XJ10402 - Blender Kunft - Free user manual and instructions

Product Type	Blender
Model	XJ10402
Brand	Kunft
Power	600 W
Capacity	1.5 L
Speed Settings	2 speeds + pulse
Blade Material	Stainless steel
Jug Material	High-grade plastic (BPA-free)
Safety Features	Overload protection, non-slip feet, safety lock lid
Cleaning	Detachable parts dishwasher safe
Dimensions (H x W x D)	40 x 18 x 18 cm
Weight	2.2 kg
Power Cord Length	1.2 m
Warranty	2 years
Colors Available	White, Black

Frequently Asked Questions - XJ10402 Kunft

How do I assemble the blender?

Place the jug on the motor base, align the tabs, and twist clockwise until it locks. Ensure the lid is securely fastened.

Can I blend hot liquids?

No, do not blend hot liquids. Allow them to cool to below 60°C to avoid pressure buildup and damage.

How do I clean the blender?

Detach the jug and lid. Rinse immediately after use. All removable parts are dishwasher safe. Wipe the motor base with a damp cloth.

What is the maximum capacity?

Do not fill beyond the max line (1.5 L for liquids, 1 L for thick mixtures) to prevent overflow.

Why does the blender stop suddenly?

It may be due to overload protection. Unplug, let it cool for 15 minutes, reduce the load, and restart.

Can I crush ice?

Yes, use the pulse function in short bursts for best results. Do not exceed 30 seconds continuous operation.

Is the jug BPA-free?

Yes, the jug is made of high-grade BPA-free plastic, safe for food contact.

How do I replace the blade?

Blades are not user-serviceable. Contact Kunft customer service for replacement. Do not attempt to disassemble the blade unit.

What warranty is provided?

The blender comes with a 2-year warranty covering manufacturing defects. Proof of purchase is required.

Where can I find the user manual?

The manual is available for free download in PDF format at notice-facile.com or from Kunft's official website.

USER MANUAL XJ10402 Kunft

INSTRUCTIONS' MANUAL

MANUAL DE INSTRUÇÕES

White KUNFT blender with clear glass body and control knob, set against a red and orange background (no text or symbols on the device itself)

table blender

XJ10402

Dear client,

We thank you for purchasing this product.

This appliance was submitted to several laboratorial tests, which certify its quality. To simplify the use of this appliance, this instruction manual has been provided. The instructions must ensure a quick and safe use.

Please read carefully the instructions and safety measures described in this manual.

We wish our clients great satisfaction in using their new appliance.

INDEX

1. SAFETY INSTRUCTIONS ....4
2. OPERATING INSTRUCTIONS ....5

2.1. Cooking ....5
2.2. Cleaning ....5
2.3. Cautions of operation ....5

1. AFTERMARKET 6
2. ENVIRONMENT CONSERVATION ....7

table blender XJ10402

KUNFT®

1. SAFETY INSTRUCTIONS

Before using your appliance, read carefully this instruction manual and keep it in a safe place, as you may need it for future consultations.

Before you start your appliance, and to ensure a correct use, do not use it if:

• It has fallen on the ground;
• You notice any evidence of damage;
• Any anomaly occurs during its operation;

In case of verifying any of this situations, allow the technical service from Worten to test the appliance

WARNING:

• Turn the appliance only with the indicated voltage
• The blender must always be disconnected from the power source when:

- during the operation any anomaly arises.

- doing cleaning and maintenance of the device after each use.

• Do not pull the cord to turn the appliance off
• Do not immerge the appliance in water

This appliance can be used by children from 8 years old and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and maintenance shall not be made by children without supervision.

- These instructions are also available on www.suporteworten.pt

IMPORTANT WARNINGS:

• To avoid hazards and deterioration of your appliance by an incorrect use, it is advisable to read the instructions carefully and attentively.
• Your appliance must not be used to other ends than the ones foreseen in the instructions manual. Your safety is only guaranteed in a household use and not for commercial use. The incorrect use will not be covered and automatically cancels the right to warranty.
• The material used in packaging should not be left within the reach of children.
• You should read carefully the instructions manual before the first use.
• Unplug from outlet before removing the jar with the juice or whenever you are not using it.

• The electrical cord must be placed in a way not to be damaged during the operation.

• Keep the appliance away from any source of heat or water.

• If the power cord is damaged, do not use your appliance; take it to an authorized technical assistance to be replaced.

IMPORTANT: During maintenance and cleaning of your appliance be very careful with the blades. These may injure you.

2. OPERATING INSTRUCTIONS

2.1. Cooking

1. Pour the required quantity of cold tap water into the jar. Do not exceed the maximum level (refer to the markings on the inside of the jar). Do not use wine or any other flammable liquid.
2. Place the food into the jar.
3. Place the lid on the jar. Ensure safety in blending.
4. If the food you put is not enough, you can add food through the middle of the lid, and no need remove the whole lid.
5. Plug the blender in.
6. Push the speed knob to whatever mixing speed you need or push the button to pause and hold to keep mixing on. Caution: when mixing at the maximum of 60 seconds, you must stop and wait 60 seconds before resetting.
7. Once mixing is complete, unplug the cooker. Remove the jar carefully.

2.2. Cleaning

1. Remove the plug from the wall socket before cleaning.
2. To clean the jar and lid, use hot soapy water and soft cloth. Do not use abrasive products. It is dishwasher-safe for cut blade, jar and lid.
3. Be especially careful with handling the cut blade.
4. To clean the base, remove any liquid still in the reservoir by tipping up the base over a sink. Clean the inside with a damp cloth and allow to dry. This process can be repeated for the outside of the base.
5. Clean the appliance with a damp cloth and never put it into water or flush it with water.

2.3. Cautions of operation

1. The plug must be removed before cleaning the blender and it must be dried before the blender is used again.
2. Do not use the blender if the lead is damaged.
3. If the power cable on the blender is damaged, it may only be replaced by a repair center recognized by the manufacturer since special tools are required.

table blender XJ10402

KUNFT®

1. The blender must not be immersed in water for cleaning purposes.
2. Do not use the blender for purposes other than that for which it is intended.
3. Before mixing, please ensure the content is not exceeded 1500 mL.

NOTE

• Caution: when mixing at the maximum of 60 seconds, you must stop and wait 60 seconds before resetting.
• A short (or detachable) power supply cord is to be provided to reduce risks resulting from becoming entangled in or tripping over a longer cord.
• Longer extension cords are available and may be used if care is exercised in their use.
• The marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance.
• The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.
• Any other servicing should be performed by an authorized service representative.

3. AFTERMARKET

KUNFT has designed this appliance in order to guarantee the maximum reliability. However, if a problem occurs, by following the procedures suggested in this section you may be able to determine its cause.

Do not attempt to open the appliance - there is a risk of electrical shock.

If you are not able to solve the problem, please contact your seller or manufacturer.

All users must be familiarized with this section. Knowing what could go wrong can help you avoid the occurrence of problems.

WARNING: any attempt of fixing the appliance without contacting the manufacturer will nullify the warranty.

In case the problem persists, take your appliance to an aftermarket section of any Worten, Modelo or Continente store in order to solve the problem.

Worten Equipamentos para o Lar ensures for a period of 2 years, counting from the date of purchase of this appliance, a warranty against any found manufacturing defect. The warranty supposes a correct use and maintenance of the appliance, namely according to the instructions expressed in this manual. In case otherwise identified, the malfunctions will not be under the warranty.

The repairing of electrical appliances must only be made by qualified technicians, as otherwise there may occur future complications on the appliances.

To avoid unnecessary risks, in case there are any malfunctions on the wires or on another type of components, repairing must be made on the specialized locations of technical assistance, as appropriate tools are needed.

4. ENVIRONMENT CONSERVATION

Aiming to protect the environment, we try to reduce to a maximum the volume of the packages which are confined to three easy separation materials: cardboard, paper and plastic.

The appliance is made of recyclable material, once disassembled by a specialized company. Follow the local legislation concerning recycling of all materials.

Imported, produced and distributed by:
