| Product Type | Electric leaf blower / vacuum / mulcher |
| Brand | Fieldmann |
| Model | FZV 4003-E |
| Power Source | Mains powered (230 V AC, 50 Hz) |
| Power | 3000 W |
| Air Speed (max) | 250 km/h |
| Air Volume | 800 m³/h |
| Vacuum Function | Yes, with mulching |
| Mulching Ratio | 10:1 |
| Collection Bag Capacity | 45 L |
| Weight | 4.5 kg |
| Dimensions (L x W x H) | approx. 90 x 30 x 35 cm |
| Noise Level | 96 dB(A) |
| Vibration Level | 2.5 m/s² |
| Safety Features | Double insulation, safety switch, thermal overload protection |
| Cleaning | Clean with dry cloth, do not use water |
| Maintenance | Regularly check carbon brushes, clean air vents, lubricate fan if needed |
| Spare Parts | Available from Fieldmann service centers: impeller, bag, switch, carbon brushes |
| Warranty | 24 months |
Frequently Asked Questions - FZV 4003-E Fieldmann
What is the main function of the Fieldmann FZV 4003-E?
The Fieldmann FZV 4003-E is an electric leaf blower, vacuum, and mulcher. It can blow leaves, vacuum them into a collection bag, and shred them to reduce volume.
How do I switch between blowing and vacuuming?
To switch modes, you need to change the tube assembly. For blowing, attach the blower tube; for vacuuming, attach the vacuum tube and collection bag. Refer to the manual for detailed instructions.
Can I use the vacuum function without the collection bag?
No, the vacuum function requires the collection bag to be attached. Operating without it could cause damage or injury.
How do I empty the collection bag?
Open the zipper or clip on the bag, empty the contents into a compost bin or trash, then close securely before reattaching.
What safety precautions should I take when using this device?
Always wear safety goggles and ear protection. Keep children and pets away. Do not use in wet conditions. Avoid contact with the fan area. Use a residual current device (RCD) if using an extension cord.
Why does the motor stop during operation?
The device has thermal overload protection. If the motor overheats, it automatically shuts off. Allow it to cool for at least 10 minutes before restarting. Also check for blockages in the fan or tube.
How do I maintain the carbon brushes?
Carbon brushes should be inspected after every 20 hours of use. If worn to less than 3 mm, replace them with identical brushes from a Fieldmann service center.
Can I use an extension cord?
Yes, use a properly rated extension cord (minimum 1.5 mm² cross-section, max 30 m length). Ensure the cord is suitable for outdoor use.
What should I do if the device vibrates excessively?
Excessive vibration may indicate a loose or damaged impeller. Stop use immediately, unplug the device, and inspect the fan assembly. If damaged, replace the impeller at a service center.
How do I clean the device?
Unplug the device and use a soft, dry cloth to wipe the exterior. Do not use water or solvents. Clean the air vents with a brush to remove dust.
