Product Type	Pedestal Fan
Brand	Tornado
Model	HI-FAN-20HVWM-WR-1P
Blade Diameter	20 inches (approx.)
Number of Speeds	3 (Low, Medium, High)
Oscillation	Yes, wide-angle (approx. 90 degrees)
Tilt Adjustment	Yes, manual tilt (up/down)
Height Adjustment	Yes, adjustable pole (approx. 30-50 inches)
Power Consumption	120 W
Voltage	120 V ~ 60 Hz
Net Weight	5.2 kg (11.5 lbs)
Base Diameter	400 mm (15.7 inches)
Cord Length	1.8 m (5.9 ft)
Material	ABS plastic base, metal blade grille
Safety Features	Overheat protection, anti-tip base
Noise Level	Approx. 55 dB (high speed)
Control Type	Mechanical rotary switch on motor housing
Cleaning	Wipe with damp cloth; do not immerse in water
Replacement Parts	Blades, motor, base, and pole available
Assembly Required	Yes, simple assembly with included tools

Frequently Asked Questions - HI-FAN-20HVWM-WR-1P TORNADO

How to assemble the Tornado HI-FAN-20HVWM-WR-1P?

Assemble the base, pole, motor housing, and blade in order. Use the provided screws and tools. Refer to the manual for step-by-step instructions. Ensure all parts are securely tightened.

How to clean the fan?

Unplug the fan. Wipe the grille, blades, and pole with a damp cloth. Do not use harsh chemicals or immerse the fan in water. Allow all parts to dry completely before use.

Can I use the fan outdoors?

No, this fan is designed for indoor use only. Exposure to moisture or extreme temperatures may damage the fan and pose safety risks.

How to adjust the oscillation?

Pull the oscillation knob (usually on the motor housing) up to engage oscillation. Push down to stop. The fan can be tilted manually for desired direction.

What is the warranty period?

Typically, Tornado offers a 1-year limited warranty against manufacturing defects. Check your purchase receipt or contact customer support for details.

How to reduce fan noise?

Ensure the fan is on a stable surface and all screws are tight. Clean the blades as dust buildup can cause imbalance. If noise persists, contact support.

Does the fan come with a remote control?

No, the HI-FAN-20HVWM-WR-1P uses manual controls (rotary switch and pull knob). Remote control is not included.

What to do if the fan wobbles excessively?

Check that the base is level and screws are tight. Inspect blade balance; you can use a blade balancing kit if needed. Also ensure the pole is fully secured.

Does the motor require lubrication?

No, the motor is sealed and permanently lubricated. Do not attempt to oil the motor as it may cause damage.

Is the height adjustable?

Yes, the fan has an adjustable pole. Loosen the collar, slide the pole to desired height, and tighten firmly. Never adjust while the fan is running.

USER MANUAL HI-FAN-20HVWM-WR-1P TORNADO

Model: HI-FAN-20HVWM-WR-1P

Top-down view of a black Tornado air fan with visible blades and mesh structure (no text or symbols on the fan itself)

PLEASE READ AND SAVE THIS INSTRUCT

Attention: Pictures in the IM are for reference only.

Intended Use:

This product is intended for industrial or commercial use only. Use only with electrical wiring that is in good working order and that meets applicable codes and ordinances. If you have any questions whether your wiring is adequate, consult a qualified electrician.

This fan is suitable for outdoor use.

While using your fan, you should follow the IMPORTANT INSTRUCTIONS listed below. As part of those instructions, we have used the word "WARNING" to indicate the level of hazard: WARNING indicates a hazard which, if not avoided, could result in injury or death.

IMPORTANT INSTRUCTIONS

As with all electrical appliances, basic safety precautions should always be followed to reduce the risk of electric shock, fire, or injury to persons, including the following precautions:

• Read all the instructions before using this fan.
• Use this fan only as described in this manual. Any other use not recommended by the manufacturer may cause electrical shock, fire or injury to persons.
  Do not operate the fan with a damaged power cord or after the fan malfunctions or has been dropped in any manner.
• Use of extreme caution is necessary when any fan is used by or near children, disabled persons or pets and whenever the fan is left operating unattended.
• Do not place the fan on a small, unlevel, uneven or any surface which might allow fan to tip or fall.
• Always unplug fan when not in use, when moving from place to place, when assembling or disassembling parts, and before cleaning.
• The use of attachments, not recommended or sold by the manufacturer, may cause hazards.
• To reduce the risk of fire or electrical shock, do not use this fan with any solid state speed control device.
• Do not operate the fan with blade guards or any safety device removed.
• Automatically operated device - To reduce the risk of injury, disconnect from power supply before servicing.
• If the power supply cord is damaged, contact your local service center or a qualified electrician to install an appropriate replacement cord to prevent any injury or damage.
• Do not use an extension cord with this fan.
• To reduce the risk of injury to persons, install fan at least 2.1m (7 feet) above the floor.
• Do not run power cord under carpeting. Do not cover cord with throw rugs, runners or the like. Arrange cord away from traffic area where it will not be tripped over.
• Do not insert or allow any object to enter any openings on the fan. Doing so may cause electric shock and/or fire hazard. Avoid contact with moving parts.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the appliance.

ReAd & SAve THeSe INSTRUCTIONS

WARNING:

Risk of electrical shock---This fan is supplied with a grounding conductor and GFCI type plug. To reduce the risk of electrical shock, make sure that it is connected only to a PROPERLY grounded outlet.

Use only on GFCI protected receptacles.

To Reduce The Risk Of Electric Shock, Connect Only To An Outlet Provided With A Ground Fault Circuit Interrupting Device.

Do not under any circumstances remove the power plug's ground prong or ground fault unit. For your personal safety, the fan must be grounded.

The fan is equipped with a power supply with ground fault circuit interrupting device. Removal or tampering of power cord will void warranty.

Never use an extension cord to connect the fan to an outlet. All installations must be made into a grounded outlet.

WARNING Electrical Shock Hazard

Do not use with damaged cord or plug. Use with adequate electrical system that is up to code.

⚠️ CAUTION: To reduce the risk of electric shock, connect only to an outlet

WARNING to Reduce the Risk of Fire or Electric

Shock, do not use this product with any solid-state speed control device.

DANGER: Do not submerge motor in water or allow motor to be exposed to water. Personal injury and/or death could result. Never handle the fan or motor with wet hands or when standing on wet or damp surface or in water. Fatal electrical shock could occur.

Installation Instructions

Use the following information as a guideline only. It is the user's responsibility to be sure the location and the wall surface can handle the weight of this fan (14.6 lbs).

The wall fan must be mounted on 12 inch (300mm) thick dry and cement - grouted firm wall or on 4 by 5 inch wood studs / joists.

Use wall bracket as a template for locating the holes to be drilled.

After determining the hole locations, use an appropriate sized drill bit and, drill holes through mounting surface. It is recommended that a minimum of grade 5 fasteners be used. The following are acceptable surfaces for mounting wall mount assembly.

STEEL SURFACE - When mounting to a steel surface, such as vertical I-beam, drill through holes at pre-marked locations, using a 9/32" drill bit. Attach wall mount assembly to mounting surface using 1/4"-20 hex screw, in combination with 1/4" flat washers, 1/4" lock washers, and 1/4"-20 hex nuts.

MASONRY SURFACE - When mounting to a masonry surface use a 1/4" expansion type bolt or 1/4" masonry lag with shield designed to handle the weight of this fan. Drill holes at pre-marked locations using appropriate sized drill bit as recommended for the fastener.

Usage:

Fan operation: Always operate the fan in the upright position following all instructions and recommendations listed in this manual.

Fan location: Place the fan in the area of the room that will provide proper fan cooling.

Fan connection: Plug fan directly into 120 volt A.C., 60 Hz wall outlet. Be sure plug fits tightly in outlet. A loose connection may cause overheating and damage to the plug or fan.

Note: To prevent overloading a circuit, do not plug the fan into a circuit that is servicing other electrical needs.

Speed control: To operate the fan, each pull of the string will cycle through the following settings:

• OFF
- LOW
• MED
• HIGH
• OFF

We are happy to help, contact us: [e-mail]

Care and Maintenance

Cleaning: CAUTION-Before cleaning the fan be sure to disconnect power cord from the plug. Clean the grille surface with a clean damp cloth. Do not use harsh chemical or abrasive cleaners. DO NOT IMMERSE THE FAN OR ANY WIRES IN WATER. Replace front grille before fan use. Allow fan to dry completely before use. Periodic grille cleaning with a vacuum will prevent dust build up. The motor is sealed and does not require any interior maintenance, cleaning or lubrication.

Maintenance: The Internal motor bearings are permanently lubricated at the factory and do not require any additional lubrication.

Repair: DO NOT OPERATE THE FAN WITHOUT THE GRILLE IN PLACE. DO NOT USE THE FAN IF IT HAS MALFUNCTIONED OR BECOME DAMAGED IN ANY WAY.

Storage: Keep original carton for storage of the fan. Coil and tie the power cord to avoid damage during storage.

LIMITED ONE-YEAR WARRANTY

Hexago LLC warrants this product to be free of defects in material and workmanship for the applications specified in the Owner's Manual for a period of 12 months for the whole fan from date of purchase. This warranty only applies to the original purchaser of this product.

This warranty excludes damage, accidental or otherwise, to the unit not caused by a defect in material or workmanship.

The warranty also excludes damage caused by misuse, tampering, modification, missassembly, repairs or alternations, or failure to adequately maintain and care for the unit. Operating this product under any conditions others than those recommended or at voltages other than indicated will also void this warranty. For warranty issues, contact the place of purchase for repair/ replacement opportunities. The original dated receipt or proof of purchase must accompany all returns.

All warranties, expressed or implied, are limited for 12 months for the whole fan from the date of purchase. Please contact us at www.tornadofans.com if you have any questions. Tornado is a registered trademark of Hexago LLC.

Some states do not allow for the limitation or exclusion of incidental or consequential damages, or do not allow limitation on implied warranties. The above limitations and exclusions may not apply to you. This warranty gives you specific legal rights, and may also include other rights that vary state by state.

Customer service email: [e-mail] Website: www.tornadofans.com

202112

FOR CALIFORNIA CONSUMERS ⚠ WARNING: This product can expose you to chemicals including lead and phthalates, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
