9641 HDG - Cooker Arçelik - Free user manual and instructions
Find the device manual for free 9641 HDG Arçelik in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Cooker |
| Brand | Arçelik |
| Model | 9641 HDG |
| Energy Source | Electric / Gas (Mixed) |
| Hob Type | Gas burners with electric ignition |
| Number of Cooking Zones | 4 gas burners |
| Oven Type | Electric oven with convection |
| Oven Capacity | 65 liters |
| Oven Functions | Convection, Grill, Fan-assisted |
| Grill | Yes, with adjustable power |
| Convection | Yes, for even cooking |
| Timer | Digital timer with programmable functions |
| Child Lock | Yes, on control panel |
| Automatic Shut-off | Yes, for oven and hob |
| Dimensions (HxWxD) | 85 x 60 x 60 cm |
| Net Weight | 50 kg |
| Voltage | 220-240 V |
| Frequency | 50 Hz |
| Cleaning Type | Enamel interior, easy to wipe |
| Warranty | 2 years |
Frequently Asked Questions - 9641 HDG Arçelik
How do I set the timer on the Arçelik 9641 HDG?
Press the timer button on the control panel, then use the + and - buttons to set the desired time. The oven will automatically shut off when the time elapses.
How should I clean the oven interior?
Use a damp cloth and mild detergent. Avoid abrasive cleaners. For stubborn stains, use a non-abrasive oven cleaner. The enamel coating makes cleaning easier.
Is there a child lock function?
Yes, the device includes a child lock. Activate it by pressing and holding the lock button for 3 seconds. To deactivate, repeat the same action.
What is the convection function used for?
The convection function circulates hot air inside the oven for even cooking and browning. It is ideal for baking pastries, roasting meats, and cooking multiple dishes simultaneously.
Can I use aluminum foil in the oven?
Yes, you can use aluminum foil, but avoid direct contact with the heating elements. Place it on a baking tray or wrap food loosely to prevent fire hazards.
How do I replace the oven light bulb?
Ensure the oven is switched off and cooled. Remove the glass cover by turning it counterclockwise. Replace the bulb with a high-temperature resistant bulb (25W, 300°C). Refit the cover.
Why is one of the gas burners not igniting?
Check if the burner cap is properly placed and clean. Ensure the gas supply is open. If the spark igniter is not working, clean the electrode and dry it.
How do I unlock the control panel after child lock activation?
Press and hold the child lock button for 3 seconds until the lock icon disappears from the display.
What is the maximum temperature of the oven?
The oven can reach a maximum temperature of 250°C (approximately 482°F) in standard and convection modes.
Does the oven have a self-cleaning function?
No, the oven does not feature a self-cleaning function. It requires manual cleaning. However, the enamel interior facilitates easy wiping.
