Product Type	Gas water heater
Brand	Junkers
Model	TA 213 A
Energy Source	Natural gas or propane
Ignition Type	Piezo electronic ignition
Heating Capacity	Approximately 20 kW
Dimensions (H x W x D)	700 x 400 x 250 mm
Weight	Approximately 12 kg
Water Connection	1/2 inch BSP
Gas Connection	1/2 inch BSP
Flue Type	Room-sealed or open flue (depending on installation)
Safety Features	Flame failure device, overheat protection
Control	Manual gas valve and temperature selector
Maintenance	Annual servicing by qualified technician
Spare Parts Availability	Common parts available through authorized dealers
Noise Level	< 50 dB(A)
Efficiency Rating	Energy class B (typical)
Installation	Wall-mounted indoor only

Frequently Asked Questions - TA 213 A Junkers

What type of gas does the Junkers TA 213 A use?

The Junkers TA 213 A is designed for natural gas but can be converted to propane with a conversion kit.

How do I ignite the water heater?

Turn the gas knob to the pilot position, press and hold it, then press the piezo igniter button repeatedly until the pilot lights. Hold the knob for 30 seconds, then release and turn to the desired temperature.

Why does the pilot light go out frequently?

This may be due to a faulty thermocouple or a draft. Clean the thermocouple or replace it if necessary. Ensure the draft diverter is not blocked.

What maintenance is required?

Annual servicing by a qualified gas technician is recommended. This includes cleaning the burner, checking the flue, and testing safety devices.

What is the water pressure requirement?

The minimum water pressure for proper operation is 0.5 bar, and the maximum is 10 bar. If pressure is too low, a booster pump may be needed.

Can I install the TA 213 A outdoors?

No, this model is designed for indoor installation only. Outdoor installation would void the warranty and pose safety risks.

How do I adjust the water temperature?

Turn the temperature selector knob clockwise to increase temperature and counterclockwise to decrease. The range is typically 35°C to 60°C.

What does the error code 'E1' mean?

An 'E1' code indicates a flame failure. Check that the gas supply is on, the thermocouple is clean, and the pilot is lit. If the problem persists, call a technician.

Where can I find spare parts?

Spare parts such as the thermocouple, gas valve, and burner are available from Junkers authorized dealers or online retailers.

Is the TA 213 A energy efficient?

This model has a typical energy class of B. For higher efficiency, consider a condensing model, but the TA 213 A is reliable and cost-effective.

USER MANUAL TA 213 A Junkers

Simple line drawing of a two-tiered structure with no text or symbols

2975-04c.1/0

Simple line drawing of a vertical structure with horizontal beams and a triangular top (no text or symbols)

2975-04d.1/0

Simple line drawing of a door with a chimney above it (no text or symbols)

2975-046.1/0

Simple line drawing of a two-panel window frame with a small icon below (no text or symbols)

2975-041.1/0

2975-04g.1/0
