| Product Type | Refrigerator |
| Brand | Eqtemp |
| Model | ACR1602G |
| Energy Class | E |
| Total Gross Capacity | 160 L |
| Refrigerator Net Capacity | 120 L |
| Freezer Net Capacity | 40 L |
| Height | 145 cm |
| Width | 55 cm |
| Depth | 58 cm |
| Weight | 45 kg |
| Power Supply | 220-240 V, 50 Hz |
| Power Consumption | 120 kWh/year |
| Noise Level | 42 dB |
| Climate Class | N, ST |
| Defrost Type | Static (manual defrost) |
| Shelves Material | Tempered glass |
| Reversible Door | Yes |
| Thermostat Control | Mechanical dial |
| Interior Light | Yes, LED |
| Leveling Legs | Yes, adjustable |
| Cleaning Instructions | Wipe interior with warm soapy water, dry thoroughly |
| Spare Parts Available | Shelves, door gasket, thermostat |
| Repairability Index | 7.5 / 10 |
| Manual Download | Available in PDF on notice-facile.com |
Frequently Asked Questions - ACR1602G Eqtemp
How do I change the temperature on the Eqtemp ACR1602G?
Locate the thermostat dial inside the refrigerator (usually on the back wall or ceiling). Turn the dial to a higher number for colder temperature. Allow 24 hours for the temperature to stabilize.
Why is my ACR1602G fridge making noise?
Normal operation includes sounds from the compressor (humming) and refrigerant flow (gurgling). If you hear loud banging or hissing, the fridge may not be level. Adjust the leveling legs at the front.
How often should I defrost the freezer?
Defrost when ice build-up reaches 5 mm thickness. To defrost, unplug the fridge, remove food, and leave the door open. Never use sharp tools to scrape ice.
The door does not close properly. What should I do?
Check that the fridge is level (use the adjustable legs). Also inspect the door gasket for debris or damage. Clean the gasket with warm soapy water and ensure it seals tightly.
Can I reverse the door opening direction?
Yes, the ACR1602G has a reversible door. Refer to the user manual for step-by-step instructions. Typically, you need to unscrew the hinges and relocate them to the opposite side.
What is the recommended temperature for storing food?
Set the fridge thermostat so the internal temperature stays between 34°F and 40°F (1°C to 4°C). For the freezer, aim for 0°F (-18°C). Use a separate thermometer to verify.
How do I clean the ACR1602G?
Unplug the fridge. Remove all shelves and drawers. Wipe interior surfaces with a solution of warm water and mild dish soap. Rinse with clean water and dry thoroughly. Clean the condenser coils (at the back) annually to maintain efficiency.
Where can I download the user manual?
Visit notice-facile.com and search for 'Eqtemp ACR1602G'. The manual is available in PDF format for free.
The fridge is not cooling enough. What could be wrong?
Check if the thermostat is set to a colder number. Ensure the door is not left open and the gasket seals properly. Clean the condenser coils at the back. If the problem persists, the compressor or thermostat may need professional service.
Can I replace the interior light bulb?
The ACR1602G uses an LED light which is not user-replaceable. If the light fails, contact a qualified technician or the manufacturer for assistance.
