| Type | Active PA Speaker |
| Model | EVF-1122D/94 |
| Brand | Bosch |
| Power Output (RMS) | 200 W |
| Peak Power | 400 W |
| Frequency Response | 50 Hz - 20 kHz |
| Impedance | 8 Ohms |
| Sensitivity | 95 dB (1W/1m) |
| Driver Configuration | 1x 12" woofer, 1x 1" compression driver |
| Crossover Frequency | 2 kHz |
| Enclosure Material | Plywood with black coating |
| Dimensions (H x W x D) | 600 x 350 x 300 mm |
| Weight | 12 kg |
| Input Connectors | XLR combo, RCA, 1/4" TRS |
| Output Connectors | XLR through |
| Cooling | Passive (no fan) |
| Protection Features | Overload, thermal, short circuit |
| Mounting Options | Pole mount, fly points |
| Operating Temperature | 0°C to 40°C |
| Cleaning Instructions | Wipe with dry cloth; do not use solvents |
| Safety Certifications | CE, UL, RoHS |
| Spare Parts Availability | Contact Bosch service centers |
| Warranty | 2 years |
Frequently Asked Questions - EVF-1122D/94 BOSCH
How do I connect the EVF-1122D/94 to a mixer?
Use a balanced XLR cable to connect the mixer output to the XLR combo input on the speaker. Ensure the mixer and speaker are powered off during connection.
Can I use this speaker outdoors?
Yes, but it is not weatherproof. Protect it from rain and extreme humidity. Avoid direct sunlight for extended periods.
How do I clean the speaker grille?
Remove the grille if possible and vacuum gently with a soft brush attachment. Wipe the cabinet with a damp (not wet) cloth. Do not use abrasive cleaners.
What is the maximum power handling of this speaker?
The RMS power handling is 200W, with a peak of 400W. Exceeding these ratings may damage the speaker.
Does the EVF-1122D/94 have built-in Bluetooth?
No, this model does not include Bluetooth. It is a passive (or active) PA speaker with wired inputs only.
Can I mount this speaker on a wall?
Yes, it has fly points for rigging. Use appropriate hardware and consult a professional installer for safe mounting.
Why is there no sound coming from the speaker?
Check power connections, volume levels, and signal cables. Ensure the mixer or source is sending audio. Verify the speaker is turned on and not in standby mode.
What type of cable should I use for the speaker?
For passive speakers, use heavy-gauge speaker wire (e.g., 12 AWG) for long runs. For active models, use balanced XLR or TRS cables.
How do I update the firmware on this speaker?
The EVF-1122D/94 does not have user-updatable firmware. Contact Bosch support for any firmware updates.
Where can I find replacement parts?
Contact an authorized Bosch service center. Spare parts such as drivers, grilles, and amplifier modules are available through their network.
