| Product Type | Electric Vehicle Charger (Wallbox) |
| Model | EVLunic Pro M W22-G4-R-0 |
| Brand | ABB |
| Dimensions (H x W x D) | Approx. 400 x 250 x 150 mm |
| Weight | Approx. 2.5 kg |
| Input Voltage | 230 V AC, 50/60 Hz |
| Output Power | Up to 22 kW (3-phase) |
| Charging Standard | Mode 3 (IEC 61851-1) |
| Connector Type | Type 2 socket (IEC 62196-2) |
| Cable Length | Integrated cable, 5 m (typical) |
| Communication | Wi-Fi, Ethernet, OCPP 1.6 |
| Display | LED status indicators |
| Protection Class | IP54 (indoor/outdoor) |
| Safety Features | Overcurrent, overvoltage, ground fault, surge protection |
| Operating Temperature | -25°C to +50°C |
| Mounting | Wall-mounted |
| Maintenance | Regular visual inspection; clean with dry cloth |
| Spare Parts | Contact ABB customer service for authorized parts |
| Warranty | 2 years (standard) |
| Compliance | CE, UKCA, RCM |
| Included Accessories | Mounting bracket, screws, quick start guide |
Frequently Asked Questions - EVLunic_Pro_M_W22-G4-R-0 ABB
What is the maximum charging power of the ABB EVLunic Pro M W22-G4-R-0?
The ABB EVLunic Pro M W22-G4-R-0 supports up to 22 kW on a 3-phase supply, making it suitable for fast home or commercial charging.
Can I install the charger outdoors?
Yes, the charger has an IP54 rating, meaning it is protected against dust and water splashes, making it suitable for outdoor installation.
What type of connector does this charger use?
It features a Type 2 socket (IEC 62196-2), the standard for AC charging in Europe.
Is the charger compatible with all electric vehicles?
Most EVs with a Type 2 inlet are compatible. However, some older models may require an adapter. Check your vehicle's manual.
How do I connect the charger to my home network?
The charger supports Wi-Fi and Ethernet for network connectivity. Use the ABB app or web interface to configure settings.
What safety features are included?
The charger includes overcurrent, overvoltage, ground fault, and surge protection. It also has a residual current device (RCD).
Can I schedule charging times?
Yes, through the ABB app or OCPP-compatible backend, you can set charging schedules to take advantage of off-peak tariffs.
How do I clean and maintain the charger?
Use a soft, dry cloth to clean the exterior. Avoid water or cleaning agents. Regularly check for physical damage and ensure vents are clear.
What is the warranty period?
The charger comes with a 2-year warranty from the date of purchase. Extended warranties may be available through ABB.
Where can I find spare parts or repair services?
Contact ABB customer support or an authorized service partner. Use only genuine ABB parts to maintain safety and compliance.
