USER MANUAL AWO256 PULSAR

AWO 256 metal casings are designed as components (supplying) in intruders alarms, access control systems, security systems etc. There are intended for installation:

• control panel optional with supplementary modules
- access control controllers with optional modules
• radio or GSM transmitter with optional module PSU
- other dedicated devices, components etc.

2. Monta / Installation:

Metal enclosure (+PCB) must be installed by a qualified installer, holding relevant certificates, required and necessary in particular country for connecting (interfering with) 230 V AC systems and low-voltage installations.

Because transformer is designed for continuous operation and is not equipped with ON/OFF switch, power supply circuit should have appropriate overload protection. User should be informed how to disconnect unit from mains (most often by separate and mark adequate fuse in fuse box). Power supply installation should be conform to applicable standards and law. Enclosure (+PCB) should be installed indoor, where air humidity is normal (RH=90% max. without condensation) and temperature in range of -10°C to +40°C.

Caution! Prior to entering for installation it is necessary to make sure if the voltage in 230 V AC circuit is disconnected.

All service works inside enclosure must be carried out with 230 V AC supply voltage disconnected.

1. Mount the PCB (control panel, etc.) with dedicated holes (using pins, screws etc.).
2. Mount enclosure in a dedicated location, lead connection wires ( 230 V) and signal cables through the cable openings.

Remarks: supply circuit \~230 V should be carried out with three-core cable

(with yellow-green protective PE conductor).

1. Supply conductors 230V should be connected to 230 V AC L-N terminals of the transformers.

Protective conductor should be connected to the terminal marked with grounding symbol.

Caution! Operating the power supply without properly made and technically operational electric shock protection circuit is IMPERMISSIBLE!

This creates hazard of equipment damage and risk of electric shock.

Remarks: connect required voltage U1 or U2 or U3 (secondary winding voltage) for the correct device.

1. If necessary, make other connections required for the correct type of system / device.

Remarks: consistent with requirements and recommendation of the equipment producer.

1. Start system (switch on 230V , battery), adjust or configure: according to procedure of producer's system.

2. After installing and checking the proper operation of the system, close enclosure.

3. Parametry techniczne / Technical data:

Centrale / Alarm control panels: HS2016, HS2016-4, HS2032, HS2064, HS2128.

Moduły / Modules: HSM2300, HSM2204, HSM2208, HSM2108, PCL-422.

Power Series

Centrale / Alarm control panels: PC1832, PC1864.

Moduły / Modules: PC5320, PC5100, PC5108, PC4216, PC5200, PC5204, PC5400, IT-100.

Power Series Pro

Centrale / Alarm control panels: HS3032, HS3128, HS3248.

Centrale / Alarm control panels: PR402, CPR 32- SE.

SATEL:

Centrale / Alarm control panels: Integra24, 32, 64, 64+, 128, 128+, 256+, Versa5,10, 15 Plus, IP, Perfecta16, 32, 32 LTE –T 32, Micra, CA-10 P, CA-6 P, CA-5 P, CA-4 VP.

Moduły / Modules: CA-64 PTSA, CA-10 E, ETHM-1 Plus, ETHM-2,GSM-X, GSM-X LTE, INT-ADR, INT-AV, INT-E, INT-FI, INT-GSM, INT-KNX-2, INT-O, INT-PP, INT-R, INT-RS Plus, INT-VG, INT-VMG, MST-1, ACCO-NT, ACCO-KP-PS, ACCO-KPWG-PS.

TELMOR:

Centrale / Alarm control panels: TCA-824.

Moduly / Modules: TEX800.

Documentaon shows which devices can be installed in a given enclosure. It does not denote how many different devices can be installed in one enclosure. Number of installed devices depends on their size and arrangement.

Simple line drawing of a rectangular container with scattered circular and diamond shapes (no text or symbols)

AWO256 - 17/TRP50/SATEL

Simple line drawing of a rectangular door with corner handles and no text or symbols

Simple line drawing of a rectangular door with four vertical slots and a handle (no text or symbols)

OZNAKOWANIE WEEE

The waste electric and electronic products do not mix with general household waste. There is separate collection system for used electric and electronic products in accordance with legislation under the WEEE Directive and is effective only with EU.
