Product Type	Tumble Drier (Condenser)
Brand	Rommer
Model	SECAPLIS
Rated Capacity	8.0 kg
Dimensions (W x D x H)	595 x 615 x 845 mm
Net Weight	43 kg
Power Supply	220-240 V~, 50 Hz
Rated Input Power	2700 W
Energy Efficiency Class	B
Condensation Efficiency Class	B
Annual Energy Consumption	557.0 kWh/year
Programs	Cotton (Iron, Light, Standard, Extra), Synthetics (Light, Standard, Extra), Delicate, Warm/Cool (20/30 min), Quick, Refresh
Special Functions	Delay (1-24h), Anti-Crease (30 or 120 min), Gentle, Child Lock, Drum Light
Moisture Sensor	Automatic moisture sensing
Lint Filter	Clean after each use
Air Condenser	Clean periodically
Water Container	Empty after each use; automatic full alarm
Noise Level (Standard Cotton Full Load)	69 dB(A)
Safety Features	Child lock, overheating protection, door open detection, thermal cut-off
Installation	Indoor use only, on solid level ground, not behind lockable door
Accessories (Optional)	External drainage hose, stacking kit (purchased separately)
Spare Parts Availability	Contact manufacturer or service agent
Repair Policy	Only authorised technicians; user can check basic faults before calling service

Frequently Asked Questions - SECAPLIS Rommer

What should I do if the dryer does not start?

Check that the mains plug is inserted, the door is properly closed, the programme is selected, and the start/pause button has been pressed. Also verify the fuse in your house. If the display does not come on, ensure the power supply is active.

How often should I clean the lint filter?

Clean the lint filter after each use. A clogged filter blocks air circulation, increasing drying time and energy consumption. Disconnect the power cord before cleaning.

What does it mean when the water container icon flashes?

The water container is full or there is a pump error. Empty the container or check the pump. The dryer will pause; after emptying, press Start/Pause to resume.

How can I activate the child lock?

Press and hold the Anti-Crease and Gentle buttons simultaneously for 3 seconds. The 'Child Locked' icon lights up. To release, repeat the same action.

What is the maximum drying capacity?

The maximum rated drying capacity is 8.0 kg. Do not overload to ensure efficient drying and avoid damage.

Why is the drying time too long or clothes not dry enough?

Check if the lint filter and air condenser are clean. Ensure the water container is not full. Verify proper ventilation around the dryer. You may need to select a higher drying programme or use the Time function.

Can I dry delicate fabrics like wool?

Yes, use the Delicate programme for machine-washable woollen items. This programme provides gentler care. Remove and hang items immediately after cycle ends.

What does error code E30 mean?

E30 indicates a heater problem. The error code flashes on the display. Check the heater and thermostat. If the issue persists, contact an authorised technician.

How do I use the delay function?

Select a programme, then press Delay repeatedly to set a delay from 1 to 24 hours. Press Start/Pause to begin the countdown. The drying will start after the set delay.

What should I do if water leaks from the dryer?

Align the dryer horizontally. Clean the air condenser and door seals. Ensure the water container is properly inserted. If leaking continues, contact service.

USER MANUAL SECAPLIS Rommer

Safety information....1
Installation....5
Part description....6
Attention and advice....8
Description of controls....9
Operation instruction.... 10
Programme table....11
Specialty drying function....12
Cleaning and routine maintenance.... 14
Alarm function.... 15
Precautions....16
Technical specifications & ......Product fich€7

Dry care symbols

Please pay attention to use the drying machine if the materials of your clothes can not be dried by it or contain the symbols as follows:

Dry	Normal	Not tumble dry normal	Do not dry
Line dry / hang to dry	Drip dry	Dry flat	In the shade
Dry clean Do not dry clean	dry clean	Dry clean normal cycle with any solvent	Dry clean normal cycle petroleum solvent only

Safety notes

⚠️ To prevent any damages to your and others' life or property, you have to follow the safety notes.

1. This product belongs to Category I electrical appliances, and only for drying textiles which have been washed with water in the household. Please pay attention to the safety of power use during the operation!
2. The power source with reliable earthing must be used. Its earth wire must be buried under the ground and shall not be connected with the public utilities such as city water pipe or gas pipe etc. The earth wire and null wire shall be distinguished and shall not be connected together.
3. The power wire shall be met national standard and must be able to withstand the current above 16A. To ensure your and your family's safety, please make improvement immediately if any power use at your home does not comply with the above-mentioned requirements.
4. The tumble dryer is not to be used if industrial chemicals have been used for cleaning.
5. The lint trap has to be cleaned frequently.
6. Lint must not to be allowed to accumulate around the tumble dryer.

7. Adequate ventilation has to be provided to avoid the back flow of gases into the room from appliance burning other fuels, including open fires.

8. Do not dry unwashed items in the tumble dryer.

9. Items that have been soiled with substance such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with a extra amount of detergent before being dried in the tumble dryer.

10. Items such as foam rubber (latex form), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.

11. Fabric softeners, or similar products, should be used as specified by the fabric softener instructions.

12. The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature the ensures that the items will not be damaged.

13. WARNING: never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.

14. The exhaust air must not be discharged into a flue which is used for exhausting fumes from appliance burning gas or other fuels.

15. The appliance must not be install behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the tumble dryer. In such a way that a full opening of the tumble dryer door is restricted.

16. Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a tumble dryer. The items become warm, causing an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling, stacking or storing oil-affected items can prevent heat from escaping and so create a fire hazard.

17. If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care products be placed in a tumble dryer they should first be washed in hot water with extra detergent-this will reduce, but not eliminate, the hazard.

18. The appliance should not be overturned during normal use or maintenance.

19. Remove all objects from pockets such as lighters and matches.
20. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
21. If the power cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
22. This appliance is for indoor use only.
23. The openings must not be obstructed by a carpet.
24. Children of less than 3 years should be kept away unless continuously supervised.
25. Keep pets away from this appliance.
26. If the appliance appear high temperature abnormally, please draw the mail plug immediately.

Correct Disposal of this product:

Symbol of a trash bin crossed with no text or numbers, representing waste sorting or disposal (no text present)

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.

Electric shock hazard

1. Do not draw the power cord forcefully to pull out the mains plug.
2. Please do not plug/draw the mains plug with wet hands.
3. Do not damage the power cord and the power plug.

Injury danger

1. Do not disassemble and install the dryer under no instruction or supervision.
2. Do not stack this dryer on washing machine without stacking kits. (if want stacking on washing machine, please purchase the Independent parts and it must be installed by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.)
3. Do not lean on the opened door of the dryer.
4. Do not put any pyrotoxin on the dryer, such as the candle, electric cooker.

Damage danger

1. Do not dry over the rated capacity.
2. Do not operate the dryer without the filter door and .filter base
3. Do not dry the clothes before being spun.
4. Do not expose the dryer directly under the sun, and indoor use only.
5. Do not install the dryer in the humid and drenching environment.
6. At the cleaning and maintenance, please do remember to pull out the power plug and do not directly wash the dryer with water.

Explosion danger

Please do not dry the clothes with some flammable substances such as the coabil, or there will be the explosion.alcohol

Transport

Move cautiously. Do not grasp any salient parts of machine. The machine door can not be used as the handle for delivery.

Installation position

1. Please install the dryer on solid and flat ground.
2. Please do not place the dryer on the slope, soft carpet or wooden floor.
3. Please do not install the dryer outdoors, to prevent the dryer from being frozen to damage of machine parts.

Simple line drawing of a container with a cross symbol, placed on a surface with pebbles (no text or symbols)

Simple line drawing of a mechanical assembly with a circular component and cross symbol (no text or labels)

Simple line drawing of a washing machine with a circular valve and cross symbol (no text or labels)

Level adjusting

If the floor is obviously uneven, it needs to be adjusted. It vibrates the machine, causing machine to move from its position. Using tools to adjust the height of four machine legs to adjust the levelness of this dryer.

Power supply connection

1. Make sure that the voltage of the power supply is the same as the electric of the dryer.specification
2. Please do not connect it with the power connection board, the universal plug or socket.

Part description

Accessories

The following parts are optional for specific models.

If your dryer has following parts, please the install following the instruction below.

Installation step:

Step 1: removing the drain hose from the hose connector using glove.

Step 2: insert the external drainage hose.

Step 3: put the hose holder on the washing basin or any other sink.

Line drawing of a kitchen sink with faucet and bucket (no text or symbols)

Quick start

Attention

Before the first cycle, the dust and grease may remain in this dryer during the transportation, to avoid contaminating your clothes, period of manufacture and please follow these steps:

a) Put some clean rags into the drum.
b) Plug the power.
c) Press "On/Off" button, select the "Quick" programme, and press "Start/Pause". button.
d) After finishing this programme, please follow the "cleaning and routine maintenance" to clean the lint filter and air condenser on page 14.

Advice

1. Before drying, thoroughly spin the laundry in washing machine. High spin speed can reduce the drying time and save energy consumption.
2. For uniform drying result, sort the laundry according to fabric type and drying programme.
3. Before drying, please close zips, hooks and eyelets, button up, tie fabric belts, etc.
4. Do not over dry the clothes, because over dried clothes can easily get creases or shrinkage.
5. Do not dry the articles containing rubber or similar elastic materials such as bicycle covers and feather products.raincoats,
6. The door can be opened only after the programme of the drying machine is Do not open the door before the programme finished, as the skin complex may be scalded by steam or hot surface.
7. Clean the lint filter and empty container after each use to avoid extension of drying time and energy consumption.
8. Do not dry these clothes after dry-clean process.
9. The weight references as follows:

	Blended Coats (about 800g)		Jackets (about 800g in cotton)		Jeans Trousers (about 800g)		Towel Quilts (about 900g in cotton)
	Single Sheets (about 600g in cotton)		Work Clothes (upper and lower) (about 1120g in cotton)		Pajamas (about 200g)		Shirts (about 300g in cotton)
	Undershirts (about 180g in cotton)		Underpants (about 70g in cotton)		Socks (about 30g in blended material)

    subgraph Status display
        H["Drying"] --> I["8:88"]
        J["Ironing"] --> I
        K["Normal"] --> I
        L["Airing"] --> I
        M["Start Pause"] --> N["Anti-Crease"]
        O["Child Lock"] --> P["Gentle"]
    end

    subgraph Start/pause
        Q["Start/Pause"] --> R["Anti-Crease"]
        S["Anti-Crease"] --> T["Gentle"]
    end

    subgraph Anti-Crease
        U["This function will give more care to protect sensitive textiles from being creased"] --> V["Gentle"]
        W["This function will give less heat to protect sensitive textiles from high temperature"] --> X["Gentle"]
    end

    subgraph Cycle
        Y["Different Dryer cycle can be selected according to the user's needs to make the clothes have more effective drying result."] --> Z["On/Off"]
    end

    subgraph On/Off
        AA["On/Off"] --> AB["On and off function. When this button is pressed, this machine is switched between on and off."]
    end

    B --> AC["Time Adjusting"]
    AC --> AD["Delay"]
    AD --> AE["Time"]

    subgraph Digital tube display
        AF["Only light (DELAY > REMAIN>) relevant to the phase that is currently being carried out will remain display during the drying process."]
        AG["When the drying procedure begins, REMAIN> will display the remaining time, that is, the drying procedure will finished in [x:xx"] time.]
        AH["The display "- "means programme in "Standby" status, you can press any buttons or open the door to awaken programme."]
    end

Programme selector

1. Press the 【On/Off】 button.
2. Rotate the programme knob to select the desired programme.
3. Select the Delay, Anti-Crease or Gentle functions for additional option. 【】 【】 【
4. Press the Start/Pause key. 【】

The Drying procedure stops

The buzzer will prompt from the dryer when finishing the cycle.

Press the On/Off button to turn down the power, and pull out the power cable.

Programme table

Programme		Weight (max)	Application/Properties
Cotton	For cottons and coloureds made of cotton or linen.
	Iron	8.0kg	To dry cotton pieces of clothing.Drying level: .applicable to iron
	Light		To dry cotton pieces of clothing.Drying level: .applicable to hang
	Standard		To dry cotton pieces of clothing.Drying level: .cupboard dry
	Extra		To dry cotton pieces of clothing.Drying level: .extra dry
Synthetics	For non-iron washing made of synthetic and blended fabrics, cotton.
	Light	3.5kg	To dry thin synthetic fabrics which are also to be hanged or ironed,sush as knitwear,shirts.Drying level: applicable to hang or iron.
	Standard		To dry thin synthetic fabrics which are not ironed, such as easy care shirts, table linen,baby clothes, socks. Drying level: cupboard dry.
	Extra		To dry thick or multi-layered synthetic fabrics. Drying level: extra dry.
Delicate		3.0kg	For machine-washable woollen textiles.Textiles are fluffer,but not dried.Remove and hang up textiles when the programme ends.
Warm/Cool(20min/30min)		3.0kg	For timer programme , delicate textiles made of acrylic fibres or small items.Using T ime f unction to adjust W ram time.【】
Quick		3.0kg	For washing which is to be dried quickly, e.g. made of acrylic fibres or for individualsmall items. Also for subsequent drying.
Refresh		1.0kg	For refreshing or gertly cleaning textiles with commercially available dry cleaning products.

Note: the above programme is only recommended for use, the user can according to personal habits to choose the right programme.

Specialty drying function

1. Instruction of the moisture sensor

This function can automatically sense the moisture of clothes, and will adjust the time of drying procedure according to how much clothes automatically you put into the dryer.

This function will automatically activate during the drying procedure except the "Cool" "Refresh" and programme. "Warm"

2. Additional time adjusting function

This function can set the time of drying procedure by your self; the time can be adjusted from 20 to 60 minutes by press "Time" button. This function special designed for clothes, for example, one facecloth or two pairs of socks.

to control drying process, but only for "Warm" It's like using timer programme.

3. Instruction to the delay drying procedure

This function is used to delay clothes drying within 24 hours. You can press this key continuously; it can be selected within 1-24 hours. The delay time means drying procedure will start in x:xx hours.

When the delay procedure starts, the display will only show the delay start time and flash DELAY icon. After 30s, the display will light DELAY icon and show “-”.

Steps in details

(1). Load your laundry and make sure the machine door is closed.
(2).Press the 【On/Off】button,then to turn the programme selector knob and select a desired programme.
(3). You can select the 【Anti-Crease】 or 【Gentle】 functions according to your need.
(4). To press the 【Delay】 key.
(5). Continue to press the 【Delay】 to select the delay time.
(6). After the 【Start/Pause】key is pushed, the Dryer is at the run condition. The drying procedure will be automatically performed when the delay time is over.
(7). If you push the 【Start/Pause】 button again, the delay function will be paused.
(8). If you want to cancel the "Delay" function, please press the 【On/Off】 button.

4. Instruction of the child safety feature

(1). This machine incorporates a special child safety lock, which can prevent children from carelessly pressing keys or making the faulty operation.
(2). When the dryer is at the operation state, press the【Anti-Crease】and【Gentle】buttons at the same time for over 3 seconds to start child lock function. When child lock function is set, the display will light “Child Locked” icon.

and no key can effect to the dryer .except 【On/Off】 button

Under the start state of the child lock button, the 【】 and Anti-Crease

【】buttons shall be pressed at the same time for over 3 seconds to Gentle release the child lock function.

5. Instruction of the Anti-Crease function【】

At the end of the drying cycle, the “Anti-Crease” phase time is 30 minutes (default) or 120 minutes (selected), when the anti-crease function is selected in all of the and the drum willdrying programme, the LED of anti-crease shall illuminate, give more care to intermittent rotate during the drying programme, in older to ensure the sensitive textiles can not get crease.

6. Instruction of the Gentle function【】

When the gentle function is selected except “Refresh”, “Cool” and “Warm”, the display time shall be to add 20 minutes, the LED of gentle shall illuminate, and the programme will give less heat to protect sensitive textiles from high temperature which may harm to these textiles, such as acetate, elastane and etc.

7. Instruction of the drum light

For your convenience, this function can help you to see clearly when you open the machine door.

Clean the lint filter

Leave the dryer to cool down

1.Open the machine door.

1. Take out the lint filter, pull upward to take it out.

2. Clean the lint filter; wipe off the scrap threads accumulated on the lint filter, with your hand or rinse with water and dry thoroughly.

3. Reinstall the lint filter.

Technical diagram of a mechanical component with internal grid pattern and red arrow indicating rotation (no text or symbols)

Illustration of a hand interacting with a curved panel or frame structure (no text or symbols visible)

Technical line drawing of a mechanical assembly or device with no visible text or symbols

NOTE!

1. The lint filter accumulated on the filter will block the air circulation, which will cause the extension of drying time and energy use; therefore, the scrap thread filter shall be cleaned after each use.

2. Do disconnect the power cord before cleaning!

3.Do not operate the dryer without the lint filter!

1. Clean the lint filter after each use to prevent lint accumulation inside the dryer.

Wash air condenser

-Leave the dryer to cool down.

-Residual water may escape, place an absorbent cloth under the maintenance flap.

1. Unlock the maintenance flap.
2. Completely open maintenance flap.
3. Screw both locking levers toward as each other.
4. Pool out the air condenser.
5. Clean the air condenser completely, drain thoroughly.
   6.Clean the seals.
6. Re-insert the air condenser, handle at the button!
7. Unscrew both locking levers.
   9.Cloth the maintenance flap until it locks into position.
   Please clean the air condenser if frequently used.
   Do not damage the air condenser!

Technical line drawing of a mechanical component with internal compartments and a handle (no text or symbols)

Diagram of a device interior with arrows indicating flow or movement, no visible text or symbols

Diagram showing a device with a fan and cable, no text or symbols present

Technical line drawing of a mechanical component with internal compartments and mounting holes (no text or symbols)

1. Clean with water only; do not use hard/sharp-edged objects! Do not operate the dryer without the air condenser!

2. During drying, water may collect between the window and the seal, but this does not affect the function of your dryer!

Empty the water container

1. Hold and pull out the water container with two hands.
2. Tilt the water container, pour out the condensed water.
3. Insert the water container.

Line drawing of hands operating a mechanical component (no text or symbols)

Line drawing of a kitchen appliance with a sink and water drain, no text or symbols present

WARNING:

1. Empty the water container after each use, the programme will be paused and the “icon will flash if the water container is full during the drying process. After the container emptyed, the dryer can be restarted by pushing 【Start/Pause】 button.

2.Do not drink the condensed water.

Alarm function

Alarm Problem	Alarm Reason Buzzer Alarm Release
“”Is flashing	Water tank full or pump error		Check the water tank and pump.
“”Is flashing	Air flow block		Check the filter and the air folw
“”E30	Heater problem	The Error Code is flashing on X:XX at Flash Rate 1. Meanwhile the beep is sounded every 15 minutes.	Check the heater and the thermostat
“”E32	Humidity sensor error		Check the Humidity sensor and PCB
“”E33	Temperature sensor error		Check the front temperature sensor
“”E34			Check the rear temperature sensor
“”E60	Motor error		Check the motor and the PCB

Precautions

⚠️ Only authorised technicians can carry out repairs.

Before you call customer service, please check if you have deal with the faulty by yourself or if you have follow the user instructions.

A technician will charge you for advice, even during the warranty period.

Problem	Solution
Display does not come on	The mains plug is inserted.Check the programme selected.Check fuse in the house.
“”Is flashing “”Is flashing	Empty condensation container.If failure, check hose for condensation outlet.
“”Is flashing	Clean air cooler.Clear lint filter.
Dryer does not start	Check the start saltedCheck the the door has closed.Check the programme has set.
Water is running out	Align dryer horizontally.Clear air condenser and door seals.
Door is open by itself	Press door until it “clicks”into position.Check the clothes is over load .
Humidity in the room is increase significantly	Ventilate room adequately.Clean the cool grille.Ensure that the air condenser has been inserted.
Degree of dryness was not reached or drying time too long	Clean lint filter and wash condenser.Empty container.Check water outlet.Dryer installation too restricted.Clean the moisture sensors.Use next higher drying programme or usingTimer programme.

⚠️ If you cannot deal with the fault by yourself and need help:

1. Press the 【On/Off】button.
2. Pull out the mains plug and call the service.

Specification

Power supply voltage	220-240V~
Rated input Power	2700W
Rated Frenquency	50Hz
Overall Size	595×615×845(mm)
Rated Drying Capacity	8.0kg
Net Weight	43kg

Note: The rated capacity is the maximum capacity, make sure that the dry clothes which are loaded to the appliance do not exceed the rated capacity each time.

Product fiche

Brand: Midea

Model: MDS80-C01/B0107E-EU18-Y2, MDT80-C01/B0107E-EU18-Y2, MDL80-C01/B0107E-EU18-Y2

Rated capacity: 8kg

Dryer Type: Condenser

Energy efficiency class: B

Energy consumption 557.0kWh per year, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.

Automatic or non-automatic: Automatic

EU Ecolabel: N/A

Energy consumption of the standard cotton programme at full load: 4.74 kWh

Energy consumption of the standard cotton programme at partial load: 2.50 kWh

Power consumption of the off-mode (Po): 0.28 W

Power consumption of the left-on mode (PI): 1.72 W

Duration of the left-on mode: 10 min

The 'standard cotton programme' used at full and partial load is the standard drying programme to which the information in the label and the fiche relates, that this programme is suitable for drying normal wet cotton laundry and that it is the most efficient programme in terms of energy consumption for cotton.

Weighted programme time of the standard cotton programme at full and partial load: 123 min

Programme time of the standard cotton programme at full load: 160 min

Programme time of the standard cotton programme at partial load: 95 min

Condensation efficiency class B on a scale from G (least efficient) to A (most efficient).

Average condensation efficiency of the standard cotton programme at full load: 81.2%

Average condensation efficiency of the standard cotton programme at partial load: 83.6%

Weighted condensation efficiency for the standard cotton programme at full and partial load: 82.6%

Sound power level for the standard cotton programme at full load: 69dB

Wuxi Little Swan Co., Ltd.

No.18 ChangJiang South Road, Wuxi City, Jiangsu Province, China

附页

可选电压频率对照表

额定电压	额定频率
110V~	60Hz
127V~	60Hz
220V~	50Hz
220V~	60Hz
230V~	50Hz
230V~	60Hz
240V~	50Hz

注意: 此页为非打印页面，仅供制单参考

V3.0

MDS70-C01_B0107E-EU18-Y2-PM01
