| Product Type | Top-Loading Washing Machine |
| Model | XQB80-F303Z |
| Brand | TCL |
| Capacity | 8.0 kg |
| Dimensions (W x D x H) | 560 x 580 x 910 mm |
| Weight | 34 kg |
| Power Supply | 220-240 V ~ 50 Hz |
| Power Consumption | 410 W (wash) / 300 W (spin) |
| Water Consumption | Approx. 110 L per cycle |
| Spin Speed | 700 rpm |
| Programs | Standard, Heavy, Quick, Delicate, Soak, Rinse+Spin |
| Control Type | Electronic with LED display |
| Water Level | Automatic (adjustable) |
| Material (Drum) | Stainless steel |
| Material (Lid) | Tempered glass |
| Noise Level (Wash/Spin) | 58 dB / 68 dB |
| Safety Features | Child lock, overflow protection, unbalanced load detection |
| Maintenance | Clean filter monthly, descale every 3 months |
| Spare Parts Availability | Online through TCL service centers |
| Manual Included | Yes (PDF available) |
Frequently Asked Questions - XQB80-F303Z TCL
How do I start a wash cycle?
Select the desired program using the program knob, then press the Start/Pause button. The machine will begin filling and washing.
What does the 'Child Lock' do?
The Child Lock prevents accidental button presses during operation. To activate, hold the 'Child Lock' button for 3 seconds.
How can I clean the filter?
Turn off and unplug the machine. Open the filter cover at the bottom front, unscrew the filter, clean it under running water, and reinstall securely.
Why is the machine not spinning?
Check if the unbalanced load detection is active. Redistribute clothes evenly. Also ensure the drain hose is not clogged.
What does the 'Overflow Protection' do?
If water level exceeds a safe limit, the machine automatically drains and stops to prevent flooding. This is a safety feature.
Can I use liquid detergent?
Yes, pour liquid detergent into the detergent dispenser compartment. For powder detergent, use the appropriate compartment.
How do I set a delay start?
Press the Delay button repeatedly to set the delay time (1-24 hours), then press Start/Pause. The machine will start after the set delay.
What is the maximum load for delicate items?
For delicate or hand-washables, load no more than 2 kg to avoid damage.
How do I descale the machine?
Run an empty cycle with a descaling agent (or vinegar) on the highest temperature setting. Repeat every 3 months.
Where can I get spare parts?
Contact TCL customer service or visit the official TCL website for authorized spare parts. Provide the model number XQB80-F303Z.
User questions about XQB80-F303Z TCL
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Washing machine in PDF format for free! Find your manual XQB80-F303Z - TCL and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. XQB80-F303Z by TCL.
USER MANUAL XQB80-F303Z TCL
Operating Instructions
适用型号
XQB70-F303Z
XQB80-F303Z
XQB70-3678Z
二、水平调整和底盖板安装
- 按住滑动器向下压，拔下进水管接头。
Certificate of Quality
检验员：
