Product type	Bottle warmer
Brand	Philips
Model	24DV19
Power supply	220-240 V ~ 250 W
Ambient operating temperature	+7°C to +37°C
Protection	PTC temperature controlled heating system
Tank capacity	10 or 20 ml of water
Functions	Bottle heating, jar heating, keep warm
Indicator light	Green (ready) and red (heating) light
Control type	Rotary click selector
Heating ring	Included, necessary for quick heating
Measuring spoon	Included for dosing water
Safety	Do not use without water, do not immerse, do not repair yourself
Cleaning	Damp cloth, without harsh products

Frequently Asked Questions - 24DV19 PHILIPS

How to heat a bottle with the Philips 24DV19?

Fill the reservoir with 10 or 20 ml of water using the measuring spoon. Place the bottle in the container, put the ring on top. Turn the selector to the appropriate setting. The light turns red, then green when the temperature is reached. Remove the bottle, shake gently and check the temperature on the back of your hand.

How to heat a jar of baby food?

Remove the label and lid from the jar. Fill the reservoir with 10 or 20 ml of water. Place the jar in the container and the ring on top. Set the selector to the jar symbol. The light turns red then green. Remove the jar, stir the contents and check the temperature.

What to do if the bottle temperature is too low?

Turn the selector to the right until the light turns red to restart heating. Check the position of the ring and the starting temperature.

What to do if the temperature is too high?

Lower the set temperature. Check the position of the ring and the starting temperature. Let it cool slightly before serving.

How to use the keep warm function?

Set the selector to the keep warm symbol. Do not add water. The thermostat maintains the temperature. Do not exceed one hour for hygiene reasons.

How to clean the bottle warmer?

Unplug the appliance and let it cool. Clean the container and the exterior with a damp cloth. Never immerse the appliance and do not use harsh cleaning products.

What to do if the appliance does not heat up?

Wait 15 minutes between consecutive uses to allow the protective circuit breaker to reset. Make sure the outlet works.

The indicator light does not turn on, what to do?

Shield the light from ambient light to improve visibility. If it still does not light up, contact an authorized service center.

Can I use the bottle warmer without the ring?

No, the ring is necessary for quick heating and correct temperature. Without it, the temperature may be incorrect.

How much water to use for heating?

Use 10 or 20 ml of water depending on the bottle level and starting temperature. The provided measuring spoon allows correct dosing.

USER MANUAL 24DV19 PHILIPS

Instructions for use

English 4

White Philips baby care appliance with control knob and brand logo (no visible text beyond branding)

ultra fast bottle warmer

SBC SC250

PHILIPS

Helpline www.p4c.philips.com

Close-up illustration of a washing machine dial with buttons and control knob (no text or symbols)

Functional Overview - Product illustration on inside flap

① Bottle and jar lifter
② Hand grips
③ Mains plug
④ Click-step control knob
⑤ Indicator lamp
⑥ Ring with water cup
⑦ Container
⑧ Cable reservoir

Important Safeguards

• Read and save these instructions
  • Never use the unit without water in it.
• Do not touch hot surfaces. Use handles or grips.
• Do not move an appliance containing hot liquids.
• Do not immerse appliance, cord or plugs in water or other liquid.
• Close supervision is necessary when the unit is used near children.
• Do not let cord hang over edge of table or counter.
• Do not place on hot surfaces or in a heated oven.
• Test food on inside of hand before serving to ensure it is at a safe temperature for your baby.
  • Use only containers that have been approved for boiling.
• Only use the Baby Bottle Warmer when the ambient temperature is between +7°C and +37°C.

Installation

Before connecting the Baby Bottle Warmer to the mains, check to ensure that the mains outlet is 230V AC.

1 Place the Baby Bottle Warmer out of the reach of children and on a dry, non-slip, horizontal surface.
2 Turn the click-step control knob ④ to the left to the ‘●’ (OFF) position.

The indicator lamp lights green.
3 Unreel the required cable length from the cable reservoir ⑧ and plug into the mains outlet.

Operation

Warming of baby bottles

1 Turn the click-step control knob ④ to the left to the ‘●’ (OFF) position.
2 Connect the bottle warmer to the mains socket.

The indicator lamp lights green.
3 Fill the beaker with 10 or 20ml water by using the water cup of the ring ⑥. The content is depending on the bottle filling and start temperature (see Heating Overview on page 3).
4 Place the bottle in the middle of the beaker and put the ring ⑥ on top of it.
5 Use the click-step control knob ④ to set the correct setting (see Heating Overview on page 3).
The indicator lamp lights red.
When the right temperature is reached the indicator lamp will light green.
6 Remove the bottle from the container and turn the control knob to the '●' (OFF) position.

7 Shake the bottle a little bit to distribute the heat evenly before you allow your baby to drink.
8 Check that the contents of the bottle are the correct temperature by pouring a few drops on the back of your hand.

Notes!

• The ring ensures that the hot steam heats up the bottle extremely fast to the right temperature. Warming the bottle without the ring, might result in a wrong temperature, therefore never use the bottle warmer without the ring.
• The dimensions of the bottle or the material of the bottle (glass in stead of plastic) may influence selecting the correct knob setting. Therefore always control the end temperature and adjust the setting of the knob.

Warning! When you leave the bottle in the bottle warmer after it is heated up, the temperature might increase a few degrees.

Warming baby food jars

1 Turn the click-step control knob ④ to the left to the ‘●’ (OFF) position.
2 Connect the bottle warmer to the mains socket.

The indicator lamp lights green.
3 Remove the label and lid from the jar.
4 Fill the beaker with 20ml water by using the water cup of the ring.
5 Place the jar in the middle of the container and put the ring on top of it.
6 Set the click-step control knob to the 🔊 symbol.

The indicator lamp lights red.

When the right temperature is reached the indicator lamp will light green.

7 Remove the jar from the container and turn the control knob to the left to the '●' (OFF) position.
8 Stir the contents of the jar to distribute the heat.
9 Always check that the contents of the jar are at the correct temperature by testing some on the back of your hand or via your mouth.
10 If the temperature is much too low, fill the beaker again with 10ml. Turn the click-step control knob ④ to the right until the indicator lamp lights up red to start the heating up again.

Note! The ring ensures that the hot steam heats up the jar extremely fast to the right temperature. Warming the jar without the ring, might result in a wrong temperature, therefore never use the bottle warmer without the ring.

Keeping warm

With the Baby Bottle Warmer you can also keep the bottles and jars warm for a short time.

To do this set the control knob to the 📄 symbol. Do not add water. The thermostat ensures that the set temperature is maintained. For microbiological and hygienic reasons baby food should never be kept warm for longer than one hour.

Note! Never hold the Baby Bottle Warmer in your hands when in use.

Maintenance

Cleaning

- Disconnect the Baby Bottle Warmer from the mains socket and allow it to cool down. Clean the container and the outside of the Baby Bottle Warmer with a damp cloth.

Notes: – Never immerse the Baby Bottle Warmer in water. – Do not use cleaning or scouring agents.

Warning: If a fault occurs, consult a Philips' service centre. Under no circumstances should you try to repair the Bottle Warmer yourself, do not dismantle. Servicing should be performed by qualified service personnel only.

Technical Specifications

Power supply (mains): 220-240V AC Power consumption (mains): 250 Watts Operational ambient temperature: between +7°C and +37°C Protection: PTC temperature controlled

Problem solving
Problem	Solution
Temperature too low.	Turn the click-step control knob4 to the right until the indicator lamp lights up red to start the heating up again.Check ring filling and start temperature.
Temperature too high.	Lower the adjustment setting.Check ring filling and start temperature.
The jar has not been heated correctly.	Stir the contents from time to time while heating. Check that the click-step control knob is in the position.
Unit does not warm up.	Wait 15 minutes between consecutive uses to allow the safety cut-out to reset.
The indicator light switches on and off while keeping warm.	This is normal; it may turn on or off while heating.
Indicator light does not seem to light.	Shield indicator from ambient light to improve visibility.
The bottom of the tank is spotted.	Hard water deposits are normal and may increase if your water is very hard; remove the deposits periodically with white vinegar (see maintenance).

Fonctionnement -
