SD4300 - DVD player TOSHIBA - Free user manual and instructions

Product Type	DVD Player
Brand	Toshiba
Model	SD4300
Playable Disc Types	DVD-Video, DVD-R, DVD+R, DVD-RW, DVD+RW, SVCD, VCD, CD, CD-R, CD-RW
Video D/A Converter	108MHz/14-Bit
Component Video Output	ColorStream Pro Progressive Scan
Progressive Scan	3:2 Pulldown Digital Cinema Progressive
JPEG Photo Viewer	Yes
Digital Picture Zoom	Yes
Audio D/A Converter	192kHz/24-Bit
Dolby Digital/DTS Compatible	Yes
MP3 Playback	Yes
Remote Control	Included
Front LED Display	Yes
Screen Saver	Yes
Tray Lock	Yes
Terminals	ColorStream Component Video Output (1 set), RCA Video (1), L-R Audio (1), Coaxial Digital Audio Output (1)
Unit Dimensions (W x H x D)	16.93 x 1.69 x 8.23 in
Unit Weight	3.21 lbs
Carton Dimensions (W x H x D)	18.9 x 3.54 x 11.69 in
Carton Weight	4.52 lbs
UPC Code	022265003152
Energy Star Certified	Yes
Color	Black front panel

Frequently Asked Questions - SD4300 TOSHIBA

What disc formats does the Toshiba SD4300 support?

The SD4300 supports DVD-Video, DVD-R, DVD+R, DVD-RW, DVD+RW, SVCD, VCD, CD, CD-R, and CD-RW. Note that some burned discs may be incompatible due to recording quality or disc design.

Does the SD4300 have progressive scan output?

Yes, it features ColorStream Pro Progressive Scan with 3:2 pulldown for a smoother, more film-like picture on compatible TVs.

Can the SD4300 play MP3 files?

Yes, it supports MP3 playback from CD-R, CD-RW, and DVD discs. However, CD-RW is not recommended for MP3 files due to potential compatibility issues.

What is the video D/A converter specification?

The SD4300 uses a 108MHz/14-bit video D/A converter for high-quality video processing.

Does it support JPEG photo viewing?

Yes, the JPEG Photo Viewer allows you to view digital photos from CD and DVD discs on your television.

What audio outputs does the SD4300 have?

It includes L-R analog audio outputs and a coaxial digital audio output for connection to an AV receiver or soundbar.

What are the dimensions and weight of the unit?

The unit measures 16.93 x 1.69 x 8.23 inches (WxHxD) and weighs 3.21 lbs. The carton dimensions are 18.9 x 3.54 x 11.69 inches and weighs 4.52 lbs.

Is the SD4300 ENERGY STAR certified?

Yes, the product is ENERGY STAR qualified, meeting energy efficiency guidelines set by the U.S. government.

Does it include a remote control?

Yes, a remote control is included for convenient operation.

What is ColorStream Pro?

ColorStream Pro is Toshiba's component video output technology that provides progressive scan video with enhanced color purity and image detail for a superior viewing experience.

USER MANUAL SD4300 TOSHIBA

TOSHIBA

Leading Innovation >>>

ColorStream Pro® and multi-format playback capability make the SD4300 great for watching movies and viewing slideshows of your favorite digital photos.

Exterior view of a TOSHIBA desktop computer (no visible text or symbols on body)

ADVANTAGE

Multi-format playback ^1 capability supports DVD-R, DVD-RW, DVD+R, DVD+RW, VCD, SVCD, CD-R, CD-RW, and MP3 playback for true flexibility.

ColorStream Pro® Progressive Scan Component Video Outputs enhance color purity and image detail.

JPEG Photo Viewer ^1 enables users to view digital photographs from CD and DVD discs on their televisions.

Slim chassis height is combined with a stylish black front panel, and a display designed to complement today's TVs.

PRELIMINARY

SD4300

Specifications

PLAYABLE DISC TYPES ^1

DVD-Video/DVD-R/DVD+R/

DVD-RW/DVD+RW/

SVCD/VCD/CD/CD-R/CD-RW

VIDEO

Video D/A Converter 108MHz/14-Bit

F

Component Video Output ColorStream Pro

Progressive Scan 3:2 Pulldown Digital Cinema Progressive

JPEG •

Digital Picture Zoom •

Fast Scan •

Slow Motion •

Multi-Camera Angle Select

Multi-Language Select •

Mult-Subtitle Select

AUDIO

Audio D/A Converter 192kHz/24-Bit

Dolby® Digital/DTS® Compatible •

MP3 Playback ^1

CONVENIENCE

Remote Control

Front LED Display

Screen Saver

Tray Lock

^1 Some DVD-R/DVD-RW and CD-R/CD-RW discs may be incompatible due to laser pick up and disc design. CD-R/CD-RW discs must be recorded using CD-DA method for CD audio playback. The DVD player may not support some MP3/WMA/JPEG recordings due to differences in recording formats, disc structure, or condition of the disc (use of CD-RW for MP3 files is not recommended). See owner's manual for more information.

TERMINALS

ColorStream ^ Component Video Output	1 set
RCA-Video	1
L-R Audio	1
Coaxial Digital Audio Output	1

PRODUCT & PACKAGING

Unit Dimensions (WHD) in.	16.93 x 1.69 x 8.23
Carton Dimensions	18.9 x 3.54 x 11.69
Unit Weight	3.21 lbs
Carton Weight	4.52 lbs
UPC Code	022265003152

http://www.tacp.toshiba.com Customer Solutions: 800.631.3811

© Toshiba America Consumer Products, L.L.C.

82 Totowa Road, Wayne, NJ 07470 (2009). All Rights Reserved (11/09.3)

ColorStream and ColorStream Pro are registered trademarks of Toshiba America Consumer Products, L.L.C. Dolby and the double-D symbol are registered trademarks of Dolby Laboratories. DTS and the Symbol are registered trademarks & the DTS logos are trademarks of DTS, Inc. ENERGY STAR is a registered mark owned by the U.S. Government.

Product design and specifications subject to change or modification without notice.
