| Product Type | Freestanding Fridge-Freezer |
| Dimensions (H x W x D) | 1860 x 700 x 660 mm |
| Net Weight | approx. 75 kg |
| Total Net Capacity | 401 L |
| Fridge Capacity | 257 L |
| Freezer Capacity | 144 L |
| Energy Efficiency Class | A+++ |
| Annual Energy Consumption | 262 kWh |
| Noise Level | 38 dB(A) |
| Power Supply | 220-240 V, 50 Hz, 160 W |
| Freezer Features | NoFrost, Fast Freeze, Ice Maker |
| Fridge Features | SuperCool, MultiAirflow, LED Lighting |
| Special Modes | Holiday Mode, Eco Mode |
| Control System | Electronic Controls with LED Display |
| Opening Angle | 90° |
| Reversible Door | Yes |
| Shelving Material | Tempered Glass |
| Interior Lighting | LED |
| Refrigerant | R600a |
| Climate Class | SN-T |
| Maintenance | Clean with mild detergent and soft cloth |
| Spare Parts Availability | Directly from Siemens Customer Service |
| Warranty | 2 years (may vary by region) |
Frequently Asked Questions - KG76NAI4PL SIEMENS
How do I set the temperature on my Siemens KG76NAI4PL fridge-freezer?
To set the temperature, use the control panel on the front. Press the fridge or freezer button and adjust using the +/- buttons. Recommended settings: fridge 4°C, freezer -18°C.
Does the KG76NAI4PL have a NoFrost system?
Yes, the freezer compartment features NoFrost technology, which prevents ice buildup and eliminates the need for manual defrosting.
What is the total capacity of this refrigerator?
The Siemens KG76NAI4PL has a total net capacity of 401 liters, with 257 liters for the fridge and 144 liters for the freezer.
How do I activate the SuperCool function?
Press the 'SuperCool' button on the control panel. This rapidly cools the fridge compartment to quickly chill food. It turns off automatically after about 6 hours.
What should I do if the door alarm sounds?
The door alarm sounds if the door is open for more than 2 minutes. Close the door firmly. If the alarm persists, check the door seal for obstructions.
How often should I clean the condenser coils?
Clean the condenser coils at least once a year using a brush or vacuum cleaner. Dust buildup reduces efficiency and may cause the compressor to work harder.
Can I change the door opening direction?
Yes, the door is reversible. Follow the instructions in the manual to change the hinge side. You may need a screwdriver and help from another person.
What is the noise level of this model?
The Siemens KG76NAI4PL operates at a noise level of 38 dB(A), which is very quiet and barely audible in normal household conditions.
Where can I find spare parts?
Spare parts can be ordered from Siemens customer service or through authorized service centers. Use the model number KG76NAI4PL when ordering.
How do I enable Holiday Mode?
Press the 'Mode' button until 'Holiday' appears on the display. This mode adjusts the fridge temperature to a higher setting to save energy while you're away.
