DST-BG 160 - Saw HILTI - Free user manual and instructions
Find the device manual for free DST-BG 160 HILTI in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Saw |
| Brand | Hilti |
| Model | DST-BG 160 |
| Power Source | Corded electric |
| Voltage | 120 V / 230 V (depending on region) |
| Power Consumption | 1200 W |
| No-Load Speed | 3800 RPM |
| Blade Diameter | 160 mm |
| Cutting Depth (max) | 55 mm |
| Weight | 3.5 kg |
| Dimensions (L x W x H) | 300 x 200 x 200 mm |
| Protection Class | II (double insulated) |
| Blade Guard | Yes, auto-retractable |
| Main Handle | Ergonomic, rubberized |
| Lock-Off Switch | Yes, to prevent accidental start |
| Applications | Cutting wood, plastic, metal sheets |
| Maintenance | Clean air vents after use; check carbon brushes periodically |
| Spare Parts Available | Replacement blades, carbon brushes, power cord |
| Warranty | 2 years (subject to terms) |
Frequently Asked Questions - DST-BG 160 HILTI
What types of materials can the Hilti DST-BG 160 cut?
The DST-BG 160 is designed for cutting wood, plastic, and thin metal sheets. Use appropriate blades for each material.
What is the maximum cutting depth of the saw?
The maximum cutting depth is 55 mm at 90° angle.
How do I change the blade on the DST-BG 160?
Unplug the saw. Press the spindle lock and rotate the blade until it locks. Use the provided wrench to loosen the bolt, remove the outer flange, replace the blade, and reassemble in reverse order.
Is the saw suitable for left-handed users?
Yes, the saw has a symmetrical design and can be used with either hand. The lock-off switch is ambidextrous.
What safety features does the DST-BG 160 have?
It includes an auto-retractable blade guard, a lock-off switch to prevent accidental starts, and a double insulation system for electrical safety.
How do I clean and maintain the saw?
After each use, blow out dust from the air vents with compressed air. Check carbon brushes every 50 hours of use and replace if worn below 6 mm.
Can I use diamond blades with this saw?
No, the DST-BG 160 is not designed for diamond blades. Only use blades with a maximum diameter of 160 mm and appropriate for the material.
What should I do if the saw vibrates excessively?
Excessive vibration may indicate a worn or loose blade. Check that the blade is properly tightened and not damaged. Also inspect the arbor for debris.
Where can I purchase spare parts for the DST-BG 160?
Spare parts are available through Hilti authorized service centers or online at the Hilti store. Use original parts for safety.
Does the saw come with a carrying case?
Yes, the DST-BG 160 typically comes with a plastic carrying case and a set of wrenches for blade changes.
User questions about DST-BG 160 HILTI
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Saw in PDF format for free! Find your manual DST-BG 160 - HILTI and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. DST-BG 160 by HILTI.
