FM Stereo/FM-AM Tuner

ST-JX531

Operating Instructions

Before operating the unit, please read this manual thoroughly and retain it for future reference.

OWNER'S RECORD

The model and serial numbers are located at the rear. Record the serial numbers in the spaces provided below. Refer to them whenever you call upon your Sony dealer regarding this product.

Model No. ST-JX531 Serial No.

WARNING

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

AUTION

you are cautioned that any change or modifications not pressly approved in this manual could void your authority operate this equipment.

Precautions

On safety

• Operate the unit only on 120 V AC, 60 Hz.
• The name plate indicating operating voltage, power consumption, etc. is located on the rear of the unit.
• Should any solid object or liquid fall into the unit, unplug it and have it checked by qualified personnel before operating it any further.
• Unplug the unit from the wall outlet if it is not to be used for an extended period of time. To disconnect the cord, pull it out by grasping the plug. Never pull the cord itself.
• One blade of the plug is wider than the other for the purpose of safety and will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet, contact your dealer.

On installation

• Place the unit on a level surface.
• Do not install the unit in a location near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, excessive dust, mechanical vibration or shock.
• Good air circulation is essential to prevent internal heat buildup in the unit. Place the unit in a location with adequate air circulation. Do not place the unit on a soft surface.

On cleaning the cabinet

Clean the cabinet, panel and controls with a soft cloth lightly moistened with mild detergent solution. Do not use any type of abrasive pad, scouring powder or solvent such as alcohol or benzine.

On repacking

Do not throw away the carton and the packing material. It makes an ideal container to transport the unit in.

For the customers in the U.S.A.

For detailed precautions, see the leaflet "IMPORTANT SAFEGUARD".

If you have any question or problem concerning your unit, please consult your nearest Sony dealer.

CAUTION

TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED AC PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

Connections

Location of Controls

- Connect the AC power cord last. Make sure power is off. - Cord plugs and jacks are color coded. Red plugs and jacks are for right channel (R) and white ones for the left channel (L) - The cable connectors should be fully inserted into the jacks. A loose connection may cause hum and noise. - Keep speaker cords, connecting cords and power cords away from the AM loop antenna and the tuner's antenna lead-in to avoid possible noise pickup.

To change the AM tuning interval The AM tuning interval is preset at the factory to 10 kHz to match the frequency allocation system of your country. To change the interval, proceed as follows. 1 Press the POWER switch to turn on the unit. 2 Set the BAND FM/AM selector to AM. 3 Press the POWER switch to turn off the unit. 4 Hold the TUNING knob in the "+" position, and then press the POWER switch to turn on the unit. To reset the interval, follow the same procedure. Note When the interval is changed, all stored stations will be erased from the memory. After changing the interval, be sure to store the stations again.

Tuning in Automatically Before reception, be sure to connect the supplied AM and EM antenna

POWER → ON Amplifier 1 Set the amplifier to the tuner mode VIDEO TAPE CD TUNER PHONO 2 Press BAND FM/AM to select the band. BAND FM/AM "FM" or "AM" appears in the display window. 3 Press AUTO TUNING to release the AUTO TUNING mode. AUTO TUNING "AUTO" disappears in the display window 4 Turn TUNING to select the station. TUNING For a lower frequency. For a higher frequency.

Indicators in the display window
• "TUNED" appears when a station is tuned in
- "STEREO" appears when an FM stereo program of
sufficient signal strength is received

Indicators in the display window
• "TUNED" appears when a station is tuned in
- "STEREO" appears when an FM stereo program of
sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window
• "TUNED" appears when a station is tuned in
- "STEREO" appears when an FM stereo program of
sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received
Indicators in the display window • "TUNED" appears when a station is tuned in • "STEREO" appears when an FM stereo program of sufficient signal strength is received

4 Turn TUNING to select the station. TUNING For a lower frequency. For a higher frequency.

3 Press AUTO TUNING to release the AUTO TUNING mode. AUTO TUNING "AUTO" disappears in the display window

2 Press BAND FM/AM to select the band. BAND FM/AM "FM" or "AM" appears in the display window.

1 Set the amplifier to the tuner mode VIDEO TAPE CO TUNER PHONO

Tuning in Manually POWER → ON Amplifier 1 3 4 2

Storing Station Frequencies into Memory

How many stations can be stored? Up to 10 stations can be stored in any order for each alphabet (A. B. C). Therefore, 30 stations can be stored in total If you cannot store a station successfully You can store a station only while "MEMORY" is displayed. If the "MEMORY" indicator has gone off, press MEMORY again How long does a station remain stored? • Storing a new station on a used code erases the previously stored one. • The stored station is maintained for approximately one month even if the power remains off.
How long does a station remain stored? a. Spring a new station on a used code era
previously stored one.
• The stored station is maintained for approximately one
month even if the power remains off.
If you cannot store a station successfully
You can store a station only while MEMORY is displayed. If the "MEMORY" indicator has gone off, press MEMORY
again
How many stations can be stored?
Up to 10 stations can be stored in any order for each
alphabet (A, B, C). Therefore, 50 stations can be stored in total

Tuning into a Stored Station Directly

Which stations are skipped during memory scanning? The memory scan will skip stations which have a very weak signal. If you cannot scan successfully Turn the TUNING knob while the code indicator is flashing. If the flashing has stopped, press MEMORY SCAN again

Troubleshooting

Before going through the check list below, first refer back to the connection and operating procedures. Should any problem persist after you have made these checks, consult your nearest Sony dealer.

Trouble	Cause	Remedy
No sound.	Switches of the amplifier are wrongly set.	Set them correctly.
Unable to receive stored stations.	Frequency is incorrectly stored.	Store the correct frequency.
STEREO indicator blinks.	Antenna direction and location are not correct.	Check the setting of antenna.
	Different frequency is used from that of the broadcasting station.	Set to the correct frequency.
	Signal is too weak.	Connect an external antenna for FM.
Too many noises.	Picking up noises from other electrical apparatus.	Move the tuner and antenna lead-in wire away from the noise sources.
	Antenna direction and location are not correct.	Check the setting of the antenna.
	Antenna wire collects unnecessary radio waves or noises.	Replace it with a coaxial cable.
	There are working TVs, transceivers and amateur wireless units in the vicinity.	Do not use noise-producing apparatus near the tuner.
	One antenna is used for more than two tuners, or with a TV set.	Use a distributor.
Unable to scan stored stations.	TUNING is not operated.	First press MEMORY SCAN and then turn TUNING.

Specifications

FM tuner section

Tuning range 87.5 - 108 MHz

Antenna terminals 75 ohms unbalanced

300 ohms balanced

Intermediate frequency

10.7 MHz

Sensitivity (at 50 dB quieting)

22.1 dBf, 7 μV (mono).

42.1 dBf, 70 μV (stereo)

Usable sensitivity 19.5 dBf, 5 μV (IHF)

Signal-to-noise ratio (at 75 kHz deviation)

80 dB (mono), 75 dB (stereo)

Harmonic distortion 0.3% (mono), 0.5% (stereo) at 1 kHz

Separation 35 dB at 1 kHz

Frequency response 30 Hz - 15 kHz -0.5 dB

Selectivity 55 dB at 400 kHz

AM suppression ratio 54 dB

Image response ratio 50 dB

IF response ratio 90 dB

Spurious response ratio

70 dB

Automatic tuning threshold

17.8 μV (30 dBf)

Output 775 mV, 4.7 kilohms (at 75 kHz deviation)

AM tuner section

Tuning range 530 - 1,710 kHz (10 kHz)

Antenna AM loop antenna, External antenna

terminal

Intermediate frequency

450 kHz

Usable sensitivity AM loop antenna: 500 μV/m (1,000 kHz)

Signal-to-noise ratio 54 dB

Harmonic distortion 0.5%

Selectivity 38 dB (10 kHz)

General

Power requirements 120 V AC, 60 Hz

Power consumption 8 W

Dimensions Approx. 430 x 80 x 295 mm (w/h/d)

(17 × 3 ^1 / 4 × 11 ^5 / 8 inches)

Weight Approx. 2.6 kg (5 lb 12 oz)

Accessories supplied CONTROL S cord (1)

Audio connecting cord (1)

AM loop antenna (1)

FM wire antenna (1)

Design and specifications are subject to change without notice.
