| Product Type | Freezer |
| Brand | Siemens |
| Model | KG55NVL20M |
| Energy Efficiency Class | A+ |
| Climate Class | SN-T |
| Noise Level | 41 dB |
| Freezing Capacity | 12 kg/24h |
| Storage Volume (Net) | 260 L |
| Dimensions (H x W x D) | 1850 x 550 x 600 mm |
| Weight | 65 kg |
| Power Supply | 220-240 V, 50 Hz |
| NoFrost System | Yes, automatic defrost |
| Super Freeze Function | Yes |
| Electronic Temperature Control | Yes, with LED display |
| Temperature Alarm | Yes |
| Door Open Alarm | Yes |
| Adjustable Legs | Yes, front |
| Door Hinge Reversible | Yes |
| Interior Light | LED |
| Storage Baskets | 3 wire baskets |
| Ice Maker | No |
| Warranty | 2 years |
| Repairability Index | 8.0/10 |
Frequently Asked Questions - KG55NVL20M SIEMENS
How to install the Siemens KG55NVL20M freezer?
Ensure the freezer is placed on a level, stable surface with adequate ventilation. Leave at least 10 cm clearance on all sides. Connect to a grounded outlet. Wait 2 hours before loading food.
What should I do if the freezer does not start?
Check the power cord connection and fuse. Verify the thermostat setting is not at '0'. If still not running, contact Siemens service.
How to use the Super Freeze function?
Press the Super Freeze button approximately 24 hours before freezing fresh food. The function automatically deactivates after 50 hours or when the set temperature is reached.
What is the recommended temperature for the freezer?
The ideal temperature is -18°C. Use the electronic controls to adjust between -16°C and -24°C.
How to clean the freezer?
Unplug the freezer. Remove all food and shelves. Clean interior with warm water and mild detergent. Do not use abrasive cleaners. Dry thoroughly before restarting.
Why is there ice buildup in my noFrost freezer?
If ice forms, the door may not be sealing properly. Check the door gasket for debris or damage. Ensure the freezer is not overloaded.
How to change the door swing direction?
The door hinge is reversible. Unscrew the hinge brackets, remove the door, and reattach on the opposite side. Refer to the manual for detailed steps.
What spare parts are available for this model?
Common spare parts include door gaskets, shelves, thermostat, and electronic control boards. Use Siemens genuine parts for repairs.
How to reset the temperature alarm?
The alarm sounds if the interior temperature rises above -9°C. Press the 'Alarm' button to silence. Check if the door was left open or if a large amount of warm food was added.
Is the freezer suitable for garage use?
The climate class SN-T allows operation from 10°C to 43°C ambient temperature. In unheated garages below 10°C, the freezer may not perform correctly.
