| Product Type | Media Player / OPS Module |
| Model | OPS-DRD |
| Brand | NEC |
| Dimensions (W x H x D) | 180 mm x 30 mm x 120 mm |
| Weight | 1.2 kg |
| Power Consumption | 150 W (max) |
| Power Supply | Internal, 19V DC |
| Processor | Intel Core i5 (8th Gen or later) |
| Memory | 8 GB DDR4 |
| Storage | 128 GB SSD |
| Video Outputs | 1x HDMI 2.0, 1x DisplayPort 1.2 |
| Audio Output | HDMI, 3.5 mm stereo jack |
| USB Ports | 2x USB 3.0, 2x USB 2.0 |
| Networking | 1x Gigabit Ethernet, Wi-Fi 802.11ac |
| Operating System | Windows 10 IoT Enterprise |
| Mounting | OPS slot compatible |
| Operating Temperature | 0°C to 40°C |
| Humidity | 20% to 80% (non-condensing) |
Frequently Asked Questions - OPS-DRD NEC
How do I install the OPS-DRD media player into a compatible display?
Insert the module into the OPS slot on the back of the display, ensuring alignment with the guide rails. Push firmly until it clicks into place. Secure with the provided screws. Connect necessary cables (power, video, network) if not already integrated.
What operating system does the OPS-DRD run?
It runs Windows 10 IoT Enterprise or a similar embedded OS. Check your specific model configuration.
Can I upgrade the RAM or storage?
Yes, the module allows user upgrades. The RAM is typically SODIMM DDR4 and storage is a removable M.2 SSD. Refer to the manual for compatible parts and installation.
Why is there no video output after installation?
Ensure the display is powered on and set to the correct input source (OPS). Check that the module is fully inserted and locked. Try reseating the module. If the issue persists, verify the power supply and LED indicators.
How do I perform a factory reset?
Press and hold the reset button (if available) for 10 seconds. Alternatively, access Windows recovery options by pressing F11 during boot and selecting 'Reset this PC'.
What video resolutions are supported?
Supports up to 4K UHD (3840x2160) at 60 Hz via HDMI or DisplayPort. Lower resolutions are also supported.
How can I update the firmware?
Download the latest firmware from NEC's support website. Copy the firmware file to a USB drive, insert into the module, and follow the on-screen instructions in the BIOS update utility (accessible during boot).
Does the OPS-DRD support audio output?
Yes, audio is transmitted via HDMI/DisplayPort to the display. There is also a 3.5 mm headphone jack for local audio output.
What are the power requirements?
The module requires 19V DC input from the display's OPS connector or an external power adapter. Maximum power consumption is 150 W.
Is the OPS-DRD compatible with all NEC displays?
It is compatible with NEC displays that have an OPS slot conforming to the Intel OPS standard. Check your display's specifications or contact NEC support for compatibility.
