CK53UCF - Range hood Emilia - Free user manual and instructions

Product Type	Under-cabinet range hood
Model	CK53UCF
Brand	Emilia
Dimensions (mm)	W520 x D315 x H250
Rated Voltage	230V
Rated Frequency	50Hz
Total Power	234W
Motor Power	230W
Light Power	2 x 2W LED
Motor Quantity	1
Outlet Diameter	150mm (120mm reducer optional)
Min. Distance to Gas Hob	750mm
Min. Distance to Electric Hob	650mm
Grease Filter	Aluminum, washable
Charcoal Filter	Optional, replace every 3 months
Controls	Push-button, 3 fan speeds + light switch
Lighting	2 x LED lamps (AC 230V, 2W max)
Installation Type	Ducted only
Material	Stainless steel
Warranty	24 months domestic use
Safety Features	Thermal protection, automatic shut-off in case of overheat
Cleaning	Damp cloth and neutral detergent; filters washable in dishwasher

Frequently Asked Questions - CK53UCF Emilia

What is the minimum installation height above a gas hob?

The minimum distance from the hob surface to the bottom of the hood must be at least 750mm for gas hobs and 650mm for electric hobs. Always check your hob's manual for specific requirements.

Can I use the hood in recirculation mode?

No, the Emilia CK53UCF is designed for ducted installation only. It must be connected to an external exhaust duct to expel air outside. Charcoal filters are available for optional recirculation, but the hood requires a duct connection.

How often should I clean the grease filters?

Under normal usage, clean the aluminum grease filters every 2 months. For heavy use, clean more frequently. They can be washed with warm detergent solution or in a dishwasher. Allow them to dry completely before reinstallation.

How do I replace the LED lamps?

First, disconnect the hood from power. Push the LED lamp from the inside to release it. Disconnect the wire terminal and replace with a new AC 230V, 2W Max LED lamp of the same type. Ensure the lamp is securely connected before reassembly.

What should I do if the hood vibrates or makes loud noise?

Check if the hood is installed securely according to the manual. Tighten all mounting screws. Ensure duct joints are properly connected. If noise persists, inspect for loose components or damaged ductwork.

Why is the extraction performance poor?

Possible causes: the distance from hob is too large (ideal 65-75cm), duct is blocked, filters are clogged, or room ventilation is inadequate. Clean or replace filters, clear duct obstructions, and ensure windows or doors are open slightly for air intake.

Can I use an extension cord for the power supply?

No, do not use an extension cord. The hood must be connected directly to a suitable 230V power outlet. If the supply cord is damaged, it must be replaced by a qualified technician to avoid hazard.

What is the recommended duct diameter?

The hood is designed for 150mm round duct. A reducer to 120mm is available if needed. Keep duct runs as short and straight as possible with minimal bends for best performance.

How do I activate the warranty?

Complete and return the registration card to Glem Gas Australasia within the specified period. Provide proof of purchase and ensure installation was done by a licensed technician. The warranty covers domestic use for 24 months.

Can I flambé food under the hood?

No, flambéing under the hood is strictly prohibited. Open flames can damage the filters and pose a fire hazard. Always use the hood with moderate heat and avoid high naked flames.

USER MANUAL CK53UCF Emilia

COOKER HOOD INSTRUCTION MANUAL AND

INSTALLATION GUIDE

Please read this guide before installing and using the hood

MODEL

DESCRIPTION

CK53UCF UNDERCUPBOARD RANGEHOOD

CK75UCF UNDERCUPBOARD RANGEHOOD

EMILIA

GLEM

Emilia Glem Appliances

Unit 26 10 Straits Avenue South Granville NSW 2142

PO BOX 63 Blaxcell PO South Granville NSW 2142

Tel [phone]

Fax [phone]

www.glemgas.com.au

Dear Customer,

If you follow the recommendations contained in this Instruction Manual, our appliance will give you constant high performance and will remain efficient for many years to come.

CONTENTS

RECOMMENDATIONS AND SUGGESTIONS

CHARACTERISTICS INSTALLATION & USE MAINTENANCE

TROUBLE SHOOTING

Product Specification & Technical Parameters

Model	CK53UCF/CK75UCF
Rated Voltage	230V
Rated Power Frequency	50Hz
Light Power	2x2W (LED)
Motor Power	230W
Total Power	234W
Motor	1
Diameter of Outlet Adapter	150mm
Dimension (mm)	W520/750 x D315x H250

RECOMMENDATIONS AND SUGGESTIONS

INSTALLATION

* The manufacturer will not be held liable for any damages resulting from incorrect or improper installation.
* Please read this instruction manual before installing and using this rangehood. Please keep this instruction manual in a safe place for future reference.

* Only a qualified and trained service technician can undertake the work of installation and servicing.

* Check that the main voltage corresponds to the one indicated on the rating plate fixed inside the hood.

* Do not connect the hood to exhaust ducts carrying combustion fumes (boilers, fireplaces, etc.)

* If the hood is used in conjunction with non-electrical appliances (e.g. gas burning appliances), a sufficient degree of ventilation must be guaranteed in the room in order to prevent the backflow of exhaust gas. The kitchen must have an opening directly with the open air in order to guarantee the entry of clean air.

* The minimum distance is 750mm from the cooker hood to a gas hob, and is 650mm to an electric hob. If the installation instructions for gas hobs specify a greater distance, this must be taken into account.

NOTICE: Two or more people are required to install or move this appliance. Failure to do so can cause physical injuries.

USE

* The rangehood has been designed only for domestic use to eliminate kitchen fumes.

* Never use the hood for purposes other than what it has been designed for. * Never leave high naked flames under the hood when it is in operation. * Adjust the flame intensity to direct it onto the bottom of the pan only; making sure that it does not engulf the pan sides.

* Deep fryer fat must be continuously monitored during use: overheated oil can burst into flame.

* The hood should not be used by children or person not instructed in its correct use.

MAINTENANCE

* Proper maintenance of the rangehood will assure proper performance of the unit.

* Disconnect the hood from the main supply before carrying out any maintenance work.

* Clean and/or replace aluminum grease filters and activated charcoal filters after specified period of time.

* Clean the hood using a damp cloth and a neutral liquid detergent.

* DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary.

WARNING!!

In certain circumstances electrical appliances may be a danger hazard.

* Do not check the status of the filters while the rangehood is operating.
* Do not touch the light bulbs after appliance use.
* Do not disconnect the appliance with wet hands.
* Avoid free flame, as it is damaging for the filters and a fire hazard.
* Constantly check food frying. Overheated oil may become a fire hazard. * Disconnect the electrical plug prior to any maintenance.
* Children don't recognize the risks of electrical appliances. Therefore use or keep the appliance only under supervision of adults and out of the reach from children.
* Don't use this product outdoors.
* This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction, concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
* There should be adequate ventilation of the room where the range hood is used at the same time as appliances burning gas or other fuels. * There is a fire risk if cleaning is not carried out in accordance with instructions.
* Do not flambé under the rangehood.
* The exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances burning gas or other fuels.

CHARACTERISTICS

DIMENSIONS

INSTALLATION & USE

Note 1 : On stainless steel hoods, carefully remove the plastic protective film from all exterior surfaces of the hood prior to final installation.

Note 2: At least two people will be required to mount the hood.

DESCRIPTION / CONNECTIONS

The hood is only installed in the Ducting version. The hood draws cooking fumes saturated with fumes and odour through the grease filters and expels it to the outside through an outlet pipe.

Caution: To reduce the risk of fire, use of metal ductwork is preferred. Do not use flammable material to convey exhaust air.

1. Decide where the ductwork will run between the hood and the outside.

2. A straight, short duct run will allow the hood to perform most efficiently.

3. Long duct runs, elbows, and transitions will reduce the performance of the hood. Use as few of them as possible. Larger ducting may be required for best performance with longer duct runs.

4. It is recommended that 150mm round duct is to be used, however a reducer from 150mm to 120mm can be ordered supplied should 120mm be required.
5. The air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels. Regulations concerning the discharge of air have to be followed. Check with the local authority and building code for exhaust ducting requirements.
6. Install a roof/wall cap. Connect round ductwork to cap and work back towards hood location.

Electrical Connection

* Electrical wiring must be done by a qualified person(s) in accordance with all applicable codes and standards. Turn off electrical power at service entrance before wiring.

* If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. * Do not use the plug and an extension cord other than the ones initially supplied with the hood.

INSTALLATION

Before beginning installation, to better handle the hood, we advise removing the face plate.

1. Attach the air outlet adapter over the hood. Tighten it with 4 screws.
2. The range hood is designed to operate with 150mm exhaust Ducting.

DUCTING VERSION INSTALLATION:

Before fixing, the outlet exhaust duct for air evacuation to the outside must be installed. Use an outlet exhaust duct with: - minimum indispensable length; - Minimum possible bends (maximum angle of bend: 90°); - certified material (according to local, building and fire regulations); and as smooth as possible inside. It

Technical line drawing of a mechanical component with a cylindrical shaft and base, showing a downward force arrow (no text or symbols)

is also advisable to avoid any drastic changes in duct cross-section

(recommended diameter: 150mm).

Fitting under wall unit

1. Before fixing the hood to the unit, drill a hole of 165mm diameter for φ150mm exhaust Ducting or 135mm for φ120mm exhaust Ducting in the wall unit.

2. In any case, check the position of the power outlet and consider where the power cable will run, since a hole might have to be made in the wall unit to accommodate it.

3. Unscrew the 2 visible screws located on hood of both the side-ends and remove the face plate. The 8 mounting holes around the unit are then accessible.

4. Lift the rangehood and fit through the opening of the cabinet. Secure unit by using 8 long mounting screws. Fit the face plate on the hood by screwing 2 screws.

5. Make the electrical connection.

Technical line drawing of a mechanical assembly with internal components (no text or symbols)

Installation is now complete.

Notice:

-Exhaust air must not be discharged into a flue which is used for exhausting fumes from appliance burning gas or other fuels.

-If the instructions for installation for the gas hob specify a greater distance than 750mm, this has to be taken into account.

-The regulations concerning the discharge of exhaust air have to be followed. Check with the local authority for building codes for exhaust ducting requirements

OPERATION

This hood may be operated using the push button on the face plate.

The light switch turns the lamps on and off.

The fan switch turns the fan on to three speed settings:

0 - OFF

1 - LOW SPEED

2 - MEDIUM SPEED

3 - HIGH SPEED

MAINTENANCE

GREASE FILTER

* The grease filters should be cleaned frequently (every two months of operation, or more frequently for heavy use). Use a warm detergent solution.

* Grease filters are washable.

1. push in on the metal latch tab. This will disengage the filter from the hood. Tilt the filter downward and remove.
2. Wash the filters, taking care not to bend them. Allow them to be dry before refitting.
3. To install the grease filter, align rear filter tabs with slots in the hood. Push in the metal latch tab, push filter into position and release. Make sure the filter is securely engaged after assembly.

Line drawing of a microwave oven with control panel and door (no text or symbols)

CHARCOAL FILTER(optional)

This filter is not washable, cannot be regenerated, and should be replaced approximately every 3 months of operation, or more frequently in the case of heavy usage.

1. To install the charcoal filter, lock it until the stop click is heard.

2. Install the face plate after charcoal filter is installed.

3. To remove the charcoal filters, remove the charcoal filter by turning anti-clockwise.

LAMPS

This rangehood may require two LED lamps (AC 230V, 2W Max)

WARNING: Always switch off the electrical supply before carrying out any operation on the appliance.

To change lights:

1. Push the LED lights from inside to outside. The lights will come out.
2. Undo the light wire terminal, and replace with LED lights of same kind.

Line drawing of a microwave oven with internal components and mounting holes (no text or symbols)

CAUTION:

1. THE SURFACE, THE LIGHT COVER MAY BE HOT. TAKE CARE WHEN REPLACING LED LAMPS.

2. THE LED LAMPS MAY BE HOT. TAKE CARE WHEN REPLACING LED LAMPS.

We recommend only using lamps of the same specification as the ones being replaced.

HOOD CLEANING

Stainless steel is one of the easiest materials to keep clean. Occasional care will help preserve its fine appearance.

Cleaning tips:

* Hot water with soap or detergent is all that is usually needed.
* Follow all cleaning by rinsing with clear water. Wipe dry with a clean, soft cloth to avoid water marks.
* For discolorations or deposits that persist, use a non-scratching household cleanser or stainless steel polishing powder with a little water and a soft cloth.
* For stubborn cases use a plastic scouring pad or soft bristle brush together

with cleanser and water. Rub lightly in direction of polishing lines or "grain" of the stainless finish. Avoid using too much pressure that may damage the surface.

* Do not allow deposits to remain for long periods of time.
* Do not use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface causing rust.
* Do not allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in contact with stainless steel for extended periods. Many of these compounds contain chemicals that may be harmful. Rinse with water after exposure and wipe dry with a clean cloth.
* Painted surfaces should be cleaned with warm water and mild detergent only.

TROUBLE SHOOTING

The rangehood may not work or work improperly. Before calling after-sales service, switch off the appliance, unplug the power supply and refer to this guide to determine the problem.

If malfunction persist, contact our After Sales Service and specify the nature of the problem, appliance model no and serial number (on the rating plate inside the hood)

Status	Reasons	Solutions
No response of the lamps and the motor	1. The plug is off from the power socket.2. The power cord is damaged.	1. Ensure that the plug is put into the power socket properly.2. Replace the power cord if the power cord is damaged.
	The fuse on the PCB board is damaged.	Replace the fuse on the PCB board.
	The switch is damaged.	Repair or replace the switch.
The lamp doesn't work	The lamp is damaged.	Replace the damaged lamp.
The hood body gives out strong vibrations and a loud noise	1. The hood has not been installed properly according to the installation process described in the instruction manual.2. Check if the joint connection of each part is damaged.	Ensure the hood has been installed properly according to the instruction manual.
The air exhaust performance is bad	Check if the distance between the hood and the cooker top is too big.	The ideal distance is 65-75cm.
	Ensure there is adequate ventilation.	Open the door and windows properly. Improve the environment.
	The duct is damaged.Grease Filters or charcoal filter cloggedExhaust air outletclogged	Repair or replace the damaged duct.Replace or clean the filtersClear the air exhaust outlet

GLEM GAS AUSTRALASIA PTY. LTD. PRODUCT WARRANTY

Thank you for choosing an Emilia Glem Appliance, the purchase of this appliance is an important investment in your home and so to protect your investment we urge you to complete the registration card attached, please return it immediately.

IT IS A WARRANTY REQUIREMENT THAT PROOF OF PURCHASE BE PROVIDED PRIOR TO REQUESTING A SERVICE CALL. THIS WARRANTY SHALL NOT APPLY IF THE APPLIANCE WAS NOT INSTALLED BY A LICENSED TECHNICIAN AND PROOF IS NOT SUPPLIED.

The benefits conferred by this warranty are in addition to all other conditions and warranties in respect of this product which the consumer may have under the Trade Practices Act 1874 of the Commonwealth of Australia and/or similar State or Territory Laws.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

Glem Gas Australasia Pty Ltd warrants, this appliance to be free from defects in workmanship and materials for a period of:
a) Where the appliance is intended to be used and is used for DOMESTIC USE – 24 MONTHS FROM DATE OF DELIVERY TO THE ORIGINAL PURCHASER.
b) Where the appliance is intended to be used and is used for COMMERCIAL USE - 90 DAYS FROM DATE OF DELIVERY TO THE ORIGINAL PURCHASER.

Glem Gas Australasia Pty Ltd, during the period of warranty, will at its option, and subject to the terms and conditions stated below, repair or replace free of charge this appliance or any component part, which upon examination by Glem Appliances P/L. is found to be defective.

THIS WARRANTY SHALL NOT APPLY:

a) If the rating plate has been removed or the serial number or other details on it have been removed or rendered illegible.
b) If the appliance is connected to any voltage other than shown on rating plate.
c) If the appliance has been subjected to misuse, abuse accident or want of care.
d) If the appliance has been installed, operated or maintained contrary to the instructions supplied by Glem Gas Australasia P/L.
e) If any defect or failure is due to connection to an inadequate or faulty power supply.
f) If damage is caused by foreign objects in or on the appliance or by reason of its use for purposes other than that for which it was delivered.
g) If a repair has been made or attempted by the purchaser.
h) Where the appliance is installed outside an 80km radius from the GPO of any Australian Capital City to freight and travel costs beyond that radius.

This warranty does not cover any glass damage or replacement of light bulbs.

Parts covered under warranty that need replacing i.e.: seals, knobs or filters. These can be posted to customer to put on at their discretion.

This Warranty is given by Glem Gas Australasia Pty Ltd and no other person or organisation is authorised to vary its provisions and conditions.

Complete this section and keep it for your own record.

Please complete the section below and return to:

Glem Gas Australasia Pty. Ltd, PO Box 63 Blaxcell PO South Granville or fax to 02 9721 2766

WARRANTY FORM
