| Product Type | Public Address Speaker |
| Model | LB6-100S |
| Brand | Bosch |
| Dimensions (H x W x D) | 200 x 120 x 120 mm |
| Weight | 1.2 kg |
| Power Handling (RMS) | 6 W |
| Impedance (100V line) | 8 ohms |
| Frequency Response | 100 Hz - 15 kHz |
| Sensitivity (1W/1m) | 89 dB |
| Maximum SPL | 97 dB |
| Coverage Angle | 90° conical |
| Input Connection | Screw terminals |
| Material | ABS plastic, steel grille |
| Color | White (RAL 9010) |
| Protection Rating | IP54 |
| Operating Temperature | -25°C to +55°C |
| Mounting | Wall or ceiling bracket included |
| Application | Background music and paging |
| Compliance | EN 54-24 |
| Accessories Included | Bracket, mounting screws, manual |
Frequently Asked Questions - LB6-100S BOSCH
What is the power rating of the Bosch LB6-100S speaker?
The Bosch LB6-100S has a power handling of 6 W RMS on a 100V line, suitable for low-power background music and paging applications.
Is the LB6-100S suitable for outdoor use?
Yes, the speaker has an IP54 protection rating, making it resistant to dust and water splashes, ideal for covered outdoor areas.
What mount is provided with the speaker?
The package includes a wall/ceiling bracket that allows flexible tilt and rotation for optimal sound direction.
How do I connect the LB6-100S to a 100V line?
Use the screw terminals on the back of the speaker. Connect the amplifier's 100V line to the input, ensuring correct polarity for multiple speakers.
What is the frequency range of this speaker?
The frequency response is 100 Hz to 15 kHz, providing clear speech reproduction and decent music playback for announcements.
Can the LB6-100S be used as a replacement for older Bosch models?
Yes, it is designed to be backward compatible with Bosch's standard 100V line systems and can replace older models like LB2-100S.
Does the speaker have a built-in transformer?
Yes, the LB6-100S includes a line transformer for 100V operation, with a tap for 6W (and possibly lower taps like 3W, 1.5W). Check the manual for other taps.
What is the dispersion angle of the speaker?
The speaker has a 90° conical coverage angle, ensuring even sound distribution in a wide area.
Is the LB6-100S compliant with safety standards?
Yes, it complies with EN 54-24 (voice alarm systems) and other relevant European safety and performance standards.
How to clean and maintain the speaker?
Use a soft dry cloth to clean the enclosure. Avoid solvents or water. Check connections periodically and ensure the grille is free from debris.
