| Product Type | Electric Bike |
| Brand | Fortis |
| Model | FS7MDMBTBMA |
| Frame Material | Aluminum Alloy |
| Wheel Size | 27.5 inches |
| Motor Type | Brushless Rear Hub Motor, 250W |
| Battery Capacity | 36V 14Ah (504Wh) Lithium-ion |
| Charging Time | Approximately 4-6 hours |
| Range (Assist Mode) | Up to 50-80 km (depending on terrain & assistance level) |
| Max Speed | 25 km/h (EU compliant) |
| Transmission | Shimano 7-speed derailleur |
| Brakes | Mechanical Disc Brakes, 180mm rotors |
| Suspension | Front Suspension Fork, 80mm travel |
| Display | LCD Backlit Display with Speed, Battery, Odometer, Assistance Level |
| Pedal Assist Levels | 5 levels (Eco, Tour, Sport, Turbo, Walk) |
| Throttle | Twist Throttle on Right Handlebar |
| Lights | LED Headlight and Rear Reflector |
| Weight (with Battery) | Approximately 24 kg |
| Maximum Load Capacity | 120 kg (including rider and luggage) |
| Frame Size | 18 inches (suitable for riders 165-185 cm) |
| Water Resistance | IPX4 (splash resistant) |
| Warranty | 2 years on frame, 1 year on electrical components |
| Certifications | CE, EN 15194 |
Frequently Asked Questions - FS7MDMBTBMA Fortis
How do I charge the battery on my Fortis FS7MDMBTBMA?
Remove the battery from the bike by unlocking it with the key. Connect the charger to the battery and then to a wall outlet. Charging time is approximately 4-6 hours. The charger LED turns green when fully charged. Always use the original charger.
What is the maximum weight limit for the e-bike?
The maximum load capacity is 120 kg, including the rider and any luggage. Exceeding this limit can affect performance and safety.
How do I adjust the pedal assist levels?
Use the up/down buttons on the LCD display to cycle through the 5 levels: Eco, Tour, Sport, Turbo, and Walk mode. The level is displayed on the screen. Higher levels provide more assistance but reduce range.
Can I ride the Fortis FS7MDMBTBMA on public roads?
Yes, it is compliant with EU regulations (max 25 km/h). It is classified as an electric bicycle and can be ridden on bike lanes and roads without a license or registration. Always follow local traffic laws.
What maintenance does the e-bike require?
Regularly check tire pressure (35-50 psi), clean the chain and lubricate it every 200 km, inspect brake pads for wear, and ensure battery contacts are clean. Store the battery at room temperature when not in use for long periods.
How do I replace the inner tube or tire?
Remove the wheel by loosening the axle nuts. Use tire levers to pry the tire off the rim, replace the inner tube, and remount the tire. Inflate to recommended pressure. For the rear wheel, disengage the motor cable first.
The battery won't charge. What should I do?
Check that the charger is plugged in and the outlet works. Ensure the battery is properly connected to the charger. If the charger LED remains red after 6 hours, the battery may be defective. Contact Fortis support.
How can I extend the range of my e-bike?
Use lower pedal assist levels, maintain steady pedaling without sudden starts, keep tires properly inflated, and reduce cargo weight. Riding on flat terrain also conserves battery.
What should I do if the brakes feel spongy?
Spongy brakes indicate air in the hydraulic system or worn pads. For mechanical disc brakes, check cable tension and adjust the barrel adjuster. If pads are worn, replace them. If unsure, take the bike to a professional.
Is the Fortis FS7MDMBTBMA waterproof?
The bike has IPX4 water resistance, meaning it can withstand splashes from any direction but should not be submerged. Avoid riding in heavy rain and never use a pressure washer to clean it.
