PHN-AC18DCPB - Hair Dryer HYUNDAI - Free user manual and instructions

Product Type	Hair Dryer
Model	PHN-AC18DCPB
Brand	Hyundai
Motor Type	AC Motor
Power Consumption	2000 W
Voltage	220-240 V, 50/60 Hz
Heat Settings	3 levels (Cool, Warm, Hot)
Speed Settings	2 levels (Low, High)
Cool Shot Button	Yes
Concentrator Nozzle	Included
Diffuser	Included
Removable Filter	Yes, rear filter
Overheat Protection	Auto shut-off
Hanging Loop	Yes
Dimensions (approx.)	25 x 8 x 10 cm (LxWxH)
Weight (approx.)	0.5 kg
Cable Length	1.8 m
Ion Technology	No
Color	Black/Silver
Warranty	1 year

Frequently Asked Questions - PHN-AC18DCPB HYUNDAI

How do I clean the filter on my Hyundai PHN-AC18DCPB hair dryer?

Unplug the dryer. Remove the rear filter cover by twisting it counterclockwise. Use a soft brush or cloth to remove lint. Reattach the cover securely.

Can I use the cool shot button while drying?

Yes, press the cool shot button to release a burst of cool air to set your hairstyle. It works regardless of the heat setting.

What does the overheat protection do?

If the dryer gets too hot, it automatically shuts off to prevent damage. Let it cool down for a few minutes before restarting.

Is the diffuser suitable for curly hair?

Yes, the included diffuser helps distribute air evenly, reducing frizz and enhancing natural curls.

What is the voltage range for this hair dryer?

It operates on 220-240V, 50/60Hz. Do not use with a voltage converter unless specified.

How do I attach the concentrator nozzle?

Align the nozzle with the front of the dryer and push it on until it clicks. To remove, pull it off gently.

Can I use the hair dryer in the bathroom?

Avoid using near water. Keep it away from bathtubs, sinks, or other water sources to prevent electric shock.

How long is the power cord?

The cord is approximately 1.8 meters long, giving you flexibility during use.

What is the warranty period?

Hyundai offers a 1-year warranty for this hair dryer against manufacturing defects.

Why does my hair dryer stop during use?

It may have tripped the overheat protection. Unplug it, let it cool for 10 minutes, and check the filter for blockages.

USER MANUAL PHN-AC18DCPB HYUNDAI

GENJINE PRODUCT OF HYUNDAI CORPORATION

Thank you for purchasing the hair dryer PHN-AC18DCPB, equipped with a powerful AC motor, allows to quickly and easily realize different type of hairstyles. Read carefully all the instructions before using the unit and maintain this manual for future references.

IMPORTANT SAFETY INSTRUCTIONS

1. When the hair dryer is used in the bathroom, unplug it after use since water represents a risk even when the hairdryer is switched off.
2. Always disconnect the hair dryer from the power supply when not in use and before cleaning.

1. WARNING Do not use this appliance near bathtubs, showers, basins or other water containers.

2. Do not immerse the product in water or other liquids.

3. If the device has fallen into water DO NOT TRY TO RECOVER IT! Disconnect the product from the electrical outlet. Do not use it again until the product has been inspected and approved by a qualified electrician.

4. Remove the packaging before use. Keep all packaging (plastic bags, cardboard, etc.) out of reach of children as they are potentially dangerous and should be disposed of as required by law.

CAUTION: To reduce the risk of burns, fire or personal injury:

- Before connecting the device to the power outlet, make sure the voltage on the rating label corresponds to the local mains voltage.

- Do not leave the product unattended when not in use.

- Close supervision is necessary when the appliance is used near children or people with reduced physical, sensory and mental capabilities.

- The use, cleaning, or maintenance of the appliance by children over eight years of age or by anyone with no knowledge, experience or reduced physical and sensory abilities should not be carried out without first having received appropriate instructions and under the supervision of an adult responsible for their safety and fully aware of the associated risks.

- Cleaning and maintenance operations should not be carried out by children without supervision.

• This product is not a toy. Children should not play with the appliance.

- Do not use the appliance for purposes different from those indicated in this instruction manual. Any other use is considered improper and therefore dangerous.

- Do not use the appliance if the cord or plug are damaged, if the

product does not work properly, if it has fallen or has been damaged in any way or has dropped in water. Contact the authorized after sales service immediately for possible repair.

• If the power cord is damaged, it must be replaced by the manufacturer or its representative or a qualified person in order to avoid any dangerous situations.
• Do not tamper with the product trying to repair or replace damaged parts. All repairs should be performed only by authorize personnel; otherwise the warranty will expire.
• Keep the cable away from heat sources.
• Do not obstruct the ventilation points and do not place the appliance on a soft surface such as a bed, pillow, or sofa. Do not store the product when operating under a blanket or pillow. When turned off, put the appliance on heat-resistant surfaces only.
• Do not obstruct the ventilation points and do not place the appliance on a soft surface, such as a bed, pillow, or sofa. Do not store the product when operating under a blanket or pillow. When turned off, put the appliance on heat-resistant surfaces only.
• Do not use the appliance while sleeping or drowsy.
• Do not block the ventilation points to prevent the unit from overheating.
• Do not use the product outdoors and do not spray aerosol products when the dryer is running.
• Do not direct hot air to eyes or other areas that are sensitive to heat.
• Do not leave the appliance on any surface while it is operating or when the switch is turned on.
  • This product is intended for household use only.
• Do not twist or weave the cable and do not wrap it around the appliance.
• Keep the product and its accessories away from heat sources.
  • Always turn off the product after use.
• Store the product in a cool and dry place. Do not use the product with wet hands. Make sure the plug and the power cable do not get wet.
• For additional protection, we recommend installing a residual current device (RCD) with a rated residual operating current not exceeding 30 mA in the electrical circuit supplying the bathroom. Ask your installer.
• CAUTION: Neither switch on nor use the hair dryer without the rear filter. Before use, always make sure the filter is fixed firmly.

PRODUCT DESCRIPTION:

A. Concentrator

B. Air intake cover

C. Cold air shot

D. Temperature settings

E. Speed settings

F. Power cord

G. Hanging loop

H. Diffuser

USE THE HAIR DRYER

1. Set the desired flow:

Position 0: OFF

Position ✦ medium flow, medium temperature for gentle drying and styling.

Position × maximum flow, high temperature for quick drying.

1. After turning on the hair dryer, set the temperature as below:

Low Medium High

1. For a shot of cold air, press and hold the button for the cold shot, otherwise release it for the normal flow of warm air.

2. If for any reason the hairdryer stops working, unplug it immediately and allow it to cool.

3. Always make sure the switch is in the OFF position before plugging the unit into the power outlet.

STYLING TIPS. HAIR DRYING BASICS

1. Use shampoo and hair conditioner, and rinse thoroughly. Towel dry hair to remove excess moisture. Divide hair into sections and, using the blow dryer in conjunction with a styling brush, direct the hot air through one section of hair at a time. Direct the air steadily over each section so that it passes through the hair. The flow should be aimed at the hair, not the scalp.

2. Keep the vents clear of obstructions and free from hair during use.

3. To avoid over-drying, do not concentrate heat for an extended period of time but use continuous movements when styling.

4. For quick styling, moisten hair with a mist of water before styling with a hairdryer.

5. When using the hair dryer to create curls and waves, dry the hair almost completely using the hottest temperature setting, followed by the lowest setting. In this way the fold will be well fixed.

6. Package includes one concentrator. Use the concentrator when you need to focus flow on a small area (like a curl or wave) or to lay down curly hair.

CLEANING

1. The exterior of the appliance can be cleaned with a dry cloth.

2. The accessories (concentrators) can be cleaned with a damp cloth or rinsed under running water.

Remove the accessories from the appliance before cleaning it. Make sure the accessories are dry before using or storing them.

Do not wash the appliance with running water.

STORAGE

When the appliance is not in use, disconnect it from the mains.

Let the appliance cool down and store it in a dry place. This hair dryer is equipped with a ring for hanging it on a hook. Do not wrap the cord around the appliance to avoid damaging the cord.

RATING LABEL:

This product complies with all applicable European directives.

ance with class II electrical insulation

Do not immerse the appliance in liquids and do not use it near the bathtub. Do not place it on countertops or surfaces where it could fall into the sink or other container containing water.

INFORMATION TO USERS according to Legislative Decree No. 49 of March 14, 2014 “2012/19/UE Implementation of the Directive on Waste Electrical and Electronic Equipment (WEEE)”

The crossed-out dustbin symbol indicates that the product at the end of its life must be collected separately from other waste.

The user should, therefore, take the equipment with the essential components at the end of its useful life to the separate collection center of electronic and electrical waste, or return it to the retailer when purchasing new equipment of equivalent type, in ratio of one to one, or one to zero for devices with larger side less than 25 CM.

The separate collection for the decommissioned equipment for recycling, treatment and environmentally compatible disposal contributes to avoid possible negative effects on the environment and human health and promotes recycling of the materials.

Improper disposal of the product by the user entails the application of administrative sanctions according to Legislative Decree No. 49 of 14 March 2014

REV. 12.2023

HYUNDAI

HYUNDAI

MADE IN CHINA

Email: [e-mail]

Sito Web: www.hyundai-electronics.it
