USER MANUAL AKR 469 IX WHIRLPOOL
MAIN FEAMAIN FEATURESTURES
| Product group | абсорбатори |
| Colour body | Инокс |
| Material body Metal | |
| Colour chimney N/A | |
| Material chimney N/A | |
| Typology Pull-out | |
| Installation type Built-in | |
| Type of control Mechanical | |
| Type of control settings - | |
| Decor panel options Possible and included | |
| Motor location | Integrated motor in hood body |
| Operating Mode Convertible | |
| Electrical connection rating (W) 156 | |
| Current (A) 0,7 | |
| Voltage (V) | 220-240 |
| Frequency (Hz) | 50/60 |
| Length of Electrical Supply Cord (cm) | 150 |
| Plug type | Schuko |
| Chimney height (mm) | 0 |
| Height of product, without chimney (mm) | 211 |
| Height of the product | 180 |
| Width of the product | 599 |
| Depth of the product | 300 |
| Minimum niche height | 0 |
| Minimum niche width | 0 |
| Niche depth 0 | |
| Net weight (kg) | 6 |
TECHNICAL FEATURESTURES
| Type of manual control devices | Buttons |
| Type of automatic control devices | - |
| Number of motors | 1 |
| Total power of the motors (W) | 100 |
| Number of speed settings: boost option availability | 2 |
| Boost presence No | |
| Maximum output air extraction ( m3/h ) | 271 |
| Boost position air extraction ( m3/h ) | 0 |
| Maximum output recirculating air ( m3/h ) | 163 |
| Boost position output recirculating ( m3/h ) | 0 |
| Light Control Type | On/Off |
| Number of lights | 2 |
| Type of lamps used | Halogen |
| Total power of the lamps (W) | 56 |
| Diameter of air outlet (mm) | 120 |
| No-return airflow flap | Yes |
| Grease filter material | Washable aluminium |
| Odour filter | No |
ENERGY LABEL
| Sound power at min. speed (2010/30/EU) | 46 |
| Sound power at max. speed (2010/30/EU) | 57 |
| Noise level with boost position (dB(A) re 1 pW) | 0 |
