PLBNPS11 - Subwoofer Pyle - Free user manual and instructions

Product Type	Powered Subwoofer
Model	PLBNPS11
Brand	Pyle
Speaker Size	11 inches
Amplifier Power (RMS)	200 Watts
Amplifier Power (Peak)	400 Watts
Frequency Response	30 Hz - 200 Hz
Impedance	4 Ohms
Input Sensitivity	200 mV
Low Pass Crossover	Adjustable 40-200 Hz
Phase Switch	0° / 180°
Audio Inputs	RCA Line Level
Auto Power On/Off	Yes
Enclosure Type	Bandpass
Dimensions (W x H x D)	18.5 x 15.4 x 14.6 inches
Weight	24.5 lbs
Power Supply	AC 110-120V, 60Hz
Power Consumption	300 Watts
Fuse Rating	2.5A, 250V
Maintenance	Wipe with dry cloth; do not use solvents
Safety	Do not expose to rain or moisture; unplug during storms
Spare Parts / Repairability	No user-serviceable parts; contact authorized service
Warranty	1 Year Limited
Recommended Use	Home theater or car audio (with inverter)

Frequently Asked Questions - PLBNPS11 Pyle

How do I connect the subwoofer to my receiver?

Use an RCA subwoofer cable to connect the LFE or sub out on your receiver to the Line In on the subwoofer. If your receiver has a dedicated subwoofer output, use that.

Where should I place the subwoofer for best bass?

Place the subwoofer in a corner or along a wall to reinforce low frequencies. Avoid placing it too close to furniture that may rattle. Experiment with location to find the smoothest response.

What does the phase switch do?

The phase switch (0° or 180°) adjusts the timing of the subwoofer’s output relative to your main speakers. Set it to the position that produces the loudest, most integrated bass at your listening position.

How do I set the crossover frequency?

Set the Low Pass Crossover knob to match your main speakers’ capabilities. Typically, for small speakers set it around 80-100 Hz, for larger speakers try 60-80 Hz. Adjust to taste.

Why is there no sound coming from the subwoofer?

Check that the subwoofer is powered on, the power cord is connected, and the LED is lit. Ensure the audio input cable is securely connected. Verify that your receiver’s subwoofer output is enabled.

Can I use this subwoofer in my car?

The subwoofer is designed for home use with 110-120V AC power. For car use, you would need a power inverter to convert 12V DC to 110V AC. Ensure the inverter can handle at least 300W.

How do I clean and maintain the subwoofer?

Unplug the unit before cleaning. Wipe the cabinet with a soft, dry cloth. Do not use any liquids or abrasive cleaners. Keep the subwoofer away from direct sunlight and moisture.

What is the auto power on/off feature?

The subwoofer will automatically turn on when it detects an audio signal at the input, and turn off after a few minutes of no signal to save energy. This feature can be turned off if desired.

Can I daisy-chain multiple subwoofers?

Yes, you can use the Line Out or Thru output (if present) to connect a second subwoofer. Alternatively, use a Y-splitter from your receiver. Ensure the total impedance load is safe.

What should I do if the subwoofer produces a humming noise?

Hum is often caused by a ground loop. Try using a ground loop isolator on the RCA cable. Ensure the subwoofer and receiver are on the same electrical circuit. Keep the subwoofer away from power cables.

USER MANUAL PLBNPS11 Pyle

with Built-in Illuminating LED Lights

PYLE

PyleUSA.com

WIRING CONNECTION

Power amplifier for schematic diagram.

Connect the power amplifier to the positive and negative terminals accordingly as shown.

Close-up of a circular mechanical component with two cylindrical pins, mounted on a rectangular base (no text or symbols visible)

Exterior view of a PYLE audio amplifier box with two speakers and blue-lit speaker screen (no text or symbols visible)

REMOTE CONTROL FEATURES

1. Turn ON/Standby: Press this key to turn on LEDs or switch to standby mode.

2/9. Dynamic Mode button: Switch from dynamic mode to color mode or switch between dynamic modes.

3/8. Dynamic Mode Speed button: Use these buttons to adjust dynamic mode speed. If the unit is in static mode, pressing these buttons will switch unit to dynamic mode.

4/5. Static Color Adjust button: Use this button to swit h between static colors. Pressing these keys while in dynamic mode will switch the unit to static mode.

6/7. Brightness Adjust button: Pressing these buttons will adjust brightness while in static mode. If these buttons are pressed while unit is in dynamic mode, it will switch to static mode.

1. Demo Mode button: This button will switch the unit into demo mode. While in demo mode, unit will loop through 9 of the dynamic modes with each repeating 3 times.

PLBNPS18

8" Single Series Vented Subwoofer Enclosure Rear Vented Design with Built-in Illuminating LED Lights

Technical Specs:

• Construction Materials: 15mm Particle Board + Multilayer Board
  • Power Rating: 400 Watts Max Power
• Voice Coil: 1.5"
• Impedance: 4 Ohms
• Magnet: 30 Oz
• Sensitivity: 89 dB
  • Frequency Response: 45-800 Hz
• Remote Control Battery Operated, Requires (1) x 'CR2025' Batteries
• Battery Type: 3V Lithium Battery
• Battery Life: Up to 2+ Hours
• Product Dimensions (L x W x H): 17.3" x 11.8" x11.0"-inches

PLBNPS11

10" Single Series Vented Subwoofer Enclosure Rear Vented Design with Built-in Illuminating LED Lights

Technical Specs:

• Construction Materials: 15mm Particle Board + Multilayer Board
  • Power Rating: 500 Watts Max Power
• Voice Coil: 2.0"
• Impedance: 4 Ohms
• Magnet: 40 Oz
• Sensitivity: 90 dB
  • Frequency Response: 35-500 Hz
• Remote Control Battery Operated, Requires (1) x 'CR2025' Batteries
• Battery Type: 3V Lithium Battery
• Battery Life: Up to 2+ Hours
• Product Dimensions (L x W x H): 18.1" x 13.0" x 12.6" -inches

PLBNPS12

12" Single Series Vented Subwoofer Enclosure Rear Vented Design with Built-in Illuminating LED Lights

Technical Specs:

• Construction Materials: 15mm Particle Board + Multilayer Board
  • Power Rating: 600 Watts Max Power
• Voice Coil: 2.0"
• Impedance: 4 Ohms
• Magnet: 50 Oz
• Sensitivity: 91 dB
  • Frequency Response: 25-300 Hz
• Remote Control Battery Operated, Requires (1) x 'CR2025' Batteries
• Battery Type: 3V Lithium Battery
• Battery Life: Up to 2+ Hours
• Product Dimensions (L x W x H): 19.6" x 14.1' x 14.5" -inches

Features:

• Rear Vented Design
  • High Powered Woofers with a Silver Paper Cone
  • Rubber Edge Suspension
• Smooth Carpet Finish
  • 4 Layer Dual Voice Coil
• Binding Post Connectors
  • Perfect for Truck and Behind the Seat
  • High-Quality Construction

What's in the Box:

• Subwoofer Box
  • LED Remote Control

Line drawing of a PYLE industrial enclosure with two side flanges and a central vent (no text or symbols)

Questions? Issues?

We are here to help!

Phone: [phone]

Email: [e-mail]

California Prop 65 Warning

! WARNING:

This product contains Nickel carbonate which is known to the state of California to cause cancer birth defects and other reproductive harm. Do not ingest.

For more info go to: www.P65warnings.ca.gov
