USER MANUAL CX244 COBY
The power cord on this product contains lead, a chemical known to the State of California to cause [cancer, and] birth defects or other reproductive harm. Wash hands after handling."
E-5
COBY
OPERATING INSTRUCTIONS
E-1
- RADIO DIAL SCALE
- VOLUME CONTROL KNOB
- FUNCTION (RADIO/TAPE) SWITCH
- RADIO BAND SELECTOR SWITCH
- RADIO TUNING CONTROL KNOB
6A. PAUSE BUTTON
6B. STOP & ELECT BUTTON 6C. FAST FORWARD BUTTON
6C. FAST FORWARD BUTTON 6D. REWIND BUTTON
6F PLAY BUTTON
6F RECORDING BUTTON - SPEAKER
- TELESCOPIC ANTENNA
- BATTERY DOOR (BEHIND SET)
- HEADPHONE (EARPHONE) SOCKET
E-2
POWER SUPPLY
BATTERY OPERATION
- OPEN THE BATTERY DOOR AND INSERT 5 PCS "D-CELL" (UM-1/R20 TYPE) BATTERIES. PLEASE OBSERVE THE CORRECT BATTERY POLARITIES OR THE SET WILL NOT WORK.
- IMPORTANT WHEN THE SET IS ONLY BEING USED WITH AC POWER OR NOT BEING USED FOR AN EXTENDED PERIOD OF TIME, REMOVE THE BATTERIES TO PREVENT LEAKAGE OR DAMAGE.
AC OPERATION - MAKE SURE THE SET VOLTAGE OF THE UNIT MATCHES YOUR LOCAL HOUSEHOLD VOLTAGE
- INSERT THE TAIL-END OF THE AC-CORD INTO THE AC-COSKET AT THE REAR OF THE SET.
- INSERT THE PLUG OF THE AC-CORD INTO THE WALL OUTLET WITH AC-POWER.
OPERATION OF RADIO
- SET THE FUNCTION SWITCH TO "RADIO" AND THE BAND SELECT OR SWITCH TO THE DESIRED BAND
- ROTATE TUNING KNOB TO TUNE-IN THE DESIRED STATION.
- ADJUST THE TELESCOPIC ANTENNA AND POSITION OF THE SET TO OBTAIN THE BEST RECEPTION.
- ADJUST THE VOLUME KNOB TO THE DESIRED LEVEL
- TO TURN OFF THE RADIO. SLIDE THE FUNCTION SWITCH TO "TAPE" (OFF) POSITION, WITHOUT ANY TAPE BUTTON PRESSED.
CASSETTE TAPE PLAYBACK
- SLIDE THE FUNCTION SWITCH TO THE "TAPE" POSITION
- OPEN THE CASSETTE DOOR BY PRESSING THE "STOP/EJECT" CASSETTE BUTTON
- INSERT A PRERECORDED CASSETTE WITH THE TAPE SIDE UP, INTO THE PROPER GUIDE RAILS ON THE INSIDE OF THE CASSETTE DOOR.
- GENTLY PUSH THE CASSETTE DOOR FORWARD(INWARDS) TO CLOSE IT. MAKE SURE THE TAPE IS FULLY AND PROPERLY INSERTED BEFORE DOING SO.
- PRESS THE CASSETTE PLAY BUTTON TO START PLAYBACK. NOTE THAT THE TAPE MOVES FROM RIGHT TO LEFT.
- ADJUST THE VOLUME TO THE DESIRED LEVEL
- THE TAPE PLAYBACK CAN BE STOPPED AT ANY TIME BY PRESSING THE "STOP" BUTTON. WHEN THE TAPES HAS ENDED, THE SET SWITCHES ITSELF OFF AUTOMATICALLY AND RELEASE THE PLAY BUTTON.
- PRESS THE STOP BUTTON FOLLOWED BY THE 'REWIND' OR "FAST-FORWARD" BUTTON TO REWIND OR FORWARD THE TAPE AT HIGH SPEED.
E-3
