KKE620 - Kettle Kambrook - Free user manual and instructions

Product Type	Electric Kettle
Brand	Kambrook
Model	KKE620 (KKE620BLK)
Capacity	1.7 liters (estimated)
Power Rating	2200 W
Voltage	230-240 V
Heating Element	Concealed rapid boil element
Housing Material	Plastic with stainless steel finish (black)
Filter	Removable and washable stainless steel mesh filter
Lid Type	Wide hinged lid with one-touch pop-up button
Handle	Cool touch handle
Water Level Indicator	Water window with Min and Max marks
Power Switch	Illuminating On/Off boil switch
Power Base	Included, with cord wrap underneath
Cord Length	Approximately 0.75 m (estimated)
Auto Shut-off	Yes, after boiling
Boil-Dry Protection	Yes, automatic shut-off if operated with insufficient water
Safety Features	Auto shut-off, boil-dry protection, cool touch handle, non-slip base
Cleaning	Wipe exterior with damp cloth; removable filter washable in warm soapy water; descale with vinegar or lemon
Spare Parts	Replacement filter available; contact Kambrook customer service
Reparability	Only authorized Kambrook service centers
Warranty	Standard manufacturer warranty (contact customer service)
Country of Origin	Designed in Australia; manufactured in China (assumed)

Frequently Asked Questions - KKE620 Kambrook

What is the capacity of the Kambrook KKE620 kettle?

The Kambrook KKE620 has a capacity of approximately 1.7 liters (estimated from typical size). Fill between the MIN and MAX marks on the water window.

Can I boil other liquids like soup or milk in this kettle?

No, this kettle is designed specifically for boiling drinking quality water only. Do not boil any other liquids or foodstuffs as it may cause damage or injury.

How do I clean the removable filter?

Remove the filter by pulling it downwards to unclip and wash in warm soapy water. Ensure the kettle is cool before handling. Replace by clipping the bottom first, then the sides.

What should I do if the kettle shuts off before boiling?

This may be due to the boil-dry protection activating if there is insufficient water. Ensure the water level is above the MIN mark. Also, after boiling, wait a few seconds for the control to reset before reboiling.

How do I descale the kettle?

Use a proprietary kettle descaler or a mixture of 1 part vinegar (or a few slices of lemon) with 2 parts water. Boil, let stand overnight, empty, then rinse with clean water.

Is the kettle cord long enough?

The cord is approximately 0.75 meters long. Fully unwind before use and avoid letting it hang over edges or touch hot surfaces.

What materials is the kettle made of?

The kettle body is plastic with a black finish, and the filter is stainless steel mesh. The heating element is concealed.

Does the kettle have an automatic shut-off?

Yes, the kettle automatically switches off once the water has boiled. It also has boil-dry protection that shuts it off if operated with too little water.

Where can I get replacement parts like the filter?

Contact Kambrook customer service in Australia (1300 139 798) or New Zealand (0800 273 845), or visit their websites to order spare parts.

How loud is the kettle when boiling?

The kettle operates at a typical noise level for an electric kettle (around 70-80 dB estimated). The rapid boil element heats quickly.

USER MANUAL KKE620 Kambrook

Kambrook - Australia

Building 2, Port Air Industrial Estate

1A Hale Street

Botany NSW 2019

Australia

Customer Service Line 1300 139 798

Customer Service Fax [phone]

www.kambrook.com.au

Kambrook - New Zealand

Private Bag 94411

Botany, Manukau

Auckland 2163

New Zealand

Customer Service Line/

Spare Parts 0800 273 845

Customer Service Fax [phone]

www.kambrook.co.nz

KAMBROOK

THE SMARTER CHOICE

Black Kambrook water heater with a triangular handle and white label (no additional text or symbols visible)

Important

Please retain your instruction book for future use.

In the event that you need some assistance with your Kambrook appliance, please contact our Customer Service Department on 1300 139 798 (Australia) or 0800 273 845 (New Zealand). Alternatively, visit us on our website at www.kambrook.com.au or www.kambrook.co.nz

Contents

Kambrook Recommends

Safety First

Your Kambrook Kettle p6

Using Your Kambrook Kettle p7

Care, Cleaning and Storage p9

p4

IMPORTANT: Please retain your instruction book for future use.

At Kambrook, we believe that safe performance is the first priority in any consumer product, so that you, our valued customer can confidently use and trust our products. We ask that any electrical appliance that you use be operated in a sensible fashion with due care and attention placed on the following important operating instructions.

Important Safeguards For Your Kambrook Kettle

• Carefully read all instructions before operating the Kambrook Kettle for the first time and save for future reference.
• Remove and safely discard any packaging material and promotional labels before using the kettle for the first time.
• To eliminate a choking hazard for young children, remove and safely discard the protective cover fitted to the power plug of this kettle.
• This kettle has been designed specifically for the purpose of boiling drinking quality water only. Under no circumstances should this product be used to boil any other liquids or foodstuffs.
• Do not place the kettle near the edge of a bench or table during operation. Ensure that the surface is level, clean and free of water and other substances.
• Do not operate the kettle on a sink drain board.
• Always ensure the kettle is properly assembled before use. Follow the instructions provided in this book.
• The kettle must be used only with the power base supplied.

• Do not touch hot surfaces. Use the handle for lifting and carrying the kettle.
  • Do not place anything on top of the lid.

• Use caution when pouring water from the kettle as boiling water and steam will scald. Do not pour the water too quickly.

• Do not remove the kettle from the power base during operation. Ensure the kettle has switched off after the water has boiled or reached the selected temperature, before removing the kettle from the power base. If the kettle is removed from the power base during the boiling cycle, the kettle will automatically switch off.
• Do not use chemicals, steel wool, or abrasive cleaners to clean the outside of the kettle.
• The filter could become damaged with time; please check regularly and replace if found damaged.
• Ensure the kettle has cooled down before attempting to clean the filter and kettle.
• Always fill the kettle with water between the minimum (MIN) and maximum (MAX) marks on the water window of the kettle. Too little water will result in the kettle switching 'OFF'. Filling above the maximum mark (MAX) may result in boiling water splashing from the kettle.
• The lid should always be locked firmly in place in the closed position during use.

• Do not open the lid during operation as this may result in boiling water splashing from the kettle. Pour all the hot water from the kettle before opening the lid to refill.

• Do not operate the kettle on an inclined plane. Do not operate the kettle unless the element is fully immersed. Do not move the kettle while it is switched on.

• To prevent damage to the kettle, do not use alkaline cleaning agents when cleaning, use a soft cloth and mild detergent.
• When using the kettle, avoid spillage of water on the kettle base and connector as this may cause damage to the kettle.
• Care should be taken when handling the kettle during use, ensuring that the kettle body and parts are not touched as these may still be hot due to residual heat after boiling. Always ensure to use the kettle handle when removing the kettle or pouring water after the kettle has boiled.
• Keep the kettle clean. Follow the cleaning instructions provided in this book on (page 9).

Important safeguards for all electrical appliances

• Fully unwind the power cord before use.

- Connect only to 230V or 240V power outlet.

- Do not let the power cord hang over the edge of a bench or table, touch hot surfaces or become knotted.

- To protect against electric shock, do not immerse the power cord, power plug or appliance in water or any other liquid, unless it is recommended in the cleaning instructions.

- The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance, by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

- It is recommended to inspect the appliance regularly. Do not use the appliance if the power supply cord, plug, connector or appliance becomes damaged in any way. Return the entire appliance to the nearest authorised Kambrook Service Centre for examination and/or repair.

- Any maintenance other than cleaning should be performed at an authorised Kambrook Service Centre.

- This appliance is for household use only. Do not use this appliance for other than its intended use. Do not use in moving vehicles or boats. Do not use outdoors. Misuse may cause injury.

- The installation of a residual current device (safety switch) is recommended to provide additional safety protection when using electrical appliances. It is advisable that a safety switch with a rated residual operating current not exceeding 30mA be installed in the electrical circuit supplying the appliance. See your electrician for professional advice

- Always turn the appliance to the OFF position, switch off at the power outlet and unplug at the power outlet when the appliance is not in use.

- Before cleaning, always turn the appliance to the OFF position, switch off at the power outlet, unplug at the power outlet and remove the power cord, if detachable, from the appliance and allow all parts to cool.

- Do not place this appliance on or near a heat source, such as hot plate, oven or heaters.

- Position the appliance at a minimum distance of 20cm away from walls, curtains and other heat or steam sensitive materials and provide adequate space above and on all sides for air circulation.

Your Kambrook Kettle

1. Wide hinged lid
2. One touch pop-up lid button
3. Illuminating power On/Off boil switch; illuminates when power is ON
4. Water level window with level indicator
5. Cool touch handle
6. Power base

Not Shown

• Removable and washable stainless steel mesh filter
  • Cord wrap under the kettle base
  • 2200 watt rapid boil concealed element

KKE620BLK Model Shown

Using Your Kambrook Kettle

Before First Use

Remove any packaging material and promotional labels before using your kettle for the first time. It is recommended before the first use to fill the kettle to the maximum level with cold tap water, bring to the boil and then discard the water. Your kettle will only operate when positioned on the power base with the ON/OFF switch in the 'ON' position. The kettle will automatically switch off once the water has boiled.

Operating Your Kettle

1. To fill the kettle with water, remove it from the power base and open the lid by pressing the button on the handle of the kettle and the lid will lift upwards. Fill with the desired amount of water. Do not operate the kettle without water. Always fill the kettle between the 'MIN' and the 'MAX' marks on the water window. Too little water will result in the kettle switching off.
2. Ensure that the lid is closed before placing the kettle on the power base.
3. Place the kettle firmly onto the power base and plug the power cord into a 230V or 240V power outlet and switch on.
4. Press the ON/OFF switch to the 'ON' position. The power 'ON' light will illuminate.

NOTE: Never operate the kettle dry - too little water will result in the kettle switching 'OFF'. Do not overfill the kettle - filling above the 'MAX' mark on the water window may result in boiling water splashing from the kettle.

NOTE: This kettle must only be used with the power base supplied. Use caution when pouring water from your kettle, as boiling water will scald. Do not pour the water too quickly.

NOTE: Do not remove the kettle from the power base during operation. Ensure the kettle has switched to the 'OFF' position after the water has boiled before removing the kettle from the power base.

1. The kettle will automatically switch 'OFF' once the water has boiled. Lift the kettle from the power base and pour the water. Take care to hold the kettle level, especially when filled to the maximum level. To re-boil, it may be necessary to wait for a few seconds to allow the control to reset.
2. The kettle should be stored on its power base when not in use. The power outlet should be switched off and the power cord unplugged from the power outlet when not in use.

WARNING: This kettle is designed for the boiling of quality drinking water only. Never use it to heat or boil any other liquids or foodstuffs. The lid should always be firmly in place and locked closed before use.

Using Your Kambrook Kettle Continued...

WARNING: Do not release the lid while the water is boiling. Ensure the lid is closed whilst boiling.

Safety Boil Dry Protection

The kettle is fitted with a safety device which protects against overheating should the appliance be operated with insufficient water. If this occurs, the kettle will stop heating and automatically switch 'OFF'. Should this occur, switch off at the power outlet and unplug. Allow kettle to cool before refilling. Remove the kettle from the power base and add water. Return the kettle to the power base. The safety device will automatically reset.

Care, Cleaning and Storage

Always switch off at the power outlet and then unplug the kettle from the power outlet before cleaning.

Cleaning the Kettle Exterior

The outside surface of the kettle may be wiped over with a damp cloth and polished with a soft, clean dry cloth.

Cleaning the Removable Filter

The filter fitted inside the kettle over the spout is removable for cleaning. To remove, pull the filter downwards to unclip the bottom and pull away from the kettle. Clean the filter in warm, soapy water. To replace, clip the bottom of the filter back first and then the sides, being careful not to place too much force on the filter.

WARNING: Do not touch hot surfaces. Allow the kettle to cool down before moving or cleaning any parts.

TIP: The filter could become damaged with time, please check regularly and replace if found damaged.

NOTE: Ensure the kettle has cooled down before attempting to clean the filter.

NOTE: Do not use chemical, steel wool, or abrasive cleaners to clean the inside or outside of the kettle.

WARNING: To prevent damage to the kettle, do not use alkaline cleaning agents when cleaning; use a soft cloth and mild detergents.

WARNING: Never immerse the kettle base, switch area, power base of power supply cord in water or allow moisture to come in contact with these parts.

Mineral Deposits and Discolouration

Due to the large surface area of the immersed element (interior base), discolouration due to mineral deposits from tap water may appear more obvious by leaving a brown stain on the base. THIS IS NOT RUST. To remove the discolouration, follow the instructions “Removing Mineral Deposits”.

Care, Cleaning and Storage Continued...

Removing Mineral Deposits

Mineral deposits in tap water may cause the kettle interior and water window to discolour over time. This may be removed by using a proprietary kettle descaler which is available from most leading supermarkets, department stores and hardware stores.

Alternatively:

1. Fill the kettle until Standard 23 size full with 1 part vinegar (or a few slices of lemon) and 2 parts water, bring to the boil and allow to stand overnight.

2. Empty the solution from the kettle. Fill the kettle with clean water, bring to boil and discard the water. Repeat and the kettle will be ready for use.

Storage

Ensure the kettle is switched off, cleaned and dried before storing. Ensure that the lid is closed and locked firmly into place. Wrap the power cord around the cord storage under the power base. Stand the kettle upright on the power base. Do not store anything on top.
