63-BO-11 - Oven MPM - Free user manual and instructions

Product Type	Built-in Electric Oven
Brand	MPM
Model	63-BO-11
Energy Source	Electric
Oven Capacity	63 Liters
Dimensions (H x W x D)	595 x 595 x 575 mm
Weight	Approx. 30 kg
Power Consumption	220-240 V, 50/60 Hz, 3000 W
Energy Efficiency Class	A
Number of Functions	8
Main Functions	Conventional heat, fan-assisted, grill, defrost, pizza, bottom heat, light, ECO
Temperature Range	50°C - 250°C
Cleaning System	Easy-clean enamel interior
Safety Features	Child lock, automatic shut-off, cool-touch door
Display and Controls	Digital timer, touch controls, LED display
Interior Light	Yes
Accessories Included	Baking tray, wire shelf, twist grill rod
Spare Parts Availability	Heating elements, thermostat, door gasket, light bulb
Repairability	Modular design, user-replaceable parts, service network
Warranty	2 years

Frequently Asked Questions - 63-BO-11 MPM

How do I set the timer on my MPM 63-BO-11 oven?

To set the timer, press the timer button on the control panel, then use the + and - buttons to adjust the time. Confirm by pressing the timer button again. The oven will automatically turn off when the countdown ends.

What oven functions are available?

The oven offers 8 functions: conventional heat (top and bottom), fan-assisted, grill, defrost, pizza mode, bottom heat, interior light, and ECO mode. Select using the function knob.

How do I clean the oven interior?

The oven has an easy-clean enamel coating. Wipe with a damp cloth and mild detergent after use. For stubborn stains, use a non-abrasive cleaner. Avoid using steel wool or harsh chemicals.

Can I use aluminum foil in the oven?

Yes, but avoid covering the oven floor or heating elements completely, as this can cause overheating. Use foil only on trays or to wrap food.

How do I enable the child lock?

Press and hold the lock button for 3 seconds until the lock icon appears on the display. To disable, press and hold again. This prevents accidental operation by children.

What does the ECO mode do?

ECO mode reduces energy consumption by optimizing heating cycles. It is ideal for reheating or cooking dishes that require lower temperatures. The display shows ECO when active.

Why is my oven not heating up?

Check the power connection and ensure the circuit breaker is on. If the oven still does not heat, the heating element or thermostat may need replacement. Contact MPM service.

How do I replace the oven light bulb?

Disconnect the oven from power. Remove the glass cover by turning it counterclockwise. Replace with a 25W/300°C compatible bulb (E14 base). Reattach the cover and restore power.

What is the maximum oven temperature?

The maximum temperature is 250°C (482°F). For most baking, we recommend preheating to the desired level. The oven will beep when ready.

How do I calibrate the oven temperature?

If the oven temperature differs from your oven thermometer, you can adjust it. Access the settings menu by pressing and holding the temperature button for 5 seconds. Use +/- to adjust offset (max ±20°C). Confirm by pressing the temperature button.

USER MANUAL 63-BO-11 MPM

Blue background with a circle of twelve yellow stars, representing the European Union flag (no text or symbols beyond the stars)

ENERG

енергия - ενέργεια

MPM

MPM-63-BO-11

Blue line icon of a washing machine with a power plug, no text or symbols present

A

66 L

0.88 kWh/cycle*
