the knurled dial at the base of the jaw to select the appropriate cavity size matching your terminal.
Does the Panduit LCB1-38-E have a ratchet mechanism?
Yes, it features a ratchet mechanism that ensures a complete crimp cycle before releasing the handle, preventing partial crimps.
How do I release the ratchet if stuck?
Press the ratchet release button located on the side of the tool to disengage the ratchet lock and open the jaws.
What maintenance does the LCB1-38-E require?
Regularly clean the tool with a dry cloth and apply light machine oil to the pivot points and ratchet mechanism. Store in a dry environment.
Can I use this tool for <b>RG coaxial connectors</b>?
No, the LCB1-38-E is intended for terminal crimping only. For coaxial connectors, use a dedicated coaxial crimp tool.
What is the wire range for the LCB1-38-E?
The tool accommodates solid and stranded wire from 22 AWG to 10 AWG.
Are replacement dies available for this tool?
Yes, replacement die sets and springs can be ordered from Panduit authorized distributors.
Is the LCB1-38-E covered by a warranty?
Yes, it comes with a 1-year limited warranty against defects in materials and workmanship.
How do I crimp <b>bootlace ferrules</b> with this tool?
Select the appropriate die size for the ferrule. Insert the ferrule into the die and a wire, then squeeze the handles until the ratchet releases. Ensure a secure crimp.
