USER MANUAL SE-72014L-B Sven

This Manual and information contained in it are copyrighted. All rights reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The information of this Manual is given on “as is” terms. The author and the publisher do not bear any liability to a person or an organization for loss or damages, which have arisen from the information contained in the given Manual.

PURPOSE

SE-72014L-B surface-mount doorbell switch illuminated is designed for electrical circuits switching.

FEATURES

• Non-flammable ABS plastic case
- Mountable on various surfaces: wood, plasterboard, plastic, etc.
- Dust- and waterproof, IP54 protection class
• Enhanced design of cable terminals
- Wires can be put in from the top and bottom
- Rubber cable seals
- Illuminating for convenient use in dark environment

• Items should be installed and connected by qualified specialists only.
• Items should be connected according to the connection diagram given on the item backside.
• Avoid the item overload for its damage. The peak acceptable current value of the load is indicated on its backside.
• Avoid ingress of foreign objects inside the item case.

TECHNICAL SPECIFICATIONS

Dimensions, mm	72 × 72
Peak current, A	10
Peak voltage, V	250

Notes:

• Technical specifications given in this table are supplemental information and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to the improvement of SVEN production.

White rectangular electronic device with a black screen and a red button, no visible text or symbols.
