Arjes 280 - Roof box G3 - Free user manual and instructions

Type	Roof box
Brand	G3
Model	Arjes 280
External dimensions (L x W x H)	Approx. 220 x 80 x 40 cm
Internal capacity	Approx. 400 L
Maximum load	50 kg
Weight	20 kg
Material	ABS plastic
Color	Black / dark gray
Locking system	Central locking with key
Opening	Double-sided opening
Mounting system	Quick-clamp brackets
Compatibility	Fits most roof bars
Aerodynamic design	Yes, optimized for low drag
Maintenance	Clean with mild soap and water; avoid high-pressure washers
Safety	Secure load evenly; observe maximum load; regularly check mountings
Spare parts available	Replacement keys, mounting kits
Repairability	Shell replacement possible via manufacturer

Frequently Asked Questions - Arjes 280 G3

How do I install the roof box on my car?

Place the roof box on the roof bars, align it centrally, and tighten the clamps using the provided tool. Ensure the box is securely fastened before driving.

What is the maximum weight I can put inside the Arjes 280?

The maximum load is 50 kg. Distribute weight evenly and do not exceed this limit to ensure safety and vehicle handling.

Can I open the roof box from both sides?

Yes, the Arjes 280 features double-sided opening for easy access from either side of the vehicle.

How do I clean and maintain the roof box?

Clean with mild soap and water. Avoid abrasive cleaners or high-pressure washers. Inspect locks and mountings periodically.

Does the roof box fit all roof bar systems?

It fits most standard roof bars. Check the width and profile of your bars; adapters may be required for non-standard systems.

What should I do if I lose the keys?

Contact G3 customer service to order replacement keys. Have your model and serial number ready.

Is the roof box aerodynamic?

Yes, it has an aerodynamic shape to reduce wind noise and drag, improving fuel efficiency.

Can I use the roof box in winter?

Yes, but ensure the locks are not frozen. Use a de-icer if necessary. The plastic withstands low temperatures.

How do I secure the roof box against theft?

Always lock the box with the central locking system. You can also use additional cable locks through the mounting brackets.

What is the warranty period?

G3 offers a 2-year warranty on manufacturing defects. Keep your purchase receipt for proof.

USER MANUAL Arjes 280 G3

FIXING KIT - 1 (cod. K9.009)

Four identical mechanical clamp components with mounting holes, arranged in a 2x2 grid (no text or symbols)

FIXING KIT-2 (cod. K9042)

piega

			DUAL SET
SPARK 320	7 kg / 15.43 lbs 50 kg / 110.23 lbs
SPARK 400	10 kg / 22.04 lbs 75 kg / 165.34 lbs		•
SPARK 420	12 kg / 26.45 lbs 75 kg / 165.34 lbs		•
SPARK 480	13 kg / 28.66 lbs 75 kg / 165.34 lbs		•
SPARK 520 all versions	16.4 kg / 36.15 bc 75 kg / 165.34 lbs		•
SPARK.ECO 320	7.5 kg / 16.53 lbe 50 kg / 110.23 lbs
SPARK.ECO 400	10 kg / 22.04 lbs 75 kg / 165.34 lbs
SPARK.ECO 480	13 kg / 28.66 lbs 75 kg / 165.34 lbs
SPARK.ECO 520	16 kg / 35.27 lbs 75 kg / 165.34 lbs
ABSOLUTE 320	7.5 kg / 16.53 lbs 50 kg / 110.23 lbs
ABSOLUTE 400	11 kg / 24.25 lbs 75 kg / 165.34 lbs		•
ABSOLUTE 480	13 kg / 26.66 lbs 75 kg / 165.34 lbs		•
ALL-TIME 320	7.5 kg / 16.53 lbs 50 kg / 110.23 lbs
ALL-TIME 400	11 kg / 24.25 lbs 75 kg / 165.34 lbs
ALL-TIME 480	13 kg / 26.66 lbs 75 kg / 165.34 lbs
REEF 270	6.5 kg / 14.33 bbs 50 kg / 110.23 lbs
REEF 390	10.5 kg / 23.14 lbs 75 kg / 165.34 lbs		•
REEF 580	16 kg / 35.27 lbs 75 kg / 165.34 lbs		•
HELIOS 320	7.5 kg / 16.53 lbs 50 kg / 110.23 lbs
HELIOS 400 all versions	10 kg / 22.04 lbs 75 kg / 165.34 lbs		•
HELIOS 480 all versions	13 kg / 26.66 lbs 75 kg / 165.34 lbs		•
KRONO 320 all versions	7.5 kg / 16.53 lbs 50 kg / 110.23 lbs
KRONO 400	10 kg / 22.04 lbs 75 kg / 165.34 lbs
KRONO 480	13 kg / 26.66 lbs 75 kg / 165.34 lbs
ARJES 280	9 kg / 19.84 lbs 50 kg / 110.23 lbs
ARJES 320	7.5 kg / 16.53 lbs 50 kg / 110.23 lbs
ARJES 480	13.5 kg / 20.76 lbs 75 kg / 165.34 lbs		•
HYDRA 280	9 kg / 19.84 lbs 50 kg / 110.23 lbs
HYDRA 320	7.5 kg / 16.53 lbs 50 kg / 110.23 lbs
HYDRA 480	13.5 kg / 20.76 lbs 75 kg / 165.34 lbs
PEGASO 320	7.5 kg / 16.53 lbs 50 kg / 110.23 lbs
PEGASO 340	10 kg / 22.04 lbs 75 kg / 165.34 lbs		•
PEGASO 450	13.5 kg / 20.76 lbs 75 kg / 165.34 lbs		•
SIRIO 320	7.5 kg / 16.53 lbs 50 kg / 110.23 lbs
SIRIO 340	10 kg / 22.04 lbs 75 kg / 165.34 lbs
SIRIO 450	13.5 kg / 29.76 bbs 75 kg / 165.34 lbs
CARGO 3	10.5 kg / 23.14 lbs 75 kg / 165.34 lbs
CARGO 4	11 kg / 24.25 lbs 75 kg / 165.34 lbs
CARGO 5	12.5 kg / 27.56 bbs 75 kg / 165.34 lbs
CARGO 6	16 kg / 35.27 lbs 75 kg / 165.34 lbs

-2-

piega

3

4A

FIXING KIT-1

-3

piega

4B

FIXING KIT - 2

piega

piega
