Product Type	Car Speaker
Speaker Size	6.5 inches (165 mm)
Speaker Type	2-way coaxial
Power Handling (RMS)	60 Watts
Power Handling (Peak)	120 Watts
Impedance	4 Ohms
Sensitivity	90 dB
Frequency Response	40 Hz - 20 kHz
Magnet Type	Ferrite
Cone Material	Polypropylene
Tweeter Size	1 inch (25 mm) dome
Mounting Depth	50 mm
Installation Method	Flush mount with included grille
Weight per Speaker	0.9 kg
Package Contents	2 speakers, grilles, mounting hardware, manual
Maintenance	Wipe with a dry soft cloth
Safety	Disconnect car battery before installation
Spare Parts Availability	Contact Blaupunkt customer service
Warranty	2 years (subject to terms)

Frequently Asked Questions - BM 1200 WSN BLAUPUNKT

What are the dimensions of the Blaupunkt BM 1200 WSN speaker?

The speaker has a diameter of 6.5 inches (165 mm) and a mounting depth of 50 mm. It fits most standard car speaker slots.

What is the power handling of the BM 1200 WSN?

The RMS power handling is 60 Watts, with a peak power of 120 Watts. Ensure your amplifier matches these ratings to avoid damage.

Can I install the BM 1200 WSN in my car?

Yes, it is a 6.5-inch coaxial speaker suitable for most cars. Check the mounting depth and cutout diameter (approx. 145 mm) before installation.

Is the speaker compatible with a 4-ohm amplifier?

Yes, the BM 1200 WSN has an impedance of 4 ohms, making it compatible with most aftermarket car amplifiers.

What type of music does the BM 1200 WSN reproduce best?

With a frequency response of 40 Hz to 20 kHz, it handles bass, mids, and highs well. It is great for rock, pop, and classical music.

Does the speaker come with a grille?

Yes, the package includes two grilles to protect the speakers from physical damage.

How do I clean the speaker?

Use a dry, soft cloth to gently wipe the cone and grille. Avoid using water or chemical cleaners.

What is the warranty period?

The Blaupunkt BM 1200 WSN comes with a 2-year warranty. Keep your receipt for service requests.

Can I use these speakers without an external amplifier?

Yes, they can be powered by a standard car head unit, but for optimal performance, an external amplifier is recommended.

Are the speaker terminals standard?

Yes, they use standard spade connectors (4.8 mm or 6.3 mm) compatible with most car audio wiring.

USER MANUAL BM 1200 WSN BLAUPUNKT

Three black speaker components with circular heads and mounting base, shown from different angles (front, side, and top) against white background.

Enjoy it.

INTRODUCTION SPECIFICATION

Proper system planning is vital in order to maximize the device's performance and road safety. Plan your installation carefully to avoid compromising performance reliability of the system. Consult an authorized Blaupunkt delaler for installation or reparation. Read the manual carefult before operating the device for the first time.

Safety Notes

Ensure to follow below safety notes during installation and wiring connection: -

• Disconnect the negative terminal of the battery. Refer to the safety notes of the vehicle manufacturer.
• Ensure positions of the holes are nowhere near the vehicle component to avoid any damage during drilling.
• Ensure cross section of the cable is no less than 2.5mm^2 if the positive and negative cables are too
• long. Incorrect installation may result in malfunction of the device or the car sound system.

Installation and Connection Instructions

• Installation and Connection Instructions
• Select a dry and well-ventilated location to install the device.
• The device must not be installed in overly exposed location such on therear shelf, rear seat etc.
• The installation location must be suitable for screw holes and have stable ground support.

Disclaimer

In no event shall Blaupunkt be liable for any direct, indirect, punitive, incidental, special consequential damages to properly or life and whatsoever arising out of or connected with the use or misuse of our products.

USA & CANADA: This product is not intended for sale in the United States and Canada. If purchased in the U.S. or Canada, this product is purchased on as-is basis. No warranty, whether expressed or implied is provided in the U.S. or Canada.

Voltage Supply

• Use the supplied power extension cable to connect to the positive battery terminal.
• Firmly and carefully connect the ground lead to a bare metal point on the vehicle chassis.
• The control of the device should be a two-channel control, either via the preamplifier output of the car sound system.
• A control solely via the right or left channel is also possible since the low-frequency portion of the music is generally identical on both channels.

Recycling and Disposal

Do not dispose of your old unit in the
household trash!
Use the return and collection systems
available to dispose of the old device.

This manual may be updated from time to time without any notice.

BM 1200 WSN

A piece of 8" BMW direct fit plug & play subwoofer to upgrade OE subwoofer installed for selected BMW models with paper cone material including installation instructions

• Normal output power (RMS) : 100W
• Max. output power: 200W
- Sensitivity: 86dB
• Impedance : 4ohms
• Frequency response: 44Hz - 3.000Hz
- Surround:Rubber
• Magnet type: Neodymium magnet
- Mounting depth: 36mm
• Diameter hole : 229mm
- Overall height: 61mm

INSTALLATION

Side view of a silver sedan driving on a road with blurred city background (no visible text or symbols)

Reference vehicle is 2015 BMW 5-series. (For illustration purpose only)

INSTALLATION INSTALLATION

1. Remove screw that attach driver seat to the floor track

2. Tilt seat down to access subwoofer compartment

3. OE subwoofer will be visible after removal of the cover

4. Loosen the subwoofer screws

5. Remove subwoofer

6. Loosen and remove to 4 mounting screws of the carpet panel

7. Disconnect blue colour speaker wire

B. Carefully remove subwoofer without damaging the plastic enclosure which can be used for Blaupunkt BM 1200 WSN

9. Side by side comparison of OE subewoofer and BM 1200 WSN

10. Fit BM 1200 WSN into the plastic enclosure and tighten the screws

11. Reinstall the BM 1200 WSN into the subwoofer compartment

12.Reconnect the speaker wire

13. Reassemble speaker cover 14. Tighten the front and rear screw of the seat track

screw of the seat track

15. Finally, place the seat back to the floor track

COMPATIBILITY LIST

Blaupunkt BM 1200 WSN is compatible with all BMW models with "Stereo" or "Standard" configuration.

To maximize the performance of BM 1200 WSN, we recommend to use 1x4 Channel amplifiers or 2x2 Channel amplifiers.

BM 1200 WSN can be installed in the following list of car model:

Series	Model	Series	Model
1 series	E81 (3-door)	7 series	E65 (Limousine)
	E82 (Coupé)		E66 (Limousine L)
	E87 (5-door)		F01 (Limousine)
	E88 (Cabriolet)		F02 (Limousine L)
	F20 (5-door)		G11 (Limousine)
	F21 (3-door)		G12 (Limousine L)
2 series	F22 (Coupé)	X1	E84 (SUV)
	F23 (Cabriolet)		F48 (SUV)
	F45 (Active Tourer)		F49 (SUV L)
	F46 (Gran Tourer)	X3	E83 (SUV)
	F87 (M2)		F25 (SUV)
3 series	E90 (Limousine)		G01 (SUV)
	E91 (Touring)	X5	E70 (SUV)
	E92 (Coupé)		F15 (SUV)
	E93 (Cabriolet)		F85 (SUV)
	F30 (Limousine)		G05 (SUV)
	F31 (Touring)	X6	E71 (SUV)
	F34 (Gran Turismo)		F16 (SUV)
	F80 (M2)	i8	L15 (Roadster)
4 series	F32 (Coupé)		R60 (Countryman)
	F33 (Cabriolet)		R61 (Paceman)
	F36 (Gran Coupé)	Mini	F56 (3-door)
	F82 (M4)		F55 (S-door)
	F83 (M4 Cabriolet)		F54 (Clubman)
5 series	E60 (Limousine)		F57 (Cabrio)
	F07 (Gran Turismo)
	F10 (Limousine)	* Installed underseat in listed vehicles.
	F11 (Touring)
	G30 (Limousine)
	G31 (Touring)
6 series	E63 (Coupé)
	E64 (Cabriolet)
	F06 (Gran Coupé)
	F12 (Coupé)
	F13 (Cabriolet)
	G32 (Gran Turismo)

Designed and engineered by Blaupunkt Competence Centre

1 112 17 003 02 01
