Product Type	LED Desk Lamp
Model	VL-6
Brand	REVO
Light Source	LED (non-replaceable)
Color Temperature	3000K - 6000K adjustable
Brightness Levels	5 levels (touch control)
Power Input	DC 5V, 1A (USB powered)
Power Consumption	Max 5W
Dimensions (HxWxD)	40 x 15 x 15 cm
Weight	0.5 kg
Material	ABS plastic + aluminum
Adjustable Arm	Yes, 2-axis flexible gooseneck
Base Type	Stable weighted base with anti-slip pad
Additional Features	USB charging port, memory function, auto-off timer
Maintenance	Wipe with dry cloth; do not use liquid cleaners
Safety Certifications	CE, RoHS
Spare Parts Available	USB cable, adapter (not included with lamp)
Repairability Index	5.0 / 10 (limited repairability)
Manufacturer	REVO

Frequently Asked Questions - VL-6 REVO

How do I adjust the brightness?

Touch the sensor on the base to cycle through 4 brightness levels. Hold the sensor for 2 seconds to turn the lamp off.

Can I change the color temperature?

Yes, press the color temperature button (sun icon) to switch between warm (3000K), neutral (4500K), and cool (6000K) white.

Does the lamp have a USB port?

Yes, the base includes a USB-A output (5V, 1A) to charge your phone or other devices.

How do I clean the lamp?

Unplug the lamp and wipe the surfaces with a soft, dry cloth. Do not use any liquid or abrasive cleaners.

What power source is required?

The lamp operates on DC 5V, 1A via a micro-USB cable. Use a standard USB wall adapter or computer port.

Is the lamp head adjustable?

Yes, the gooseneck arm allows you to bend and rotate the lamp head to any angle for directed lighting.

Does it have an auto-off timer?

Yes, press the timer button to set a 45-minute timer; the lamp will automatically turn off after that.

Can I replace the LED bulb?

No, the LED is integrated and non-replaceable. The lamp is designed to last for 20,000 hours.

What is the warranty period?

REVO offers a 1-year limited warranty against manufacturing defects.

Is the lamp suitable for reading?

Yes, with adjustable brightness and color temperature, it provides comfortable reading light with no flicker.

USER MANUAL VL-6 REVO

with Dual Accessory Arms

Thank you for choosing Revo.

The Revo Vlog LED light provides bright bi-color light for vlogs and video chats. It runs on the power of a standard USB port. A 22-inch flexible arm supports the 48-LED ring-light fixture, and two 13-inch flex arms are topped with 1/4-20 threads for a camera or accessories like a microphone or mirror. The fixture's LEDs offer cool, warm, and neutral lighting modes to match most ambient lighting conditions. Ten-step power adjustment lets you select the ideal brightness for your environment.

Precautions

• Please read and follow these instructions, and keep this manual in a safe place.
• Keep this unit away from water and any flammable gases or liquids.
• Use only the correct, recommended voltage.
• Do not stare directly at the lights when they are powered on.
• Clean the unit with only a soft, dry cloth.
• Make sure the item is intact and that there are no missing parts.
• All images are for illustrative purposes only.

Specifications

LED Count: 48

Dimming: 10-step and continuous from 10% to 100%

Housing Material: Plastic, aluminum

Power Source: USB Standard-A

Power Requirement: 5 V, 2 A

Maximum Phone Width: 1.25 in. (3.2 cm)

Dimensions:

LED Flex Arm Length: 22 in. (55.9 cm)

Accessory Arm Length: 13.25 in. (33.6 cm)

Weight: 1.6 lb. (0.7 kg)

Overview

Technical line drawing of a medical device with labeled components including a REVO device and cable (no text or symbols beyond branding)

LED array

1/4-20

thread

- Attach devices with a 1/4-20 socket or accessories like a webcam, microphone, or mirror.

Flexible arms

Desk clamp

Controller

• Press the power button to turn the light on/off.
• Use the +/- buttons for 10-step brightness control or press and hold for stepless brightness adjustment from 10% to 100%.
• Press the mode selector to switch between cool, warm, and neutral.

USB plug

- Plug into any powered USB port or use a USB power adapter (not included) to run the light.

One-Year Limited Warranty

This Revo product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function.

This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER

MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state.

To obtain warranty coverage, contact the Revo Customer Service Department to obtain a return merchandise authorization ("RMA") number, and return the defective product to Revo along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser's own risk and expense.

For more information or to arrange service, visit www.revocinegear.com or call Customer Service at 212-594-2353.

Revo is a registered trademark of the Gradus Group.

© 2021 Gradus Group LLC. All Rights Reserved.

Product warranty provided by the Gradus Group.

www.gradusgroup.com
