Beatermix JM4000 - Food processor SUNBEAM - Free user manual and instructions

Product Type	Hand Mixer
Brand	Sunbeam
Model	Beatermix JM4000
Power	200W
Voltage	220-240V AC
Frequency	50/60 Hz
Speed Settings	6 speeds plus Boost
Beaters	2 V-groove steel beaters
Eject Button	Yes, for easy removal of beaters
Motor Housing Material	Plastic (assumed)
Max Continuous Operation (Heavy Loads)	15 seconds
Max Continuous Mixing (Normal Heavy)	2.5 minutes
Cleaning – Motor Housing	Wipe with damp cloth, do not immerse
Cleaning – Beaters	Wash in warm soapy water or dishwasher
Safety Features	Unplug before cleaning, keep fingers away from moving parts
Warranty	12 months replacement or repair
Country of Origin	China
Intended Use	Household
Accessories Included	2 beaters

Frequently Asked Questions - Beatermix JM4000 SUNBEAM

How do I insert the beaters into the Sunbeam Beatermix JM4000?

Ensure the mixer is unplugged and the speed switch is at 'O' (off). Insert each beater into the sockets and push firmly until they click into place.

How do I safely remove the beaters after use?

Always turn the speed switch to 'O' and unplug the mixer. Then press the eject button firmly to release the beaters. Never eject beaters while the mixer is operating.

What speed should I use for different mixing tasks?

Refer to the mixing guide: Speed 1 for folding/light blending, Speed 2 for light mixing, Speed 3 for mixing, Speed 4 for creaming/beating, and Speed 6 for whipping/aerating. Speed 5 is not specified but can be used as intermediate.

Can the Sunbeam Beatermix JM4000 handle heavy dough?

Yes, but do not operate for more than 2.5 minutes at a time for heavy mixtures. The Boost setting provides extra power for tough tasks, but the maximum continuous operation under heavy loads is 15 seconds.

How should I clean the mixer?

Unplug the mixer. Wipe the motor housing with a damp cloth and polish dry. Wash the beaters in warm soapy water with a cloth or sponge, or place them in a dishwasher. Do not immerse the motor housing in water.

Are the beaters dishwasher safe?

Yes, the beaters can be placed in a dishwasher. However, avoid using scouring pads or abrasive cleaners on them.

What is the warranty for the Sunbeam Beatermix JM4000?

Sunbeam offers a 12-month replacement or repair warranty from the date of purchase, covering faulty materials or workmanship. You need the original proof of purchase to make a claim.

Where can I get service or support for my mixer?

Contact Sunbeam's customer service line: 1300 881 861 in Australia, or 0800 786 232 in New Zealand. Alternatively, visit www.sunbeam.com.au or www.sunbeam.co.nz for service centres and tips.

Can I use an extension cord with this mixer?

Only use an extension cord if it has been checked and tested by a qualified technician or service person. For safety, it's best to plug directly into a wall outlet.

What is the Boost function on the Beatermix JM4000?

The Boost setting provides an extra burst of power for tough mixing tasks, such as heavy doughs or thick batters. It is activated by moving the speed control beyond speed 6.

USER MANUAL Beatermix JM4000 SUNBEAM

White Sunbeam electric mixer with a metal stand, no visible text or symbols on the device body

Contents

Sunbeam's Safety Precautions	1
Features of your Hand Mixer	2
Using your Hand Mixer	3
Mixing Guide	3
Care and Cleaning	4

Important instructions – retain for future use.

Sunbeam's Safety Precautions

SAFETY PRECAUTIONS FOR YOUR SUNBEAM HAND MIXER.

• Switch off the appliance and disconnect from supply before changing accessories or approaching parts that move in use.
• Never eject beaters when the appliance is in operation.

Sunbeam is very safety conscious when designing and manufacturing consumer products, but it is essential that the product user also exercise care when using an electrical appliance. Listed below are precautions which are essential for the safe use of an electrical appliance:

• Read carefully and save all the instructions provided with an appliance.
• Always turn the power off at the power outlet before you insert or remove a plug. Remove by grasping the plug - do not pull on the cord.
• Turn the power off and remove the plug when the appliance is not in use and before cleaning.
• Do not use your appliance with an extension cord unless this cord has been checked and tested by a qualified technician or service person.
• Always use your appliance from a power outlet of the voltage (A.C. only) marked on the appliance.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• The temperature of accessible surfaces may be high when the appliance is operating.

• Never leave an appliance unattended while in use.

• Ensure fingers are kept well away from moving beaters.

• The maximum operating time under heavy loads to 15 seconds only (as indicated by the rating). This does not apply to any of the recipes detailed in this booklet.

• Do not use an appliance for any purpose other than its intended use.

• Do not place an appliance on or near a hot gas flame, electric element or on a heated oven.
• Do not place on top of any other appliance.
• Do not let the power cord of an appliance hang over the edge of a table or bench top or touch any hot surface.
• Do not operate any electrical appliance with a damaged cord or after the appliance has been damaged in any manner. If damage is suspected, return the appliance to the nearest Sunbeam Appointed Service Centre for examination, repair or adjustment.
• For additional protection, Sunbeam recommend the use of a residual current device (RCD) with a tripping current not exceeding 30mA in the electrical circuit supplying power to your appliances.
• Do not immerse the appliance in water or any other liquid unless recommended.
• Appliances are not intended to be operated by means of an external timer or separate remote control system.
• This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments; farm houses; by clients in hotels, motels and other residential type environments; bed and breakfast type environments.

Features of your Hand Mixer

6 speed settings plus Boost

6-speed control provides a range of speeds for various mixing tasks. The Boost setting provides an extra burst of power for those extra tough mixing tasks.

Eject button

The eject button effortlessly releases the beaters for easy cleaning.

200w motor

Provides adequate power for quick and easy mixing.

'V-groove' beaters

Specially designed steel beaters provide maximum aeration and optimum mixing results.

Using your Hand Mixer

Before fitting the beaters ensure that the cord is unplugged from the power outlet and the speed switch is in the 'O' (off) position.

1. Insert the beaters one at a time into the sockets, and push firmly until they click into position.
2. Insert the plug into the power outlet and turn the power on and place the beaters into the ingredients to be mixed.
3. Select the desired speed setting from 1 to 6, depending on your mixing task. See Table 1 for a mixing guide.

Important: When mixing heavy mixtures do not operate for more than 2 12 minutes at a time.

1. Once you have finished mixing, turn the speed switch to the 'O' (off) position.

Remove the beaters from the mixture and press the eject button firmly to release.

Note: Never eject the beaters when the Hand Mixer is in operation.

Mixing Guide

Mixing task Recommended speed(s)
Folding/Light Blending Speed 1
Light Mixing Speed 2
Mixing Speed 3
Creaming/Beating Speed 4
Whipping/Aerating Speed 6

Care and Cleaning

Before cleaning your Sunbeam Hand Mixer, ensure that the power is turned off at the power outlet, then remove the plug. Wipe over the outside area of the Hand Mixer with a dampened cloth and polish with a soft dry cloth. Wipe any excess food particles from the power cord. Do not immerse the motor housing in water or any other liquid. Do not use harsh detergents or abrasive cleaners to clean the motor housing as these will scratch and damage the surface.

Wash the beaters in warm soapy water with a cloth or sponge. Rinse and dry thoroughly. Do not use scouring pads or abrasive cleaners. The beaters can also be placed in a dishwasher.

Note: Never wind the power cord around the motor after use as the warmth of the motor may cause damage to the power cord.

12 Month Replacement Guarantee

This Sunbeam product is covered by a 12 month replacement or repair warranty, which is in addition to your rights under the Australian Consumer Law (if your product was purchased in Australia) or New Zealand Consumer Guarantees Act (if your product was purchased in New Zealand).

Should you experience any difficulties with your product during the warranty period, please contact our customer service line for advice on 1300 881 861 in Australia, or 0800 786 232 in New Zealand.

Australia

www.sunbeam.com.au 1300 881 861

Units 5 & 6, 13 Lord Street,

Botany NSW 2019

Australia

New Zealand

www.sunbeam.co.nz 0800 786 232

Level 6, Building 5, Central Park,

660-670 Great South Road, Greenlane, Auckland

New Zealand

Upon receipt of your claim, Sunbeam will seek to resolve your difficulties or, if the product is defective, advise you on how to obtain a replacement or refund.

To assist us in managing warranty claims, we recommend you register your product as soon as practicable after purchase by creating a MySunbeam account on our website and uploading a copy of your original receipt.

In order to make a claim under our warranty, you must have the original proof of purchase documentation for the product and present it when requested (if not already uploaded to our website).

Should your product develop any defect within 12 months of purchase because of faulty materials or workmanship, we will replace or repair it, at our discretion, free of charge. A product presented for repair may be replaced by a refurbished product of the same type rather than being repaired. Refurbished parts may be used to repair the product.

Our replacement or repair warranty only applies where a defect arises as a result of faulty material or workmanship during the warranty period. Your warranty does not cover misuse or negligent handling (including damage caused by failing to use the product in accordance with this instruction booklet), accidental damage, or normal wear and tear.

Your warranty does not:

• cover freight or any other costs incurred in making a claim, consumable items, accessories that by their nature and limited lifespan require periodic renewal (such as filters and seals) or any consequential loss or damage; or

• cover damage caused by:

- power surges, power dips, voltage supply problems, or use of the product on incorrect voltage;

• servicing or modification of the product other than by Sunbeam or an authorised Sunbeam service centre;
• use of the product with other accessories, attachments, product supplies, parts or devices that do not conform to Sunbeam specifications; or
• exposure of the product to abnormally corrosive conditions; or

- extend beyond 3 months if the product is used in commercial, industrial, educational or rental applications.

The benefits given to you by our warranty are in addition to other rights and remedies under law in relation to the product.

In Australia our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

Our goods also come with guarantees that cannot be excluded under the New Zealand Consumer Guarantees Act.

If your warranty claim is not accepted, we will inform you and if requested to do so by you, repair the product provided you pay the usual charges for such repair. You will also be responsible for all freight and other costs.

Should your product require repair or service after the warranty period, contact your nearest Sunbeam service centre. For a complete list of Sunbeam's service centres, visit our website or call our customer service line for advice on 1300 881 861 in Australia, or 0800 786 232 in New Zealand.
