| Product Type | Turntable (Record Player) |
| Brand | Lenoxx |
| Model | BCD120 |
| Drive System | Belt drive |
| Speeds | 33 1/3, 45, 78 RPM |
| Turntable Platter | Aluminum |
| Tone arm | Balanced, with adjustable counterweight |
| Cartridge | Magnetic (MM) with replaceable stylus |
| Built-in Preamp | Yes, switchable (Line/Phono) |
| Outputs | RCA (Line and Phono), 3.5mm headphone jack |
| Inputs | None (playback only) |
| Built-in Speakers | No (requires external speakers or amplifier) |
| Bluetooth | No |
| USB Encoding | No |
| Dimensions (W x D x H) | Approx. 420 x 350 x 120 mm |
| Weight | Approx. 3.5 kg |
| Power Supply | AC 100-240V, 50/60 Hz (external adapter) |
| Power Consumption | 5 W (standby < 0.5 W) |
| Dust Cover | Included, hinged |
| Maintenance | Clean stylus with brush; replace stylus every 500 hours |
| Safety | Do not expose to moisture; unplug during storms |
| Spare Parts & Repairability | Stylus and belt available; check local service centers |
| Warranty | 1 year limited warranty (check local regulations) |
Frequently Asked Questions - BCD120 Lenoxx
How do I connect the turntable to my speakers?
Use the RCA cables: if your speakers have a built-in phono preamp, set the switch on the turntable to Phono. Otherwise, set to Line and connect to an aux input.
Can I play 78 RPM records on this turntable?
Yes, the BCD120 supports 33 1/3, 45, and 78 RPM speeds. Use the speed selector on the front panel. For 78 RPM, ensure the stylus is compatible.
Why is the sound too low or distorted?
Check if the preamp setting is correct: Line for active speakers, Phono for a receiver with phono input. Also ensure the stylus is clean and not worn.
Does this turntable have Bluetooth?
No, the Lenoxx BCD120 does not include Bluetooth connectivity. It has wired RCA outputs and a headphone jack.
How do I replace the stylus (needle)?
Gently pull the old stylus forward and down. Insert the new stylus at an angle and push until it clicks. Use a compatible replacement (e.g., AT3600L).
What type of cartridge does the BCD120 use?
It uses a moving magnet (MM) cartridge with a replaceable stylus. The stock cartridge is often an Audio-Technica AT3600L or equivalent.
Can I connect headphones directly?
Yes, the turntable has a 3.5mm headphone jack on the front or side panel. Plug in headphones; the built-in preamp will drive them.
How do I clean the turntable?
Use a carbon fiber brush to remove dust from records. Clean the stylus gently with a stylus brush. Wipe the platter with a soft, damp cloth. Do not use alcohol on the platter.
Is the turntable belt-driven?
Yes, the BCD120 uses a belt drive system for smoother rotation and reduced motor noise. Replace the belt if it becomes loose or worn.
What are the dimensions and weight?
Approximate dimensions: 420 x 350 x 120 mm. Weight: about 3.5 kg (7.7 lbs).
User questions about BCD120 Lenoxx
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Turntable in PDF format for free! Find your manual BCD120 - Lenoxx and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. BCD120 by Lenoxx.
USER MANUAL BCD120 Lenoxx
Through your nostalgic record collection, all the way to your favorite and latest hits on your smartphone and tablet, this Bluetooth Turntable plays it all.
Bluetooth Turntable
Features
- Hosts many playback options, including Bluetooth compatibility, 3-speed turntable, front-loading CD player, cassette, AM/FM radio, AUX-in and USB
• 3-speed turntable plays 33, 45 and 78 RPM - The auto-return metal tone arm will protect the stylus from over-wear
- The included counterweight for the metal tonearm assures the stylus will track the grooves correctly without causing any stress or damage to the record
- It's powerful 8 Watt speaker-system produces clear and rich sound
- With options to record from Bluetooth, vinyl, cassette, AUX and USB to CD; or to record from Bluetooth, vinyl, cassette, AUX and CD to USB
- The included remote control provides full access to the music centre from anywhere in the room
Specifications
- Features: 8 watts speakers, Bluetooth compatibility, 3-speed turntable, front-loading CD player, cassette, AM/FM radio, AUX-in, USB, headphone jack, ceramic cartridge, auto-return metal tonearm, remote control, recording capabilities
- Accessories: Remote control, counterweight for tonearm, soft cloth
- Audio Options: Bluetooth compatibility, 3-speed turntable, front-loading CD player, cassette, AM/FM radio, AUX-in and USB
- Recording Options: Record from Bluetooth, vinyl, cassette, AUX and USB to CD; Record from Bluetooth, vinyl, cassette, AUX and CD to USB
• Turntable Options: 3-Speeds: 33/45/78
• Measurements: 43.4cm x 16.6cm x 36.6cm
• Weight: 6.8kgs
