Product Type	Master Key System
Brand	Dormakaba
Model	Master Key Systems
Category	Access Control - Key Systems
Dimensions (Typical Cylinder)	Diameter: 17 mm, Length: 30-40 mm
Weight (Typical Cylinder)	Approx. 30 g
Power Supply	None (mechanical) or Battery (electronic versions)
Main Functions	Master keying, hierarchical access control, replaceable cylinders
Security Features	Patented keyways, anti-drill pins, hardened steel inserts
Key Types	Master keys, sub-master keys, change keys
Key Duplication Control	Restricted key blanks, security cards required
Material	Brass, steel, nickel silver
Maintenance	Lubricate with graphite powder annually, clean with dry cloth
Cleaning	Do not use water or solvents; use a soft brush for debris
Spare Parts Available	Cylinders, keys, security cards, springs, pins
Repairability	User replaceable springs and pins; cylinder replacement by locksmith
Certifications	EN 1303, ANSI/BHMA Grade 1
Warranty	Limited lifetime warranty for mechanical defects
Country of Origin	Germany, China
Included Accessories	Installation screws, fixing screws, instruction manual

Frequently Asked Questions - Master Key Systems Dormakaba

What is a master key system?

A master key system allows a single key (master key) to open multiple locks, while each individual lock has its own unique change key. It provides hierarchical access control, e.g. a building master key opens all doors, a floor master key opens only those on a floor.

How do I order additional keys for my Dormakaba master key system?

Additional keys must be ordered from a Dormakaba authorized dealer or locksmith. You will need the key number or security card. Key duplication is restricted to prevent unauthorized copies.

Can I rekey my Dormakaba master key system myself?

Rekeying (changing the pin combination) requires specialized tools and knowledge. It is recommended to have a licensed locksmith perform rekeying to maintain security and master key hierarchy.

What maintenance is required for the system?

Periodically lubricate the cylinder with graphite powder (not oil). Clean the keyway with a soft brush to remove debris. Avoid water or chemical cleaners. If the key becomes hard to turn, consult a locksmith.

Are Dormakaba master key systems compatible with other brands?

No, Dormakaba uses patented keyways and proprietary pin sizes. Cylinders and keys are not interchangeable with other brands. Always use Dormakaba genuine parts.

How secure are these systems?

Dormakaba master key systems include features like anti-drill pins, hardened steel inserts, and patented key control. They meet security standards such as EN 1303 and ANSI/BHMA Grade 1, providing high resistance to picking and drilling.

What is a security card?

A security card is provided with each master key system. It contains the key code and must be presented to order duplicate keys or additional cylinders. Keep it in a safe place.

Can I integrate this system with an electronic access control?

Yes, Dormakaba offers electronic cylinders and hybrid solutions that combine mechanical master keying with electronic access control, such as keypads or RFID readers. Contact Dormakaba for compatible options.

What should I do if a key breaks in the lock?

Do not force it. Use a lubricant like graphite and try to extract with tweezers or a broken key extractor. If unsuccessful, call a locksmith. Avoid drilling the cylinder unless necessary.

How long does a Dormakaba master key system typically last?

With proper maintenance, the mechanical parts can last decades. Springs may weaken over time but are replaceable. The key finish may wear, but functionality remains. The system is designed for long-term use.

USER MANUAL Master Key Systems Dormakaba

Dear Valued DORMA Customer,

Please include this Key System Specification Form with your purchase order and keying schedule.

Fax to 800-274-9724 or email to [e-mail].

Thank you.

General Information

YOUR ORDER CANNOT BE ENTERED OR MANUFACTURED WITHOUT THIS INFORMATION

A. DORMA Dealer PO Number
B. Contact Person Date ____ ____
C. Contact Phone
D. Contact Email ____

(To send edited keying schedule or other documents for review)

E. Name of DORMA Rep ____

F. Is this a new or existing key system with DORMA? □ new □ existing with DORMA

G. If existing, what is the Registry number or prior DORMA order number? ____

H. Project name and complete address with zip code:

I. What type of project is this?

(Airport, condo, condo complex, apartment, hospital, nursing home, office building, office park, private school, school district, college, university, retail, industrial, manufacturing, government, military, etc.)

System Architecture and Expansion – Please Select Only One

☐ One Level of Keying – Not Master Keyed

A. How many changes will be required? ____

B. Does the attached order constitute the completed project □ or just a portion? □

C. What is the approximate number of locked openings on the completed project? ____

□ Two Levels of Keying – Master Key System

A. How many changes will be required? ____

B. Does the attached order constitute the completed project □ or just a portion? □

C. What is the approximate number of locked openings on a completed project? ____

☐ Three Levels of Keying – Grand Master Key System

A. How many separate masters will be required under the grand master? ____

B. What is the maximum number of changes required under any given master? ____

C. Does the attached order constitute the completed project □ or just a portion? □

D. What is the approximate number of locked openings on the completed project? ____

☐ Four Levels of Keying – Great Grand Master Key System

A. How many separate grand masters will be required under the great grand? ____

B. What is the maximum number of masters required under any given grand master? ____

C. What is the maximum number of changes required under any given master? ____

D. Does the attached order constitute the completed project or just a portion? □

E. What is the approximate number of locked openings on the completed project? ____

A. Keyway

□ SC Conventional Cylinders BA 7-pin Small Format IC

□ SC Large Format IC D100 7-pin Small Format IC DORMA SKC

- Complete B Below

☐ Other (Specify) D100 7-pin Conventional SKC

- Complete B Below

B. For DORMA SKC Keyway Only (D100 - D600)

□ Existing Project – Please furnish project / site number ____

□ New SKC Project

This project will be maintained by □ DORMA □ CKC □ New Commercial Key Cutter

Name of existing DORMA Commercial Key Cutter who will maintain this project ____

CKC Phone/Email

□ New Commercial Key Cutter Agreement Attached

☐ End user has in-house lockshop and wants to be a DORMA Institutional Key Cutter

□ New Institutional Key Cutter Agreement Attached

Name of End User Locksmith ____

End User Lockshop Phone ____

Special Keying Required

☐ Cross Keying – Please furnish complete specifications using BHMA keying symbols.

□ Construction master keying – Causes a loss of 75% of combinations.

Temporary cores or cylinders are highly recommended for larger systems.

□ Selective master keys (JAN, HKP, etc.)

Each selective causes a loss of 25 % of combinations.

□ SKD combinations under system control

□ SKD combinations under a separate control

Cylinders and Key Marking

Cylinders Keys

☐ Ink in concealed place (default) Key Symbol (default)

☐ Stamp (engrave) see price list for charges,

characters, warranty, etc.

□

□ DND

□ US Property

□ Special – Please attach with specifics

Key Quantities Per Key Symbol Per Lock Key Packaging

Control Keys Pack CKs separately (default)	□
GGGMKs Pack CKs in cylinder boxes	□
GGMKs	*All Master Keys and Controls are always packed separately and sent Signature Required.GMKs
Master Keys	Send bitting list if required to:
Change Keys
Construction MKs
Selective MKs
Emergency MKs
	or via e-mail:

Shipping

All locks and keys will be shipped to DORMA Dealer unless otherwise specified below.

NOTE: SKC key blanks may be shipped only to Authorized DORMA Key Cutters under contract, and only to the address on www.keyauthorization.com.

Ship Change Keys to: Ship Keyed Locksets to:

Attn: Attn:

Ship Master Keys/ Emergency Keys to: Ship Control Keys to:

Attn: Attn:

For Temporary Core / Cylinder Projects, Ship Construction Master Keys to: Ship Permanent Cores / Cylinders to:

Attn: Attn:
