BRUGSANVISNING VT-SMKB1 Vitek
VITEK
PERFORMANCE YOU NEED
QUALITY YOU TRUST
VT-SMKB1 / SMKC1
SIDE VIEW B/W & COLOR SMOKE DETECTOR CAMERAS
1/3" B/W CCD WITH 420H TVL
MINIMUM ILLUMINATION OF .2 LUX
▶ CAMERA MOUNTED ON ADJUSTABLE GIMBAL TO ACHIEVE PERFECT VIEWING ANGLE
DIMENSIONS: 5.12" (OD) X 2.29" (H)
VT-SMKCI:
1/4" B/W CCD WITH 420H TVL
MINIMUM ILLUMINATION OF .92 LUX
▶ CAMERA MOUNTED ON ADJUSTABLE GIMBAL TO ACHIEVE PERFECT VIEWING ANGLE
DIMENSIONS: 5.12" (OD) X 2.29" (H)
Discreet surveillance made easy. Simple plug and play camera allows for vertical adjustment to obtain the optimum viewing angle with ease. Comes standard with A 3.6mm wide angle lens. 2.9mm, 6mm, 8mm, and 12mm lenses are also available.
PRELIMINARY SPEC SHEET
| Specifications | VT-SMKB1 | VT-SMKCI |
| Image Device | 1/3" B/W Sharp CCD image Sensor | 1/4" DSP Color Panasonic CCD Image Sensor |
| Effective Pixels | 510 x 492 | 510 x 492 |
| Resolution | 420 TV Lines | 420 TV Lines |
| Minimum Illumination | 0.2 Lux / F1.4 | 0.92 Lux / F1.4 |
| S/N Ratio | More Than 48dB | More Than 48dB |
| Electronic Shutter | 1/60 to 1/100,000 sec. | 1/60 to 1/100,000 sec. |
| AGC | On | On |
| Sync. Mode | Internal Sync. | Internal Sync. |
| Scanning System | 2:1 Interlace | 2:1 Interlace |
| Gamma Correction | 0.45 | 0.45 |
| Horizontal Sync. Frequency | 15.734KHz | 15.734KHz |
| Vertical Sync. Frequency | 60Hz | 60Hz |
| Video Output | Composite: 1.0 Vp-p / 75Ω | Composite: 1.0 Vp-p / 75Ω |
| Power Source | 12VDC | 12VDC |
| Power Consumption | 120mA | 120mA |
| Operation Temperature | -10° ~ 50°C (14° ~ 122°F) Less Than 80% RH | -10° ~ 50°C (14° ~ 122°F) Less Than 80% RH |
| Standard Lens | f3.6mm (2.9 / 6 / 8 / 12mm Optional) | f3.6mm (2.9 / 6 / 8 / 12mm Optional) |
| Dimensions (W x H) | 5.12" x 2.29" (130 x 58mm) | 5.12" x 2.29" (130 x 58mm) |
| Weight | 12.34 Oz. / 350 g. / 0.77 Lbs. | 12.34 Oz. / 350 g. / 0.77 Lbs. |
9970 GLENOAKS BLVD. UNIT B SUN VALLEY, CA 91352
PHONE: 888-VITEK-70 818-771-0300 FAX: 818-771-0400
WWW.VITEKCCTV.COM
