AL8200ED - Washing machine ASPES - Free user manual and instructions
Find the device manual for free AL8200ED ASPES in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Washing Machine |
| Brand | Aspes |
| Model | AL8200ED |
| Installation Type | Freestanding |
| Loading Type | Front Load |
| Capacity | 8 kg |
| Dimensions (H x W x D) | 850 x 600 x 600 mm |
| Weight | 70 kg |
| Power Supply | 220-240 V, 50 Hz |
| Power Consumption | 2000 W |
| Energy Efficiency Class | A |
| Spin Speed | Up to 1200 rpm |
| Number of Programs | 15 |
| Noise Level (Wash/Spin) | 56 dB / 76 dB |
| Water Consumption per Cycle | 50 L |
| Child Lock | Yes |
| Overflow Protection | Yes |
| Delay Start | Up to 24 hours |
| Display | LED |
| Drum Material | Stainless Steel |
| Maintenance | Clean filter regularly; descale every 3 months |
| Spare Parts Availability | Available through authorized service centers |
| Reparability Index (France) | 7.5 / 10 |
Frequently Asked Questions - AL8200ED ASPES
How do I install the washing machine?
Remove all packaging and transit bolts. Adjust the feet to level the machine. Connect the water inlet hose to a cold water tap with a 3/4 inch thread. Attach the drain hose to a standpipe or sink drain. Plug into a grounded outlet. Run a cleaning cycle before first use.
What is the maximum load capacity?
The maximum load capacity is 8 kg for cotton programs. Overloading may affect washing performance and cause vibration.
How do I select a program?
Turn the program dial to the desired cycle, e.g., Cotton, Synthetics, Delicates, etc. Adjust temperature and spin speed if needed. Press the 'Start/Pause' button to begin.
The machine is not draining water. What should I do?
Check if the drain hose is kinked or blocked. Clean the pump filter located at the bottom front. Ensure the drain pipe is not clogged. Restart the drain/spin cycle.
How do I clean the detergent drawer?
Pull out the drawer, press the lever to remove it completely. Rinse under warm water, scrubbing with a brush if needed. Wipe the drawer compartment. Reinsert and lock.
What does the error code 'E01' mean?
Error code E01 indicates a door lock problem. Ensure the door is fully closed and latched. If persists, check the door lock mechanism or contact service.
Can I use the machine with a sink drain?
Yes, you can connect the drain hose to a sink drain using a suitable adapter. Ensure the drain hose is at a height of 60-100 cm from the floor.
How often should I descale the machine?
Descaling is recommended every 3 months using a descaling agent or vinegar. Run an empty hot wash (90°C) with the descaling product.
Why is the machine vibrating excessively?
Check that the transit bolts are removed. Ensure the machine is leveled by adjusting the feet. Do not overload the drum. Distribute heavy items evenly.
Where can I find spare parts?
Spare parts such as belts, filters, hoses, and door seals are available from authorized Aspes service centers or online spare parts retailers. Use your model number AL8200ED.
User questions about AL8200ED ASPES
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Washing machine in PDF format for free! Find your manual AL8200ED - ASPES and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. AL8200ED by ASPES.
USER MANUAL AL8200ED ASPES
ENERG
AL8200ED
. aspes
bar
| Category | Value | |---|---| | A | 10 | | B | 20 | | C | 30 | | D | 40 | | E | 50 | | F | 60 | | G | 70 |
8,0kg
3:3847L
A B CDEFG
ABCD
