Brand	Midea
Model	MMO25PFA-ACSFBK
Product Type	Microwave oven with grill and convection
Appliance Placement	Countertop
Rated Voltage	230-240 V ~ 50 Hz
Microwave Power Input	1380 W
Microwave Power Output	900 W
Grill Power Input	2100-2300 W
Convection Power Input	2100-2300 W
Capacity	25 L
Control Type	Knob and touch button
Display Type	Digital LED
Number of Auto Menus	30
Functions	Microwave, Air Fry, Grill, Convection, Combination, Preheat, Re-Crisp, Defrost, Fermentation, Cavity Deodorization, Microwave Sterilization
Smart Connectivity	Wi-Fi via SmartHome App
Door Type	Side opening with safety interlock
Interior Material	Stainless steel or coated metal
Turntable	Glass tray included
Accessories Included	Air fry basket, grill rack, glass tray
Cleaning	Wipe with damp cloth; use lemon water for cavity
Safety Features	Child lock, door interlock, overheat protection

Frequently Asked Questions - MMO25PFA-ACSFBK MIDEA

Can I use metal containers in this microwave?

No, metal containers or utensils should not be used in microwave or combination modes as they can cause arcing and damage the oven. Only use microwave-safe utensils.

How do I connect the oven to the SmartHome app?

Download the SmartHome app, register, and follow the in-app instructions. On the oven, press and hold the Pause/Cancel button for 3 seconds until 'AP' appears, then complete connection via the app.

What is the maximum cooking time for microwave mode?

The maximum cooking time for microwave mode is 1 hour and 35 minutes (1h35m).

How do I use the Air Fry function?

Press the Air Fry button, set temperature (max 240°C) using the knob, press Start, then set time (max 1h35m) and press Start again. Place food on the air fry basket.

Why does the oven light dim during cooking?

The oven light may dim during low power microwave cooking. This is normal and does not affect cooking performance.

How do I clean the oven cavity?

Place half a lemon in a bowl with 300ml water, heat on 100% microwave power for 10 minutes, then wipe with a soft dry cloth. Avoid abrasive cleaners.

What do I do if the oven doesn't start?

Check that the power cord is securely plugged in, the door is fully closed, and the circuit breaker has not tripped. If the issue persists, contact a qualified technician.

Can I use the air fry basket in microwave mode?

No, the air fry basket and grill rack are not suitable for microwave or combination modes. Use them only in convection, grill, or air fry functions.

How does the defrost function work?

Select Auto Menu 26 (Fast Defrost), set weight using the knob (100g to 2.0kg), and press Start. The oven will pause and beep to remind you to turn the food over during defrosting.

What is the preheat function for?

The preheat function heats the oven to a desired temperature (150-230°C) before cooking, similar to a conventional oven. After preheating, the oven will automatically switch to the corresponding cooking mode.

USER MANUAL MMO25PFA-ACSFBK MIDEA

Line drawing of a microwave oven with control panel and buttons (no text or symbols)

MICROWAVE OVEN

SmartHome

Download the app & activate product

USER MANUAL

MMO25PFA-ACSFBK

THANK YOU LETTER

Thank you for choosing Midea! Before using your new Midea product, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers in a safe way.

CONTENTS

THANK YOU LETTER EN-01

SAFETY INSTRUCTIONS EN-02

SPECIFICATION EN-11

PRODUCT OVERVIEW EN-12

PRODUCT INSTALLATION EN-13

OPERATION INSTRUCTIONS EN-15

APP SETUP AND OPERATION EN-25

CLEANING AND MAINTENANCE EN-26

TROUBLE SHOOTING EN-27

TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT ---- EN-28

DATA PROTECTION NOTICE EN-29

SAFETY INSTRUCTIONS

Intended Use

The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation. If you find any damage, please contact the retailer or dealer. Please note modifications or alterations to the appliance are not allowed for your safety concern. Unintended use may cause hazards and loss of warranty claims.

Explanation of Symbols

	DangerThis symbol indicates that there are dangers to the life and health of persons due to extremely flammable gas.
	Warning of electrical voltageThis symbol indicates that there is a danger to life and health of persons due to voltage.
	WarningThe signal word indicates a hazard with a medium level of risk which, if not avoided, may result in death or serious injury.
	CautionThe signal word indicates a hazard with a low degree of risk which, if not avoided, may result in minor or moderate injury.
	AttentionThe signal word indicates important information (e.g. damage to property), but not danger.
	Observe instructionsThis symbol indicates that a service technician should only operate and maintain this appliance in accordance with the operating instructions.

Read these operating instructions carefully and attentively before using/commissioning the unit and keep them in the immediate vicinity of the installation site or unit for later use!

Precautions To Avoid Possible Exposure To Excessive Microwave Energy

a. Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
b. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
c. Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the:
- DOOR (bent)
- HINGES AND LATCHES (broken or loosened)
- DOOR SEALS AND SEALING SURFACES
d. The oven should not be adjusted or repaired by anyone except properly qualified service personnel.

Addendum

If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation.

important Safety Instructions

To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:

WARNING

• Read and follow the specific:"PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock.
• WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

• WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.

• When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.

• Only use utensils that are suitable for use in microwave ovens.
• If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
• Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.
• The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature hecked before consumption, in order to avoid burns.
• Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.
• The oven should be cleaned regularly and any food deposits removed.
• Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could diversely affect the life of the appliance and possibly result in a hazardous situation.
• The appliance must not be installed behind a decorative door in order to avoid overheating. (This is not applicable for appliances with decorative door.)
• Only use the temperature probe recommended for this oven. (for ovens provided with a facility to use a temperature-sensing probe.)
• The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet.
• The microwave oven must be operated with the decorative door open. (for ovens with a decorative door.)

- This appliance is intended to be used in household and similar applications such as:

- staff kitchen areas in shops, offices and other working environments;

- by clients in hotels, motels and other residential type environments;

- farm houses;

- bed and breakfast type environments.

- The microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.

- Metallic containers for food and beverages are not allowed during microwave cooking.

- The appliance shall not be cleaned with a steam cleaner.

- The appliance is intended to be used freestanding.

- The rear surface of appliances shall be placed against a wall.

- The appliances are not intended to be operated by means of an external timer or separate remote-control system.

- The temperature of accessible surfaces may be high when the appliance is operating.

WARNING

When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated.

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

To Reduce The Risk Of Injury To Persons Grounding Installation

DANGER

Electric Shock Hazard:

Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.

WARNING

Electric Shock Hazard:

Improper use of the grounding can result in electric shock.

Do not plug into an outlet until appliance is properly installed and grounded.

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.

This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded.

If it is necessary to use an extension cord, use only a 3-wire extension cord.

1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.

2. If a long cord set or extension cord is used:

1) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.

2) The extension cord must be a grounding-type 3-wire cord.

3) The long cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally.

Utensils

CAUTION

Personal Injury Hazard:

It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven."

There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below.

Utensil Test:

• Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
• Cook on maximum power for 1 minute.
• Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
• Do not exceed 1 minute cooking time.

Materials You Can Use In Microwave Oven

Utensils Remarks
Browning dish	Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break.
Dinnerware	Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes.
Glass jars	Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break.
Glassware	Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags	Follow manufacturer's instructions. Do not close with metal tie. Make slits to allow steam to escape.
Paper plates and cups	Use for short-term cooking/warming only. Do not leave oven unattended while cooking.
Paper towels	Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only.
Parchment paper	Use as a cover to prevent splattering or a wrap for steaming.
Plastic	Microwave-safe only. Follow the manufacturer's instructions. Should be labeled "Microwave Safe". Some plastic containers soften, as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as directed by package.
Plastic wrap	Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.

Materials To Be Avoided In Microwave Oven

Utensils Remarks
Aluminum tray	May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle	May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils	Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam	Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
Wood	Wood will dry out when used in the microwave oven and may split or crack.

SPECIFICATION

Model	MMO25PFA-ACSFBK
Rated Voltage 230-240 V~ 50 Hz
Rated Input (Microwave)	1380 W
Rated Output (Microwave)	900 W
Rated Input (Grill)	2100-2300 W
Rated Input (Convection)	2100-2300 W

PRODUCT OVERVIEW

Names of Oven Parts and Accessories

In case of any differences between the appliance and the pictures in this manual, the product shall prevail.

Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories:

Instruction Manual

3D rendering of a rectangular metal tray with mesh pattern and two side handles (no text or symbols)

Airfry basket (Cannot be used in microwave and combination, it should be used for airfry)

Simple line drawing of a metal grate or rack structure with four vertical supports (no text or symbols)

Grill Rack (Cannot be used in microwave function and must be placed on the glass tray)

A) Safety interlock system

B) Observation window

C) Door assembly

D) Oven cavity

E) Control panel

PRODUCT INSTALLATION

Countertop Installation

Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.

Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the Waveguide cover that is attached to the oven cavity to protect the magnetron.

Installation

1. Select a level surface that provide enough open space for the intake and/or outlet vents.
2. The minimum installation height is 85cm.
3. The rear surface of appliance shall be placed against a wall. Leave a minimum clearance of 30cm above the oven. A minimum clearance of 20cm is required, between the oven and any adjacent walls.
4. Do not remove the legs from the bottom of the oven.
5. Blocking the intake and/or outlet openings can damage the oven.
6. Place the oven as far away from radios and TV as possible. Operation of microwave oven may cause interference to your radio or TV reception.

1. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating label.

WARNING

Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the oven could be damaged and the warranty would be void.

The accessible surface may be hot during operation.

OPERATION INSTRUCTIONS

Control Panel

Standby Mode

(1) When the microwave oven is plugged into an outlet, "O" shows on the display. The Buzzer sounds.
(2) In the setting or pause state, press “Pause/Cancel” once to enter the standby mode.
(3) Once the cooking settings are configured, if “ ” is not pressed within 5 minutes, the oven will return to standby mode. The setting is invalid.

Microwave Heating

(1) Press "Microwave" once and then "100" and "1m00s" will display.
(2) Turn the knob to adjust the cooking time. The maximum time value is "1h35m".
(3) Press “ ” to start heating.

NOTE

(1) During the heating process, turning the knob allows for direct time adjustment and immediate operation.
(2) The beeping only occurs on the first rotation of the knob.

Air Fry

(1) Press “Air Fry” once to enter the air fry function, the default temperature“ 180°C ” will display.
(2) Turn the knob to set the temperature. The maximum temperature value is "240°C".
(3) Press “ ” to confirm the temperature.
(4) Turn the knob to set the temperature. The maximum time value is "1h35m".
(5) Press “ ” to start cooking.

Preheat Function

(1) Press “Function” once to enter the Preheat function, the default temperature “150°C” will display.
(2) Turn the knob to set the temperature. The maximum temperature value is “230°C”.
(3) Press “ ” to start preheating.
(4) When preheating is completed, the oven will sound.
(5) Open the door and place food in the oven, and then close the oven door, and based on the set preheating temperature, switch to the corresponding function mode.

NOTE

After preheating is complete without opening the oven door, it will keep warm for 1 hour.

Every 10 minutes, the oven will sound and then return to standby mode.

Grill Cooking

(1) Press “Function” twice to enter the grill cooking function, the default temperature “150°C” will display.
(2) Turn the knob to set the temperature. The maximum temperature value is “230°C”.
(3) Press “ ” to confirm the temperature.
(4) Turn the knob to set the time. The maximum time value is "1h35m".
(5) Press “ ” to start cooking.

NOTE

The buzzer will sound to remind you to turn the food over during grill cooking. If no operation, the oven will continue working.

Combination Cooking

(1) Press “ Function ” thrice to enter the combination cooking function, the default time “ 30:00 ” will display.

(2) Turn the knob to select the time. The maximum time value is "1h35m".

(3) Press “ ” to start cooking.

Microwave Cooking

5 power levels are available.

Power	100% 80%	50% 30%	10%
Display	100% 80%	50% 30%	10%

(1) Press “Function” four times to enter the microwave cooking function, the default power “100%” will display.

(2) Turn the knob to set the power level and then press “ ” to confirm. (3) Turn the knob to adjust the cooking time. The maximum time value is “1h35m”.

(4) Press “ ” to start cooking.

Re-Crisp Function

(1) Press “Function” five times to enter the re-crisp function, the default temperature “230°C” will display.

(2) Turn the knob to select the time. The maximum time value is "1h35m".

(3) Press “ ” to start cooking.

NOTE

The buzzer will sound to remind you to turn the food over during cooking. If no operation, the oven will continue working.

Auto Menu

(1) In standby mode, press “Auto Menu” once and then the screen will display “01”.
(2) Turn the knob to choose the menu you need. 30 auto menus are available.
(3) Press “ ” to confirm.
(4) Press “ ” to start cooking.

Auto Menu chart

Menu	Weight/ Time	Display	Power	Reminder
01New Orleans Style Chicken Wings	500g	500g	AirFry 230°C	the buzzer will sound during cooking to remind you to turn the food over
02Roasted Sweet Potato	1000g	1.0kg	Grill 230
03Salt and Pepper Prawns	400g	400g	AirFry 240	----
04Grilled Chicken Sausage	400g	400g	Grill 220°C	the buzzer will sound during cooking to remind you to turn the food over
05Chicken Breast with Black Pepper	250g	250g	Grill 230°C
06French Fries	250g	250g	AirFry 230°C
07Fried Chicken Fillets	280g	280g	AirFry 230°C
08Coconut Bread Loaf	100g	100g	Grill 150°C
09Fried Chicken Drumsticks	350g	350g	AirFry 230	the buzzer will sound during cooking to remind you to turn the food over
10Honey Chestnut	500g	500g
11Deep-fried Peanuts	200g	200g
12Fried Calamari	220g	220g
13Fried Cheese Strips	320g	320g
14Lava Toast	100g	100g	Grill 180
15Chiffon Cake	8 inches (500g)	500g	AirFry 170°C	----
16Chocolate Cup Cake	6(270g)	270g	AirFry 190°C
17Cranberry Cookies	400g	400g	AirFry 155
18Whole Wheat Bread	1(600g)	600g	AirFry 190
19Garlic Bread	160g	160g	Grill 230	the buzzer will sound during cooking to remind you to turn the food over
20Roast Chicken 📊	1300g	1.3kg	Microwave 80%+ AirFry 230°C
21Cumin Lamb 📊 Chops	500g	500g	Microwave 100%+ AirFry 230°C
22 Roast Beef	300g	300g	Microwave 100%+ AirFry 230°C	the buzzer will sound during cooking to remind you to turn the food over
23 Baked Frozen Pizza	340g	340g	Microwave+Grill	----
24 Steamed Fish with Soy Sauce	200g	200g	80%
	300g	300g
	400g	400g
	500g 500g
	600g 600g
25 Mapo Tofu	200g	200g
	300g	300g
	400g	400g
	500g 500g
	600g	600g
26 Fast Defrost	100-2000g	100g-2.0kg	----	the buzzer will sound during defrosting to remind you to turn the food over
27 Butter Softening	100g	100g	10%	----
28 Fermentation	5s-12hours	5s-12h00m	----	When the oven temperature is above 60°C and then the screen will display “F01”.
29 Cavity Deodorization	5s-95min	5s-1h35min	----	To remove the odor of the oven, the oven will work with fan.
30 Microwave Sterilization	3min	3m00s	----	Before sterilizing, please moisten the utensils.

NOTE

When using auto menus with microwave output, in-house grill rack can be used. Please do NOT put the air fry basket or any other metal accessories into the cavity.

refers to auto menu with microwave, please do NOT use metal accessories.

More Functions

10-1 Steamed Fish with Soy Sauce/Mapo Tofu

(1) In standby mode, press "Auto Menu" once and then the screen will display "01".
(2) Turn the knob to choose the menu 24/25. "24"/ "25" will display.
(3) Press “” to confirm. Start
(4) Turn the knob to set the weight.
(4) Press “Confirm” to start cooking.

10-2 Fast Defrost

(1) In standby mode, press "Auto Menu" once and then the screen will display "01".
(2) Turn the knob to choose the menu 26, "26" will display.
(3) Press “” Confirm to confirm the menu. Start
(4) Turn the knob to set the weight. The range of weight is 100g to 2.0kg.
(5) Press “” Confirm to start defrosting. Start

NOTE

The buzzer will sound during defrosting to remind you to turn the food over. If no operation, the oven will continue working.

10-3 Butter Softening

(1) In standby mode, press "Auto Menu" once and then the screen will display "01".
(2) Turn the knob to choose the menu 27, "27" will display.
(3) Press “” Confirm to confirm the menu. Start
(4) Turn the knob to enter the weight, the default weight "100g" will display.
(5) Press “ ” Confirm to start softening. Start

10-4 Fermentation

(1) In standby mode, press "Auto Menu" once and then the screen will display "01".
(2) Turn the knob to choose the menu 28, "28" will display.
(3) Press “ ” to confirm the menu.
(4) Turn the knob to set the temperature. The range of temperature is 25^ C- 45^ C.
(5) Press “ ” to confirm the temperature.
(6) Turn the knob to set the time, the maximum value is "12h00m".
(7) Press “ ” to start cooking.

NOTE

When the oven temperature is above 60^ C and then the screen will display "F01".

10-5 Cavity Deodorization

(1) In standby mode, press "Auto Menu" once and then the screen will display "01".
(2) Turn the knob to choose the menu 29.
(3) Press “ ” to confirm.
(4) Turn the knob to set the time, the maximum value is "1h35m".
(5) Press “ ” to start.

NOTE

To remove the odor of the oven, the oven will work with fan.

10-6 Microwave Sterilization

(1) In standby mode, press "Auto Menu" once and then the screen will display "01".
(2) Turn the knob to choose the menu 30.
(3) Press “ ” to confirm the mode.
(4) Press “ ” to start for 3m00s.

NOTE

Before sterilizing, please moisten the utensils.

Wireless Connection

Connect the network

In standby state, press and hold “Pause/Cancel” for 3 seconds, till a beep sounds, “AP” will display. If it fails, "NO" will display, and the oven will return to standby after 30 seconds.

Disconnect from the network

Press and hold “Pause/Cancel” for 8 seconds, till a beep sounds, “--” displays for few seconds, if the link has been removed successfully, the screen will display “8888” and then return to standby after 3 seconds. If it fails, “FFFF” will display, and the oven will return to standby after 3 seconds.

APP SETUP AND OPERATION

Quick Start Guide

CONNECT YOUR DEVICE TO YOUR MOBILE PHONE WITH SmartHome App

Download the SmartHome App

Scan QR code or find us on your App store

Register and log in

Log in for existing users or sign up for new users

Connect your devices to SmartHome

STEP1. Connect to wireless network and enable Bluetooth

STEP2. Open the SmartHome App. Power on selected device

STEP3. Add your device using one of the following methods:

STEP4. Ensure device and App are under same wireless network.

STEP5. Press " 🔺 " button for 3 seconds on the panel. Following instruction to set up, it will connect automatically.

Quick Tips

• Make sure your devices are powered on.
- Keep your mobile phone close to your device during connection.
- Connect your mobile phone to the wireless network at home.
- Enable the 2.4GHz frequency on your wireless network router. Contact the manufacturer if unsure whether the router supports 2.4GHz.
• The device is unable to connect to wireless network that requires authentication and also appears in public areas such as hotels and restaurants.
- It is recommended to use a wireless network name that only contains letters and numbers. If your wireless network name contains special characters, modify it in the router. Disable WLAN+ (Android) or WLAN Assistant (iOS) when connecting your devices to the network.
- To reconnect a device to the wireless network, click "+" on the App home screen and add the device again by the category and model according to the App prompts.

CLEANING AND MAINTENANCE

Be sure to unplug the appliance from the power supply.

- Clean the cavity of the oven after using with a slightly damp cloth.

- Clean the accessories in the usual way in soapy water.

- The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.

- Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.

- Cleaning Tip---For easier cleaning of the cavity walls that the food cooked can touch: Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on 100%microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.

TROUBLE SHOOTING

Normal
Microwave oven interfering TV reception	Radio and TV reception may be interfered when microwave oven operating. It is similar to the interference of small electrical appliances, like mixer, vacuum cleaner, and electric fan. It is normal.
Dim oven light	In low power microwave cooking, oven light may become dim. It is normal.
Steam accumulating on door, hot air out of vents	In cooking, steam may come out of food. Most will get out from vents. But some may accumulate on cool place like oven door. It is normal.
Oven started accidentally with no food in.	It is forbidden to run the unit without any food inside. It is very dangerous.

Trouble Possible	Cause Remedy
Oven cannot be started.	(1) Power cord is not plugged in tightly.	Unplug. Then plug again after 10 seconds.
	(2) Fuse blowing or circuit breaker works.	Replace fuse or reset circuit breaker (repaired by professional personnel of our company)
	(3) Trouble with outlet.	Test outlet with other electrical appliances.
Oven does not heat.	(4) Door is not closed well.	Close door well.

Symbol of a trash bin crossed out by two diagonal lines, with no text or numbers present.

According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time in future you need to dispose of this product please do NOT dispose of this product with household waste. Please send this product to WEEE collecting points where available.

TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT

Midea logo, word marks, trade name, trade dress and all versions thereof are valuable assets of Midea Group and/or its affiliates (“Midea”), to which Midea owns trademarks, copyrights and other intellectual property rights, and all goodwill derived from using any part of an Midea trademark. Use of Midea trademark for commercial purposes without the prior written consent of Midea may constitute trademark infringement or unfair competition in violation of relevant laws.

This manual is created by Midea and Midea reserves all copyrights thereof. No entity or individual may use, duplicate, modify, distribute in whole or in part this manual, or bundle or sell with other products without the prior written consent of Midea.

All the described functions and instructions were up to date at the time of printing this manual. However, the actual product may vary due to improved functions and designs.

DATA PROTECTION NOTICE

For the provision of the services agreed with the customer,

we agree to comply without restriction with all stipulations of applicable data protection law, in line with agreed countries within which services to the customer will be delivered.

Generally, our data processing is to fulfil our obligation under contract with you and for product safety reasons, to safeguard your rights in connection with warranty and product registration questions. In some cases, but only if appropriate data protection is ensured, personal data might be transferred to recipients located outside of the European Economic Area.

Further information are provided on request. You can contact our Data Protection Officer via [e-mail]. To exercise your rights such as right to object your personal date being processed for direct marketing purposes, please contact us via [e-mail]. To find further information, please follow the QR Code.

make yourself at home

Line drawing of a microwave oven with front panel and control panel (no text or symbols)

微波炉

3D rendering of a rectangular metal tray with mesh pattern and two side handles (no text or symbols)

Simple line drawing of a metal grate with four legs and vertical supports (no text or symbols)

A) 安全联锁系统

D) 炉腔

B) 观察窗

E) 控制面板

C) 门组件

产品安装

台面安装

Warning symbol of steam inside a triangle (no text or numbers)

微波炉运行期间，可接触表面会变热。

使用方法

控制面板

Microwave 微波

Air Fry 空气炸

Function 功能

Auto Menu 自动菜单

Pause/ Cancel 暂停 / 取消

3Sec. 3秒

Confirm 确定 Start 开始

待机模式

功率	100%	80%	50%	30%	10%
显示	100%	80%	50%	30%	10%

Symbol of a trash bin crossed with a diagonal line, representing waste or discharge (no text or numbers present)

make yourself at home
